Summary of Contents for Jeep GRAND CHEROKEE WK 2022

Page 1 2 02 2 GRAND CH E RO KEE WK OWNE R’ S M ANUAL...
Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle.
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..........................8 GETTING TO KNOW YOUR VEHICLE ................. 14 GETTING TO KNOW YOUR INSTRUMENT PANEL ............71 STARTING AND OPERATING ....................89 MULTIMEDIA ..........................151 SAFETY ............................182 IN CASE OF EMERGENCY ..................... 231 SERVICING AND MAINTENANCE ..................250 TECHNICAL SPECIFICATIONS ....................305 CUSTOMER ASSISTANCE .......................
Page 4 INTRODUCTION UCONNECT VOICE RECOGNITION ....... 36 DOORS..............22 Manual Door Locks ..........22 Introducing Voice Recognition ......36 SYMBOLS KEY............9 Power Door Locks ...........22 Basic Voice Commands ........37 ROLLOVER WARNING ..........9 Keyless Enter ‘n Go™ — Passive Entry....23 Get Started ............37 VEHICLE MODIFICATIONS/ALTERATIONS..10 Additional Information ........37 Automatic Unlock Doors On Exit......25 SYMBOL GLOSSARY..........
Page 5 ROOF LUGGAGE RACK — IF EQUIPPED ..... 69 EXTERIOR LIGHTS..........44 INTERIOR STORAGE AND EQUIPMENT ....56 Headlight Switch ..........44 Storage..............56 GETTING TO KNOW YOUR Multifunction Lever .........45 Lighted Cupholders — If Equipped ....57 INSTRUMENT PANEL Daytime Running Lights (DRLs).......45 USB/AUX Control — If Equipped ......57 High/Low Beam Switch........45 Power Outlets ...........58 INSTRUMENT CLUSTER —...
Page 6 STARTING AND OPERATING STOP/START SYSTEM — IF EQUIPPED .....107 FOUR-WHEEL DRIVE OPERATION ..... 100 Quadra-Trac I Operating Instructions/ Autostop Mode ..........107 STARTING THE ENGINE......... 89 Precautions —If Equipped......100 Possible Reasons The Engine Does Not Automatic Transmission ........89 Quadra-Trac II Operating Instructions/ Autostop............
Page 7 PARKSENSE ACTIVE PARK ASSIST SYSTEM — RECREATIONAL TOWING REAR SEAT ENTERTAINMENT (RSE) SYSTEM — IF IF EQUIPPED............125 (BEHIND MOTORHOME) ........142 EQUIPPED .............169 Enabling And Disabling The ParkSense Active Towing This Vehicle Behind Getting Started ..........169 Park Assist System........125 Another Vehicle ..........
Page 8 SAFETY IN CASE OF EMERGENCY SERVICING AND MAINTENANCE SAFETY FEATURES ..........182 HAZARD WARNING FLASHERS ......231 SCHEDULED SERVICING ........250 Anti-Lock Brake System (ABS) ..... 182 ASSIST AND SOS MIRROR — IF EQUIPPED ..231 Maintenance Plan......... 251 Electronic Brake Control (EBC) System ..183 ENGINE COMPARTMENT ........254 JACKING AND TIRE CHANGING ......
Page 9 TECHNICAL SPECIFICATIONS CUSTOMER ASSISTANCE TIRES ..............283 Tire Safety Information ........ 283 VEHICLE IDENTIFICATION NUMBER (VIN) ..305 SUGGESTIONS FOR OBTAINING SERVICE FOR Tires — General Information ......291 BRAKE SYSTEM........... 305 YOUR VEHICLE ............311 Tire Types............295 WHEEL AND TIRE TORQUE SPECIFICATIONS.. 305 Prepare For The Appointment ......
Page 10: Introduction
For further information, contact an authorized dealer. When it comes to service, remember that authorized dealers know your Jeep® vehicle best, have factory-trained technicians, genuine Mopar® parts, and care about your satisfaction.
Page 11: Symbols Key
SYMBOLS KEY ROLLOVER WARNING Utility vehicles have a significantly higher rollover rate than other types of These statements are against operating vehicles. This vehicle has a higher ground clearance and a higher center of WARNING! procedures that could result in a collision, bodily injury and/or death.
