- Page 1 PUZZLE-IN003B MODEL: PUZZLE-IN003B ® ® Desktop Network Appliance with Intel Atom C3000 Series Processor, Four DDR4, Six GbE Ports, Two 10GbE SFP+, Two M.2, PCIe Mini, Rack Mount, and RoHS Compliant User Manual Page i Rev. 1.00 – January 21, 2020...
- Page 2 PUZZLE-IN003B Revision Date Version Changes January 21, 2020 1.00 Initial release Page ii...
- Page 3 PUZZLE-IN003B Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 4 PUZZLE-IN003B Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.
-
Page 5: Table Of Contents
PUZZLE-IN003B Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 M ....................2 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 F ......................4 RONT ANEL 1.5 R ....................... 4 ANEL 1.6 T ..................5 ECHNICAL PECIFICATIONS 1.7 D... - Page 6 PUZZLE-IN003B 3.10.1 Jumper Settings ....................28 3.10.1.1 Clear CMOS .................... 28 3.10.1.2 Flash Descriptor Security Override Jumper ..........29 4 BIOS ..........................30 4.1 I ......................31 NTRODUCTION 4.1.1 Starting Setup ....................31 4.1.2 Using Setup ....................31 4.1.3 Getting Help ..................... 32 4.1.4 Unable to Reboot after Configuration Changes ..........
- Page 7 PUZZLE-IN003B 5.2.1 CPLD Programmer Connector (J8) ..............55 5.2.1 Debug Port (DBG_PORT1) ................55 5.2.2 Fan Connectors (CPU_FAN1/2 & SYS_FAN1) ..........56 5.2.1 M.2 A-key Slot (M2_CN1) ................56 5.2.2 M.2 M-key Slot (M2_M1) ................. 57 5.2.3 PCIe Mini Card Slot (MINI_PCIE1) ............... 59 5.2.1 Power Button Connector (PWR_BTN1) ............
- Page 8 PUZZLE-IN003B List of Figures Figure 1-1: PUZZLE-IN003B Series ....................2 Figure 1-2: Front Panel ........................4 Figure 1-3: Rear Panel ........................4 Figure 1-4: Physical Dimensions (millimeters) ................7 Figure 3-1: Top Cover Removal ....................14 Figure 3-2: DIMM Slot Locations ....................15 Figure 3-3: PCIe Mini Slot Location ....................
- Page 9 PUZZLE-IN003B List of Tables Table 1-1: PUZZLE-IN003B Model Variations ................2 Table 1-2: Technical Specifications ....................6 Table 3-1: 1GbE Port Pinouts ...................... 22 Table 3-2: RJ-45 1GbE Connector LEDs ..................22 Table 3-3: 10GbE Port Pinouts ....................23 Table 3-4: RJ-45 Serial Port Pinouts ................... 24 Table 3-5: Clear BIOS Jumper Settings ..................
-
Page 11: Introduction
PUZZLE-IN003B Chapter Introduction Page 1... -
Page 12: Overview
PUZZLE-IN003B 1.1 Overview Figure 1-1: PUZZLE-IN003B Series ® The PUZZLE-IN003B is a compact desktop network appliance series powered by Intel ® Atom C3758/C3558 processor. It is optimized to host VNFs (Virtual Network Functions) and is ideal for SD-WAN. The PUZZLE-IN003B supports six copper GbE ports and two 10GbE SFP+ connections for high-speed network applications. -
Page 13: Features
PUZZLE-IN003B 1.3 Features The PUZZLE-IN003B features are listed below: ® ® Powered by Intel Atom C3000 series processor Support four 2133 MHz DDR4 ECC/non-ECC UDIMMs/RDIMMs (UDIMM up to 64 GB / RDIMM up to 128 GB) ® ... -
Page 14: Front Panel
The system is turned on. No SSD activity SSD Status LED Blinking Blue SSD activity No alert Alert LED Alert message 1.5 Rear Panel An overview of the PUZZLE-IN003B rear panel is shown in Figure 1-3 below. Figure 1-3: Rear Panel Page 4... -
Page 15: Technical Specifications
PUZZLE-IN003B 1.6 Technical Specifications The PUZZLE-IN003B technical specifications are listed in Table 1-2. System ® ® CPU (SoC) Intel Atom C3000 series processor ® ® C0: Intel Atom C3758 (up to 2.20 GHz, 16M cache) ® ® C1: Intel Atom C3558 (up to 2.20 GHz, 8M cache) -
