IEI Technology PUZZLE-M801 User Manual

1u network appliance
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PUZZLE-M801
MODEL:
PUZZLE-M801
1U Network Appliance with Marvell® ARMADA® 8040 CPU,
DDR4, 32 GB eMMC, 10GbE SFP+ Ports, PCIe x2 Slot, M.2,
Console Port, Dual USB 3.0, Rack Mount, and RoHS
User Manual
Page i
Rev. 1.00 – April 15, 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PUZZLE-M801 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology PUZZLE-M801

Summary of Contents for IEI Technology PUZZLE-M801

  • Page 1 PUZZLE-M801 MODEL: PUZZLE-M801 1U Network Appliance with Marvell® ARMADA® 8040 CPU, DDR4, 32 GB eMMC, 10GbE SFP+ Ports, PCIe x2 Slot, M.2, Console Port, Dual USB 3.0, Rack Mount, and RoHS User Manual Page i Rev. 1.00 – April 15, 2019...
  • Page 2 PUZZLE-M801 Revision Date Version Changes April 15, 2019 1.00 Initial release Page ii...
  • Page 3 PUZZLE-M801 Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 PUZZLE-M801 Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    PUZZLE-M801 Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 M ....................2 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 F ......................3 RONT ANEL 1.5 R ....................... 4 ANEL 1.6 T ..................4 ECHNICAL PECIFICATIONS 1.7 D...
  • Page 6 PUZZLE-M801 4.1 P ..............32 ERIPHERAL NTERFACE ONNECTORS 4.2 I ..............33 NTERNAL ERIPHERAL ONNECTORS 4.2.1 ATX Power Connector (PWR1) ............... 33 4.2.2 Fan Connectors (CPU_FAN1, SYS_FAN1/2/3/5) ..........34 4.2.3 LCM Connector (COM1) ................. 34 4.2.4 M.2 Slot (J3) ..................... 34 4.2.5 PCIe x2 Socket for SATA Module (PCIE2) ............
  • Page 7 PUZZLE-M801 List of Figures Figure 1-1: PUZZLE-M801 Series ....................2 Figure 1-2: PUZZLE-M801 Front Panel ..................3 Figure 1-3: PUZZLE-M801 Rear Panel ..................4 Figure 1-4: Physical Dimensions (millimeters) ................6 Figure 3-1: Top Cover Removal ....................13 Figure 3-2: DIMM Slot Location ....................14 Figure 3-3: HDD Bracket Retention Screws ................
  • Page 8 PUZZLE-M801 List of Tables Table 1-1: PUZZLE-M801 Model Variations .................. 2 Table 1-2: Technical Specifications ....................5 Table 3-1: 1GbE Port1 Pinouts ....................23 Table 3-2: 1GbE Port2 Pinouts ....................23 Table 3-3: 1GbE Port3 Pinouts ....................23 Table 3-4: 1GbE Port4 Pinouts ....................24 Table 3-5: RJ-45 1GbE Connector LEDs ..................

  • Page 9: Introduction

    PUZZLE-M801 Chapter Introduction Page 1...

  • Page 10: Overview

    8040 processor. It is optimized to host VNFs (Virtual Network Functions) and is ideal for SD-WAN. The PUZZLE-M801 supports two 10GbE SFP+ ports and four 1GbE ports for high-speed network applications, and it is equipped with a PCIe x16 (x2 mode) slot for upgrading with expansion cards, such as NIC cards or accelerator cards.

  • Page 11: Features

    PUZZLE-M801 1.3 Features The PUZZLE-M801 features are listed below: ® ®  Powered by Marvell ARMADA 8040 processor  Support two 2400 MHz DDR4 non-ECC RDIMMs (system max. 16 GB)  32 GB eMMC and support two 2.5” SATA SSD/HDD ...