Page 12: Vehicle Modifications/Alterations
VEHICLE MODIFICATIONS/ALTERATIONS Red Warning Lights WARNING! Battery Charge Warning Light Ú page 80 Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death. Door Open Warning Light Ú...
Page 13 Red Warning Lights Yellow Warning Lights Oil Temperature Warning Light Electronic Stability Control (ESC) OFF Warning Light Ú page 81 Ú page 82 Seat Belt Reminder Warning Light Service LaneSense Warning Light Ú page 81 Ú page 82 Transmission Temperature Warning Light LaneSense Warning Light Ú...
Page 14 Yellow Warning Lights Yellow Indicator Lights Service Stop/Start System Warning Light Forward Collision Warning (FCW) Off Indicator Light Ú page 83 Ú page 85 Tire Pressure Monitoring System (TPMS) Warning Light 4WD Low Indicator Light Ú page 83 Ú page 85 NEUTRAL Indicator Light Yellow Indicator Lights Ú...
Page 15 Green Indicator Lights White Indicator Lights LaneSense Indicator Light Hill Descent Control (HDC) Indicator Light Ú page 85 Ú page 86 Parking/Headlights On Indicator Light LaneSense Indicator Light Ú page 85 Ú page 86 Sport Mode Indicator Light Selec-Speed Control Indicator Light Ú...
Page 16: Getting To Know Your Vehicle
GETTING TO KNOW YOUR VEHICLE KEYS In case the ignition switch does not change with the push of a button, the key fob may have a low or fully depleted battery. A low key fob battery can be verified by referring to the instrument cluster, Your vehicle is equipped with a key fob which which will display directions to follow Ú...
Page 17 GETTING TO KNOW YOUR VEHICLE All doors can be programmed to unlock on the first NOTE: 2. Separate the key fob halves using a #2 flat push of the unlock button through Uconnect blade screwdriver or a coin, and gently pry the Customers are recommended to use a battery ...
Page 18: Sentry Key
GETTING TO KNOW YOUR VEHICLE SENTRY KEY Programming And Requesting Additional 3. Remove the back cover to access and replace the battery. When replacing the battery, match Key Fobs The Sentry Key Immobilizer system prevents the (+) sign on the battery to the (+) sign on the Programming the key fob may be performed by an unauthorized vehicle operation by disabling the inside of the battery clip, located on the back...
Page 19: Ignition Switch
GETTING TO KNOW YOUR VEHICLE ON/RUN CAUTION! Driving position  The Sentry Key Immobilizer system is not All electrical devices are available (e.g. climate  compatible with some aftermarket remote controls, etc.) starting systems. Use of these systems may START result in vehicle starting problems and loss of security protection.
Page 20: Remote Start - If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! WARNING! When opening the driver's door with the ignition  When exiting the vehicle, always remove the Do not start or run an engine in a closed  in ON/RUN (engine not running), a chime will ...
Page 21: To Exit Remote Start Mode
GETTING TO KNOW YOUR VEHICLE NOTE: Battery at an acceptable charge level EMOTE TART  With Remote Start, the engine will only run for Panic button not pushed   To drive the vehicle after starting the Remote Start 15 minutes. System not disabled from previous Remote ...
Page 22: Remote Start Front Defrost Activation
GETTING TO KNOW YOUR VEHICLE Automatic Temperature Control (ATC) — matic override. This includes the OFF button on the EMOTE TART RONT EFROST If Equipped climate controls, which will turn the system off. — I CTIVATION QUIPPED The climate controls will be automatically adjusted EMOTE TART INDSHIELD...
Page 23: Vehicle Security System - If Equipped
GETTING TO KNOW YOUR VEHICLE VEHICLE SECURITY SYSTEM — IF EQUIPPED Push the lock button on the exterior Passive remain locked unless all doors are set to unlock  Entry door handle with a valid key fob avail- on first press within Uconnect Settings. The Vehicle Security system monitors the vehicle able in the same exterior zone Ú...