Page 16: Table 1-2: Technical Specifications
PUZZLE-IN003B I/O and Indicators Console 1 x RJ-45 RS-232 1 x USB 3.2 Gen 1 (5 Gb/s) port (external, Type A) 1 x USB 2.0 port (external, Type A) Indicator Power status (blue) SSD status (green) Alert LED (programmable, red) -
Page 17: Dimensions
PUZZLE-IN003B 1.7 Dimensions The physical dimensions are shown below: Figure 1-4: Physical Dimensions (millimeters) Page 7... -
Page 18: Unpacking
PUZZLE-IN003B Chapter Unpacking Page 8... -
Page 19: Anti-Static Precautions
Electrostatic discharge (ESD) can cause serious damage to electronic components, including the PUZZLE-IN003B. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the PUZZLE-IN003B or any other electrical component is handled, the following anti-static precautions are strictly adhered to. -
Page 20: Packing List
If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the PUZZLE-IN003B from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@ieiworld.com. -
Page 21: Optional Items
PUZZLE-IN003B Quantity Item Image Mounting bracket screw (M4*6) 2.4 Optional Items The following table lists the optional items that can be purchased separately. Optional Item Image RS-232 to console cable (P/N: 32005-005100-100-RS) 20-pin Infineon TPM 2.0 module, software management tool, firmware v5.5... -
Page 22: Installation
PUZZLE-IN003B Chapter Installation Page 12... -
Page 23: Installation Precautions
Air Circulation: Make sure there is sufficient air circulation when installing the PUZZLE-IN003B. The PUZZLE-IN003B’s cooling vents must not be obstructed by any objects. Blocking the vents can cause overheating of the PUZZLE-IN003B. Leave at least 5 cm of clearance around the PUZZLE-IN003B to prevent overheating. ... -
Page 24: Top Cover Removal
PUZZLE-IN003B 3.2 Top Cover Removal Before installing or maintaining the internal components, the top cover must be removed from the PUZZLE-IN003B. Follow the steps below to complete the task. Step 1: Remove the retention screw indicated in Figure 3-1. Step 2: Slide the top cover towards the rear side and gently lift the top cover (Figure 3-1). -
Page 25: Figure 3-2: Dimm Slot Locations
PUZZLE-IN003B To install the DIMM module, please follow the steps below. Step 1: Remove the top cover from the PUZZLE-IN003B. Please follow the instruction described in Section 3.2. Step 2: Locate the DIMM slots on the motherboard. Figure 3-2: DIMM Slot Locations Step 3: Open the DIMM socket handles. -
Page 26: Module Installation
PUZZLE-IN003B 3.4 M.2 Module Installation To install an M.2 module, please follow the steps below. Step 1: Remove the top cover from the PUZZLE-IN003B. See Section 3.2. Step 2: Locate the M.2 slots on the motherboard. Step 3: Remove the on-board retention screw. -
Page 27: Pcie Mini Card Installation
PUZZLE-IN003B 3.5 PCIe Mini Card Installation The PUZZLE-IN003B has one full-size/half-size PCIe Mini slot on the motherboard. To install a full-size module, follow the instructions below. Step 1: Remove the top cover from the PUZZLE-IN003B. See Section 3.2. Step 2: Locate the PCIe Mini slot on the motherboard (Figure 3-3). -
Page 28: Half-Size Pcie Mini Card Installation
A WWAN module must be installed in the PCIe Mini slot (MINI_PCIE1) to provide WWAN communication. To install a SIM card, please follow the steps below. Step 1: Remove the top cover from the PUZZLE-IN003B. See Section 3.2. Step 2: Locate the SIM card slot on the motherboard (Figure 3-4). Page 18... -
Page 29: Figure 3-4: Sim Card Slot Location
PUZZLE-IN003B Figure 3-4: SIM Card Slot Location Step 3: Unlock the SIM card slot cover by sliding the cover in the direction as shown by the arrow in Figure 3-5. Figure 3-5: Unlock SIM Card Slot Cover Page 19... -