  • Page 12: Rear Panel

    PUZZLE-M801 1.5 Rear Panel An overview of the PUZZLE-M801 rear panel is shown in Figure 1-3 below. Figure 1-3: PUZZLE-M801 Rear Panel 1.6 Technical Specifications The PUZZLE-M801 technical specifications are listed below. System Form Factor ® ® CPU (SoC) Marvell ARMADA 8040 processor (quad-core, 1.8 GHz)

  • Page 13: Table 1-2: Technical Specifications

    PUZZLE-M801 Storage 2 x 2.5" SATA 6Gb/s HDD/SSD bay 32 GB eMMC Operating System Linux Ubuntu 16.04 Expansion PCIe 1 x PCIe x16 (x2 mode) slot 1 x M.2 B-key 2242 slot (supports SATA and USB 3.1 Gen 1 signals)

  • Page 14: Dimensions

    PUZZLE-M801 1.7 Dimensions The physical dimensions are shown below: Figure 1-4: Physical Dimensions (millimeters) Page 6...

  • Page 15: Unpacking

    PUZZLE-M801 Chapter Unpacking Page 7...

  • Page 16: Anti-Static Precautions

     Follow the anti-static precautions outlined in Section 2.1.  Make sure the packing box is facing upwards so the PUZZLE-M801 does not fall out of the box.  Make sure all the components shown in Section 2.2 are present.

  • Page 17: Packing List

    If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the PUZZLE-M801 from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com.

  • Page 18: Optional Items

    PUZZLE-M801 Quantity Item Image RS-232 to console cable (only for SKUs without memory) 2.4 Optional Items The following table lists the optional items that can be purchased separately. Optional Item Image Slide rail (P/N: RAIL-B02) USB to console cable (P/N: 32013-004000-100-RS)

  • Page 19: Installation

    PUZZLE-M801 Chapter Installation Page 11...

  • Page 20: Installation Precautions

    Air Circulation: Make sure there is sufficient air circulation when installing the PUZZLE-M801. The PUZZLE-M801’s cooling vents must not be obstructed by any objects. Blocking the vents can cause overheating of the PUZZLE-M801. Leave at least 5 cm of clearance around the PUZZLE-M801 to prevent overheating. ...

  • Page 21: Top Cover Removal

    PUZZLE-M801 3.2 Top Cover Removal Before installing or maintaining the internal components, the top cover must be removed from the PUZZLE-M801. Follow the steps below to complete the task. Step 1: Remove the four retention screws indicated in Figure 3-1.

  • Page 22: Figure 3-2: Dimm Slot Location

    PUZZLE-M801 Figure 3-2: DIMM Slot Location Step 3: Open the DIMM socket handles. Open the two handles outwards as far as they can. Step 4: Align the DIMM so the notch on the memory lines up with the notch on the memory socket.

  • Page 23: Hdd Installation

    PUZZLE-M801 3.4 HDD Installation The PUZZLE-M801 allows installation of two 2.5” SATA HDD/SSD. To install HDDs into the system, please follow the steps below. Step 1: Remove the top cover from the PUZZLE-M801 by following the instruction described in Section 3.2.

  • Page 24: Figure 3-4: Secure Hdd To The Bracket

    PUZZLE-M801 Figure 3-4: Secure HDD to the Bracket Step 4: Re-connect the SATA connector module to the motherboard. Secure the bracket to the chassis with three screws removed previously (Figure 3-5). Figure 3-5: HDD Installation Step 5: Re-install and secure the top cover to the system.

  • Page 25: Pcie Expansion Card Installation

    PUZZLE-M801 3.5 PCIe Expansion Card Installation The PUZZLE-M801 allows installation of one PCIe x16 (x2 mode) card. To install a PCIe expansion card, please follow the steps below. Step 1: Remove the top cover from the PUZZLE-M801 (refer to Section 3.2).

  • Page 26: Figure 3-7: Disconnect The Expansion Slot Module

    PUZZLE-M801 Step 3: Push the expansion slot module with strength to disconnect the module from the motherboard edge connector. Figure 3-7: Disconnect the Expansion Slot Module Step 4: Remove the blank bracket panel that aligns with the PCIe slot for installing the expansion card.

  • Page 27: Figure 3-9: Pcie Expansion Card Installation

    PUZZLE-M801 Step 5: Align the expansion card to the PCIe slot. Press gently, but firmly, to seat the expansion card correctly in the slot. Install the bracket screw to secure the card to the expansion slot module. Figure 3-9: PCIe Expansion Card Installation...