Page 24: Security System Manual Override
GETTING TO KNOW YOUR VEHICLE ECURITY YSTEM ANUAL VERRIDE OWER OCKS WARNING! The Vehicle Security system will not arm if you lock The power door lock switches are located on each For personal security and safety in the event  the doors using the manual door lock.
Page 25: Keyless Enter 'N Go™ - Passive Entry
GETTING TO KNOW YOUR VEHICLE If the door lock switch is pushed while the ignition If wearing gloves, or if it has been raining/ NOTE:  is in ACC or ON/RUN and the driver's door is open, snowing on the Passive Entry door handle, the Either the driver’s door only or all doors will ...
Page 26 GETTING TO KNOW YOUR VEHICLE NOTE: When any of these situations occur, after all open doors are shut, the FOBIK-Safe search will be After pushing the door handle button, you must  executed. If it detects a Passive Entry key fob wait two seconds before you can lock or unlock inside the car, the car will unlock and alert the the doors, using either Passive Entry door...
Page 27: Automatic Unlock Doors On Exit
GETTING TO KNOW YOUR VEHICLE The liftgate (and vehicle doors if unlocked) must To use the system, open each rear door, use a flat UTOMATIC NLOCK OORS  be locked using the lock button on the key fob, blade screwdriver (or emergency key) and rotate The doors will unlock automatically on vehicles the Passive Entry lock button, or the lock the dial to the lock or unlock position.
Page 28: Steering Wheel
GETTING TO KNOW YOUR VEHICLE STEERING WHEEL After engaging the Child-Protection Door Lock  WARNING! system, always test the door from the inside to make certain it is in the locked position. Do not adjust the steering column while driving. ANUAL ELESCOPING TEERING...
Page 29: If Equipped
GETTING TO KNOW YOUR VEHICLE DRIVER MEMORY SETTINGS — IF EQUIPPED Use the four-way control to adjust the steering The heated steering wheel control button is column. located within the climate or controls screen of the This feature allows the driver to save up to two touchscreen.
Page 30: Programming The Memory Feature
GETTING TO KNOW YOUR VEHICLE 3. Push and release the set (S) button on the 4. Within five seconds, push and release button memory switch, and then push the desired (1) or (2) accordingly. “Memory Profile Set” memory button (1 or 2) within five seconds. (1 or 2) will display in the instrument cluster.
Page 31: Seats
GETTING TO KNOW YOUR VEHICLE SEATS ) — ANUAL DJUSTMENT RONT EATS QUIPPED Seats are a part of the Occupant Restraint system of the vehicle. WARNING! WARNING! Adjusting a seat while the vehicle is moving is  It is dangerous to ride in a cargo area, inside dangerous.
Page 32: Manual Adjustment (Front Seats)
GETTING TO KNOW YOUR VEHICLE Manual Front Passenger Seatback Front Passenger Seat Fold-Flat Feature — WARNING! Adjustment — Recline If Equipped Do not ride with the seatback reclined so that  To adjust the seatback, lift the lever located on the To fold the seatback to the flat load-floor position, the seat belt is no longer resting against your outboard side of the seat, lean back to the desired...
Page 33 GETTING TO KNOW YOUR VEHICLE Reclining Rear Seat To Lower Rear Seat NOTE: Do not fold the 60% rear seat down with the To recline the seatback, lift the lever located on the Either side of the rear seat can be lowered to allow ...
Page 34: Power Adjustment (Front Seats)
GETTING TO KNOW YOUR VEHICLE To Raise Rear Seat Tilting The Seat Up Or Down Raise the rear seatback and lock it into place. If The angle of the seat cushion can be adjusted up interference from the cargo area prevents the or down using the power seat switch.
Page 35: Heated Seats - If Equipped
GETTING TO KNOW YOUR VEHICLE — I Easy Entry/Exit Seat — If Equipped EATED EATS QUIPPED CAUTION! This feature provides automatic driver seat Do not place any article under a power seat or WARNING! positioning to enhance driver mobility when impede its ability to move as it may cause entering and exiting the vehicle.
Page 36: Head Restraints
GETTING TO KNOW YOUR VEHICLE You can choose from HI, LO, or OFF heat settings. To raise the head restraint, pull upward on the WARNING! The indicator arrows in the touchscreen buttons head restraint. To lower the head restraint, push indicate the level of heat in use.