Page 30: Figure 3-6: Sim Card Installation
PUZZLE-IN003B Step 4: Open the slot cover and place a SIM card onto the slot. The cut mark on the corner should be facing away from the slot as shown in Figure 3-6. Figure 3-6: SIM Card Installation Step 5: Close the slot cover and lock it by sliding it in the direction as shown by the arrow in Figure 3-7. -
Page 31: External Interface Connection
PUZZLE-IN003B 3.6 External Interface Connection The front panel has several external I/O ports. The pinouts of these I/O ports are listed in the following sections. Page 21... -
Page 32: Lan Connection - 1Gbe
PUZZLE-IN003B 3.6.1 LAN Connection - 1GbE The 1GbE LAN connectors on the front panel allow connection to an external network. The pinouts of the LAN connectors are listed below. Description Description MDIA3- MDIA1+ MDIA3+ MDIA2+ MDIA2- MDIA0- MDIA1- MDIA0+ Table 3-1: 1GbE Port Pinouts Figure 3-8: RJ-45 1GbE Connector The RJ-45 Ethernet connector has two status LEDs, one yellow and one green/orange. -
Page 33: Lan Connection - 10Gbe Sfp
PUZZLE-IN003B 3.6.2 LAN Connection - 10GbE SFP+ The 10GbE SFP+ connectors on the front panel allow transfer rate of up to 10 gigabits per second. The pinouts of the 10GbE LAN connectors are listed below. Description Description SFP+_TX_FAULT SFP+_RX- SFP+_TX_DISABLE... -
Page 34: Console Connection
PUZZLE-IN003B 3.6.3 Console Connection The PUZZLE-IN003B has one RJ-45 serial device connector on the front panel. The RJ-45 connector for the serial port can be identified easily as the RJ-45 for the network has two LEDs on the port, while the connectors for the serial cables don’t. The pinouts of the serial port are listed below. -
Page 35: Mounting The System
PUZZLE-IN003B 3.7 Mounting the System The PUZZLE-IN003B is shipped with two mounting brackets that support 1U rack mount. To install the mounting brackets, please follow the steps below. Step 1: Align the three retention screw holes in each bracket with the corresponding retention screw holes on the sides of the PUZZLE-IN003B. -
Page 36: Power-On Procedure
To power-on the PUZZLE-IN003B please follow the steps below: Step 1: Connect the power adapter shipped with the PUZZLE-IN003B to the power jack on the rear panel. Step 2: Use a power cord to connect the power adapter and the power source. -
Page 37: Resource Download
PUZZLE-IN003B 3.9 Resource Download All the resources for the PUZZLE-IN003B are available on IEI Resource Download Center (https://download.ieiworld.com). Type PUZZLE-IN003B and press Enter to find all the relevant software, utilities, and documentation. Figure 3-12: IEI Resource Download Center 3.10 System Configuration... -
Page 38: Jumper Settings
Step 0: 3.10.1.1 Clear CMOS If the PUZZLE-IN003B fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, short the jumper for 3 seconds or more, then remove the jumper clip. -
Page 39: Flash Descriptor Security Override Jumper
PUZZLE-IN003B 3.10.1.2 Flash Descriptor Security Override Jumper The Flash Descriptor Security Override jumper (J_ME1) allows to enable or disable the ME firmware update. Setting Description Open Disabled (default) Short Enabled Table 3-6: Flash Descriptor Security Override Jumper Settings Figure 3-14: Flash Descriptor Security Override Jumper Location To update the ME firmware, please follow the steps below. -
Page 40: Bios
PUZZLE-IN003B Chapter BIOS Page 30... -
Page 41: Introduction
PUZZLE-IN003B 4.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. NOTE: Some of the BIOS options may vary throughout the life cycle of the product and are subject to change without prior notice. -
Page 42: Getting Help