  • Page 28: Figure 3-10: Expansion Slot Module Installation

    PUZZLE-M801 Figure 3-10: Expansion Slot Module Installation Step 7: Secure the expansion slot module with the four retention screws previously removed. Step 8: Re-install the top cover. Page 20...

  • Page 29: Module Installation

    The M.2 slot is keyed in the B position and provides mounting screw position for 2242-size M.2 module. To install an M.2 module, please follow the steps below. Step 1: Remove the top cover from the PUZZLE-M801 (refer to Section 3.2). Step 2: Locate the M.2 slot on the motherboard.

  • Page 30: External Interface Connection

    Each Ethernet connector has a physical number (printed on the front panel) and a logical number (under Linux). The following table shows the physical number to logical number relationship on the PUZZLE-M801. Physical Number Logical Number 10GbE SFP+...

  • Page 31: Lan Connection - 1Gbe

    PUZZLE-M801 3.7.1 LAN Connection - 1GbE The four 1GbE LAN connectors on the front panel allow connection to an external network. The pinouts of the LAN connectors are listed below. Description Description D_MDP0 D_MDN0 D_MDP2 D_MDP1 D_MDN2 D_MDN1 D_MDP3 D_MDN3...

  • Page 32: Figure 3-11: Rj-45 1Gbe Connector

    PUZZLE-M801 Description Description A_MDP0 A_MDN0 A_MDP2 A_MDP1 A_MDN2 A_MDN1 A_MDP3 A_MDN3 Table 3-4: 1GbE Port4 Pinouts Figure 3-11: RJ-45 1GbE Connector The RJ-45 Ethernet connector has two status LEDs, one yellow and one green/orange. The yellow LED indicates activity on the port and the green/orange LED indicates the speed.

  • Page 33: Lan Connection - 10Gbe Sfp

    PUZZLE-M801 3.7.2 LAN Connection - 10GbE SFP+ The two 10GbE SFP+ connectors on the front panel allow transfer rate of up to 10 gigabits per second. The pinouts of the 10GbE LAN connectors are listed below. Description Description SFP+2_TX_FAULT SFP+2_SRD_RX-...

  • Page 34: Console Connection

    3.7.3 Console Connection The PUZZLE-M801 has one RJ-45 serial device connector on the front panel. The RJ-45 connector for the serial port can be identified easily as the RJ-45 for the network has two LEDs on the port, while the connectors for the serial cables don’t. The pinouts of the serial port are listed below.

  • Page 35: Mounting The System

    PUZZLE-M801 3.8 Mounting the System The PUZZLE-M801 is shipped with two mounting brackets that support 1U rack mount. To install the mounting brackets, please follow the steps below. Step 1: Align the three retention screw holes in each bracket with the corresponding retention screw holes on the sides of the PUZZLE-M801.

  • Page 36: Available Drivers

    PUZZLE-M801 Figure 3-14: Power-on 3.10 Available Drivers All the drivers for the PUZZLE-M801 are available on IEI Resource Download Center (https://download.ieiworld.com). Type PUZZLE-M801 and press Enter to find all the relevant software, utilities, and documentation. Figure 3-15: IEI Resource Download Center...

  • Page 37: Driver Download

    3.10.1 Driver Download To download drivers from IEI Resource Download Center, follow the steps below. Step 1: Go to https://download.ieiworld.com. Type PUZZLE-M801 and press Enter. Step 2: All product-related software, utilities, and documentation will be listed. You can choose Driver to filter the result.
  • Page 38 PUZZLE-M801 Page 30...

  • Page 39: Interface Connectors

    PUZZLE-M801 Chapter Interface Connectors Page 31...

  • Page 40: Peripheral Interface Connectors

    PUZZLE-M801 4.1 Peripheral Interface Connectors The connector locations of the PUZZLE-M801’s motherboard are shown below. The connector pinouts for these connectors are listed in the following sections. Page 32...

