PUZZLE-IN001A
MODEL:
PUZZLE-IN001A
1U Network Appliance with 8th Gen. Intel® Core™ i3,
Pentium®, Celeron® and Intel® Xeon® E Processor,
DDR4, Eight 5GbE Ports, Two PCIe Slots, M.2, PCIe Mini,
Redundant PSU, Rack Mount, and RoHS Compliant
User Manual
Page i
Rev. 1.01 – November 12, 2020