PUZZLE-IN003B Function Decrease the numeric value or make changes Esc key Main Menu – Quit and not save changes into CMOS Status Page Setup Menu and Option Page Setup Menu -- Exit current page and return to Main Menu F1 key... -
Page 43: Main
PUZZLE-IN003B The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 4.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. -
Page 44: Advanced
PUZZLE-IN003B 4.3 Advanced Use the Advanced menu (BIOS Menu 2) to configure the CPU and peripheral devices through the following sub-menus: WARNING! Setting the wrong values in the sections below may cause the system to malfunction. Make sure that the settings made are compatible with the hardware. -
Page 45: Trusted Computing
PUZZLE-IN003B 4.3.1 Trusted Computing Use the Trusted Computing menu (BIOS Menu 3) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. Advanced Configuration Enables or Disables BIOS... -
Page 46: It8528 Super Io Configuration
PUZZLE-IN003B 4.3.2 IT8528 Super IO Configuration Use the IT8528 Super IO Configuration menu (BIOS Menu 4) to set or change the configurations for the parallel ports and serial ports. Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. Advanced... -
Page 47: Iwdd H/W Monitor
PUZZLE-IN003B Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port. Disable the serial port Disabled Enable the serial port Enabled EFAULT 4.3.3 iWDD H/W Monitor The iWDD H/W Monitor menu (BIOS Menu 6) contains the fan configuration submenu, and displays the system temperature and CPU fan speed. -
Page 48: Smart Fan Mode Configuration (C0 Sku Only)
PUZZLE-IN003B System Temperature System Fan Speeds (C0 SKU only) Voltages: CPU_CORE_VCC +12V +5VSB +3.3V +3.3VSB 4.3.3.1 Smart Fan Mode Configuration (C0 SKU Only) Use the Smart Fan Mode Configuration submenu (BIOS Menu 7) to configure the CPU/system fan temperature and speed settings. NOTE: This submenu is only available in C0 SKU. - Page 49 PUZZLE-IN003B SYS_FAN Smart Fan Control [Auto Mode] Use the CPU_FAN Smart Fan Control options to configure the CPU Smart Fans. The fan spins at the speed set in Manual Mode Manual Mode settings. The fan adjusts its speed using Auto Mode...
-
Page 50: Serial Port Console Redirection
PUZZLE-IN003B 4.3.4 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 8) allows the console redirection options to be configured. Console redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port. - Page 51 PUZZLE-IN003B VT-UTF8 The target terminal type is VT-UTF8 The target terminal type is ANSI ANSI EFAULT Bits per second [115200] Use the Bits per second option to specify the serial port transmission speed. The speed must match the other side. Long or noisy lines may require lower speeds.
-
Page 52: Legacy Console Redirection Settings
PUZZLE-IN003B Space The parity bit is always 0. This option does not provide error detection. Stop Bits [1] Use the Stop Bits option to specify the number of stop bits used to indicate the end of a serial data packet. Communication with slow devices may require more than 1 stop bit. -
Page 53: Nvme Configuration
PUZZLE-IN003B 4.3.5 NVMe Configuration Use the NVMe Configuration menu (BIOS Menu 10) to change and/or set the configuration of the NVMe devices installed in the system. Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. Advanced NVMe Controller and Drive information... -
Page 54: Processor Configuration
PUZZLE-IN003B 4.4.1 Processor Configuration Use the Processor Configuration menu (BIOS Menu 12) to view detailed CPU specifications or enable the Intel Virtualization Technology. Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. IntelRCSetup Processor Configuration Enable/disable CPU -------------------------------------------------- Virtualization... -
Page 55: North Bridge Chipset Configuration