Page 37 GETTING TO KNOW YOUR VEHICLE In the event of deployment of an Active Head Adjustment — Rear Seats  Restraint, see Ú page 200. The head restraints on the outboard seats are not adjustable. They automatically fold forward when WARNING! the rear seat is folded to a load floor position, but ALL the head restraints MUST be reinstalled in do not return to their normal position when the rear...
Page 38: Uconnect Voice Recognition
GETTING TO KNOW YOUR VEHICLE UCONNECT VOICE RECOGNITION Head Restraint Removal — Rear Seats The center head restraint can be adjusted when NTRODUCING OICE ECOGNITION occupied, or removed for Child Seat Tethering. To remove the head restraint, raise it as far as it can Start using Uconnect Voice Recognition with these go by pulling upward.
Page 39: Basic Voice Commands
GETTING TO KNOW YOUR VEHICLE You can interrupt the help message or system Uconnect System Support: ASIC OICE OMMANDS  prompts by pushing the VR button and saying a www.DriveUconnect.com US residents visit  The following basic Voice Commands can be given Voice Command from the current category.
Page 40: Illuminated Vanity Mirrors
GETTING TO KNOW YOUR VEHICLE NOTE: You can turn the Automatic Dimming Mirror LLUMINATED ANITY IRRORS feature on or off by pushing the button at the base The sun visor can also be extended while the sun To access an illuminated vanity mirror, flip down of the mirror.
Page 41: Outside Automatic Dimming Mirror
GETTING TO KNOW YOUR VEHICLE Outside Mirrors Folding Feature If the mirror is manually folded after a powered cycle, a potential extra button push is required to All outside mirrors are hinged and may be moved get the mirrors back to the normal driving position. either forward or rearward to resist damage.
Page 42: Heated Mirrors - If Equipped
GETTING TO KNOW YOUR VEHICLE UNIVERSAL GARAGE DOOR OPENER To reset the power folding mirrors: Fold and unfold To operate HomeLink®, push and release any  them by pushing the button (this may require of the programmed HomeLink® buttons. These (HOMELINK®) multiple attempts).
Page 43: Erasing All The Home Link Channels
GETTING TO KNOW YOUR VEHICLE ® antenna is attached to the device. The button may 3. Push and hold the HomeLink® button you RASING not be immediately visible when looking at the want to program while you push and hold the HANNELS device.
Page 44: Programming Homelink® To A Miscellaneous Device
GETTING TO KNOW YOUR VEHICLE ® T 3. Push the programmed HomeLink® button to 2. Push and hold the desired HomeLink® button ROGRAMMING confirm that the garage door opener motor until the HomeLink® Indicator light begins to ISCELLANEOUS EVICE operates. If the garage door opener motor flash after 20 seconds.
Page 45: Security
GETTING TO KNOW YOUR VEHICLE 3. Continue to press and hold the HomeLink® Reprogramming A Single HomeLink® Button Push the LEARN button on the garage door  button, while you press and release (cycle) (Canadian/Gate Operator) opener to complete the training for a rolling your hand-held transmitter every two seconds code.
Page 46: Exterior Lights
GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS NOTE: For vehicles sold in Canada, rotate the headlight switch clockwise from the AUTO position to the first EADLIGHT WITCH detent to turn on parking lights and instrument The headlight switch is located on the left side of panel lights.
Page 47: Multifunction Lever
GETTING TO KNOW YOUR VEHICLE Where allowed by law, the DRLs function may be Broken, muddy, or obstructed headlights and ULTIFUNCTION EVER   disabled through the Uconnect system taillights of vehicles in the field of view will The multifunction lever is located on the left side of Ú...
Page 48: Automatic Headlights - If Equipped
GETTING TO KNOW YOUR VEHICLE — I canceled by either turning the headlight switch on UTOMATIC EADLIGHTS QUIPPED UTOMATIC EADLIGHTS IPERS then off, or by placing the ignition in the ON This system automatically turns the headlights on If your vehicle is equipped with Automatic position.