  • Page 41: Internal Peripheral Connectors

    PUZZLE-M801 4.2 Internal Peripheral Connectors The table below shows a list of the connectors on the motherboard. Pinouts of these connectors can be found in the following sections. Connector Type Label ATX power connector 24-pin connector PWR1 Fan connectors 4-pin wafer...

  • Page 42: Fan Connectors (Cpu_Fan1, Sys_Fan1/2/3/5)

    PUZZLE-M801 Description Description +12V +5 V +12V +5 V +3.3 V Table 4-2: ATX Power Connector (PWR1) Pinouts 4.2.2 Fan Connectors (CPU_FAN1, SYS_FAN1/2/3/5) PIN NO. DESCRIPTION +12V FANIO Table 4-3: Fan Connectors (CPU_FAN1, SYS_FAN1/2/3/5) Pinouts 4.2.3 LCM Connector (COM1) PIN NO.
  • Page 43 PUZZLE-M801 PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_D- USB3.0_RX- SIM_RST USB3.0_RX+ SIM_CLK SIM_DATA USB3.0_TX- SIM_PWR USB3.0_TX+ I2C_CLK SRD_RX+ I2C_DAT SRD_RX- SRD_TX- SRD_TX+ RESET- CLKREQ REFCLK- LAN_WOL# REFCLK+ ANTCTL0 COEX3 ANTCTL1 COEX2 ANTCTL2 COEX1 ANTCTL3 PCIE_RST- +3.3V +3.3V Page 35...

  • Page 44: Pcie X2 Socket For Sata Module (Pcie2)

    PUZZLE-M801 PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V Table 4-5: M.2 Slot (J3) Pinouts 4.2.5 PCIe x2 Socket for SATA Module (PCIE2) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V +12V +12V +12V +3.3V +3.3V +3.3V SATA_TX0- SATA_TX0+ SATA_RX0- SATA RX0+...

  • Page 45: Power Switch Connector (Pwr_Btn1)

    PUZZLE-M801 4.2.6 Power Switch Connector (PWR_BTN1) PIN NO. DESCRIPTION PWRBTN_SW+ PWRBTN_SW- Table 4-7: Power Switch Connector (PWR_BTN1) Pinouts 4.2.7 USB DOM Connector (JP11) PIN NO. DESCRIPTION PIN NO. DESCRIPTION   VCC5V   USB-   USB+  ...

  • Page 46: A Regulatory Compliance

    PUZZLE-M801 Appendix Regulatory Compliance Page 38...
  • Page 47 PUZZLE-M801 DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives:  EMC Directive 2014/30/EU  Low-Voltage Directive 2014/35/EU  RoHS II Directive 2011/65/EU If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 48 PUZZLE-M801 Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ...
  • Page 49 PUZZLE-M801 Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 1999/5/CE. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.
  • Page 50 PUZZLE-M801 FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and   This device must accept any interference received, including interference that may cause undesired operation.

  • Page 51: B Safety Precautions

    PUZZLE-M801 Appendix Safety Precautions Page 43...

  • Page 52: Safety Precautions

    In a site where the ambient temperature exceeds the rated temperature B.1.2 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the PUZZLE-M801 may result in permanent damage to the PUZZLE-M801 and severe injury to the user. Page 44...

  • Page 53: Product Disposal

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the PUZZLE-M801. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the PUZZLE-M801 is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 54: Maintenance And Cleaning Precautions

    B.2 Maintenance and Cleaning Precautions When maintaining or cleaning the PUZZLE-M801, please follow the guidelines below. B.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the PUZZLE-M801, please read the details below.  The interior of the PUZZLE-M801 does not require cleaning. Keep fluids away from the PUZZLE-M801 interior.
  • Page 55 PUZZLE-M801  Vacuum cleaner – Using a vacuum specifically designed for computers is one of the best methods of cleaning the PUZZLE-M801. Dust and dirt can restrict the airflow in the PUZZLE-M801 and cause its circuitry to corrode.  Swabs - Swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas.

  • Page 56: C Hazardous Materials Disclosure

    PUZZLE-M801 Appendix Hazardous Materials Disclosure Page 48...
  • Page 57 PUZZLE-M801 The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 58 PUZZLE-M801 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...