PUZZLE-IN003B 4.4.1 North Bridge Chipset Configuration Use the North Bridge Chipset Configuration menu (BIOS Menu 13) to view detailed memory specifications or enable/disable Intel VT-d. Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. IntelRCSetup North Bridge Chipset Configuration... -
Page 56: South Bridge Chipset Configuration
PUZZLE-IN003B 4.4.1 South Bridge Chipset Configuration Use the South Bridge Chipset Configuration menu (BIOS Menu 14) to configure SATA devices or PCIe interfaces. Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. IntelRCSetup -------------------------------------------------- Configuration of SATA South Bridge Chipset Configuration... -
Page 57: Pcie Ip Configuration
PUZZLE-IN003B Enable/disable port [Enabled] Use the Enable/disable port option to configure the SATA controller. Enables the on-board SATA controller. Enabled EFAULT Disables the on-board SATA controller. Disabled Hot Plug [Disabled] Use the Hot Plug option to enable or disable the hot plug function. -
Page 58: Security
PUZZLE-IN003B Link Speed [Gen3] Use the Link Speed option to configure the PCIe slot speed. Gen1 Gen2 Gen3 EFAULT 4.5 Security Use the Security menu (BIOS Menu 17) to set system and user passwords. Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. -
Page 59: Boot
PUZZLE-IN003B 4.6 Boot Use the Boot menu (BIOS Menu 18) to configure system boot options. Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. Main Advanced IntelRCSetup Security Boot Save & Exit Boot Configuration Select the keyboard Bootup NumLock State... - Page 60 PUZZLE-IN003B Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots. Normal POST messages displayed Disabled OEM Logo displayed instead of POST messages Enabled EFAULT UEFI Boot [Disabled] Use the UEFI Boot option to enable or disable to boot from the UEFI devices.
-
Page 61: Save & Exit
PUZZLE-IN003B 4.7 Save & Exit Use the Safe & Exit menu (BIOS Menu 19) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2019 American Megatrends, Inc. Main Advanced IntelRCSetup... -
Page 62: Interface Connectors
PUZZLE-IN003B Chapter Interface Connectors Page 52... -
Page 63: Peripheral Interface Connectors
PUZZLE-IN003B 5.1 Peripheral Interface Connectors The connector locations of the PUZZLE-IN003B’s motherboard are shown below. The connector pinouts for these connectors are listed in the following sections. Page 53... -
Page 64: Internal Peripheral Connectors
PUZZLE-IN003B 5.2 Internal Peripheral Connectors Internal peripheral connectors on the motherboard and are only accessible when the motherboard is outside of the chassis. The table below shows a list of the connectors on the motherboard. Pinouts of these connectors can be found in the following sections. -
Page 65: Battery Connector (Bat1)
PUZZLE-IN003B 5.2.1 Battery Connector (BAT1) PIN NO. DESCRIPTION Battery+ Table 5-1: Battery Connector (BAT1) Pinouts 5.2.1 CPLD Programmer Connector (J8) PIN NO. DESCRIPTION PIN NO. DESCRIPTION VCC3 Table 5-2: CPLD Programmer Connector (J8) Pinouts 5.2.1 Debug Port (DBG_PORT1) PIN NO. -
Page 66: Fan Connectors (Cpu_Fan1/2 & Sys_Fan1)
PUZZLE-IN003B 5.2.2 Fan Connectors (CPU_FAN1/2 & SYS_FAN1) PIN NO. DESCRIPTION +12V FANIO Table 5-4: Fan Connectors (CPU_FAN1/2 & SYS_FAN1) Pinouts 5.2.1 M.2 A-key Slot (M2_CN1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V USB_D+ +3.3V USB_D- Notch Notch Notch Notch Notch... -
Page 67: M-Key Slot (M2_M1)
PUZZLE-IN003B PIN NO. DESCRIPTION PIN NO. DESCRIPTION PERN0 REFCLKP0 REFCLKN0 SUSCLK PERST0# CLKREQ0# PEWAKE0# WAKE +3.3V +3.3V Table 5-5: M.2 A-key Slot (M2_CN1) Pinouts 5.2.2 M.2 M-key Slot (M2_M1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V PCIE_RXN3 PCIE_RXP3 DAS/DSS# PCIE_TXN3 +3.3V... -
Page 68: Table 5-6: M.2 M-Key Slot (M2_M1) Pinouts
PUZZLE-IN003B PIN NO. DESCRIPTION PIN NO. DESCRIPTION PCIE_RXP2 PCIE_TXN2 PCIE_TXP2 PCIE_RXN1 PCIE_RXP1 PCIE_TXN1 PCIE_TXP1 DEVSLP PCIE_RXN0 PCIE_RXP0 PCIE_TXN0 PCIE_TXP0 PERST# CLKREQ# REFCLKN PEWAKE REFCLKP Notch Notch Notch Notch Notch Notch Notch Notch SUSCLK PEDET +3.3V +3.3V +3.3V Table 5-6: M.2 M-key Slot (M2_M1) Pinouts... -
Page 69: Pcie Mini Card Slot (Mini_Pcie1)
PUZZLE-IN003B 5.2.3 PCIe Mini Card Slot (MINI_PCIE1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V 1.5V MPCIE_M.2_CLKREQ# SIM_VCC SIM_IO CLK_MPCIE_N SIM_CLK CLK_MPCIE_P SIM_RST SIM_VPP PLTRST_PCIE_WIFI_N +3.3V PLTRST_N MPCIE_RXN_C +3.3V MPCIE_RXP_C 1.5V SMB_CLK MPCIE_TXN_C SMB_DATA MPCIE_TXP_C USB_DATA- USB_DATA+ +3.3V +3.3V +3.3V 1.5V +3.3V... -
Page 70: Power Button Connector (Pwr_Btn1)
PUZZLE-IN003B 5.2.1 Power Button Connector (PWR_BTN1) PIN NO. DESCRIPTION PWR_BTN Table 5-8: Power Button Connector (PWR_BTN1) Pinouts 5.2.2 SATA Connector (SATA1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 5-9: SATA 6Gb/s Connector (SATA1) Pinouts 5.2.1 SATA Power Connector (SATA_PWR1) PIN NO. -
Page 71: Spi Flash Connector - Ec (J7)
PUZZLE-IN003B 5.2.3 SPI Flash Connector - EC (J7) PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_CS +3.3V EC_MISO EC_WP EC_CLK EC_MOSI Table 5-12: SPI Flash Connector (J7) Pinouts 5.2.1 TPM Connector (TPM1) PIN NO. -
Page 72: A Regulatory Compliance
PUZZLE-IN003B Appendix Regulatory Compliance Page 62... - Page 73 PUZZLE-IN003B DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive 2014/30/EU Low-Voltage Directive 2014/35/EU RoHS II Directive 2015/863/EU If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
- Page 74 PUZZLE-IN003B Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ...
- Page 75 PUZZLE-IN003B Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 1999/5/CE. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES.
- Page 76 PUZZLE-IN003B FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
-
Page 77: B Safety Precautions
PUZZLE-IN003B Appendix Safety Precautions Page 67... -
Page 78: Safety Precautions
Drop the system against a hard surface. In a site where the ambient temperature exceeds the rated temperature B.1.2 Anti-static Precautions WARNING: Failure to take ESD precautions during the installation of the PUZZLE-IN003B result permanent damage PUZZLE-IN003B and severe injury to the user. Page 68... -
Page 79: Product Disposal
Electrostatic discharge (ESD) can cause serious damage to electronic components, including the PUZZLE-IN003B. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the PUZZLE-IN003B is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to. -
Page 80: Maintenance And Cleaning Precautions
Some components in the PUZZLE-IN003B may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the PUZZLE-IN003B. ... - Page 81 PUZZLE-IN003B Vacuum cleaner – Using a vacuum specifically designed for computers is one of the best methods of cleaning the PUZZLE-IN003B. Dust and dirt can restrict the airflow in the PUZZLE-IN003B and cause its circuitry to corrode. Swabs - Swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas.
-
Page 82: C Error Beep Code
PUZZLE-IN003B Appendix Error Beep Code Page 72... -
Page 83: Pei Beep Codes
PUZZLE-IN003B C.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed S3 Resume failed Reset PPI is not available C.2 DXE Beep Codes... -
Page 84: D Hazardous Materials Disclosure
PUZZLE-IN003B Appendix Hazardous Materials Disclosure Page 74... -
Page 85: Rohs Ii Directive (2015/863/Eu)
PUZZLE-IN003B D.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU). -
Page 86: China Rohs
PUZZLE-IN003B D.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 76...