Page 49: Turn Signals
GETTING TO KNOW YOUR VEHICLE switch is pushed a second time, when the NOTE: headlight switch is rotated to the off position, or Battery saver mode is canceled if the ignition is ON. the high beam is selected. If the headlights remain on while the ignition is placed in the OFF position, the exterior lights will IGNALS automatically turn off after eight minutes.
Page 50: Interior Courtesy Lights
GETTING TO KNOW YOUR VEHICLE Ambient Light — If Equipped NTERIOR OURTESY IGHTS The overhead console is equipped with an ambient The courtesy lights can be turned on by pushing light feature. This light illuminates for improved the top corner of the lens. To turn the lights off, visibility of the floor and center console area.
Page 51: Windshield Wipers And Washers
GETTING TO KNOW YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS INDSHIELD IPER PERATION Rotate the end of the lever to one of the first four The windshield wiper/washer controls are located detent positions for intermittent settings, the fifth on the windshield wiper/washer lever located on detent for low wiper operation and the sixth detent the left side of the steering column.
Page 52: Rain Sensing Wipers - If Equipped
GETTING TO KNOW YOUR VEHICLE NOTE: Windshield Washers Use of products containing wax or silicone may  reduce Rain Sensing performance. The Mist feature does not activate the washer To use the washer, push on the end of the lever pump;...
Page 53: Rear Window Wiper/Washer
GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS A/C is on. Pressing the button again will cause the INDOW IPER ASHER MAX A/C operation to exit. Pressing other settings The rear wiper/washer controls are located on the The Climate Control system allows you to regulate will cause the MAX A/C to exit.
Page 54 GETTING TO KNOW YOUR VEHICLE Recirculation feature may be unavailable if If your air conditioning performance seems mode button, the Climate Control system will  lower than expected, check the front of the A/C conditions exist that could create fogging on the return to the previous setting.
Page 55 GETTING TO KNOW YOUR VEHICLE Driver And Passenger Up And Down Blower Control Panel Mode Buttons Blower Control is used to regulate the Air comes from the outlets in the amount of air forced through the Climate instrument panel. Each of these outlets These buttons provide the driver and passenger Control system.
Page 56: Automatic Temperature Control (Atc)
GETTING TO KNOW YOUR VEHICLE Mix Mode 3. When the system is set up for your comfort LIMATE OICE OMMANDS level, it is not necessary to change the Air is directed through the floor, defrost, Adjust vehicle temperatures hands-free and keep settings.
Page 57 GETTING TO KNOW YOUR VEHICLE Winter Operation Cabin Air Filter WEATHER CONTROL SETTINGS To ensure the best possible heater and defroster The climate control system filters out dust and Turn (A/C) on and performance, make sure the engine cooling pollen from the air. Contact an authorized dealer to Warm Weather set the mode control to system is functioning properly and the proper...
Page 58: Interior Storage And Equipment
GETTING TO KNOW YOUR VEHICLE INTERIOR STORAGE AND EQUIPMENT Door Storage Large storage areas are built into the door panels TORAGE for easy access. Console Features Glove Compartment The center console contains both an upper and a The glove compartment is located on the lower storage area.
Page 59: Lighted Cupholders - If Equipped
GETTING TO KNOW YOUR VEHICLE USB/AUX C — I ONTROL QUIPPED Connecting The External USB/AUX Device Use the connection cable to connect an external USB device to the vehicle’s USB/AUX connector port which is located in the center console. The USB ports on the media hub are equipped with a Smart Electronic Voltage Regulator (Smart Charge) feature.
Page 60: Power Outlets
GETTING TO KNOW YOUR VEHICLE NOTE: Once the audio device is connected and OWER UTLETS synchronized to the vehicle’s USB control system For further information, refer to the Uconnect Your vehicle is equipped with 12 Volt (15 Amp) (an external USB device may take a few minutes to Owner’s Manual Supplement.
Page 61 GETTING TO KNOW YOUR VEHICLE Push inward on the storage lid to open the The rear power outlet is located in the right rear compartment and gain access to this power outlet. cargo area. Power Outlet Fuse Locations 1 — F104 Fuse 20 Amp Yellow Power Outlet Console Bin Front Power Outlet Rear Cargo Power Outlet...
Page 62: Power Inverter - If Equipped
GETTING TO KNOW YOUR VEHICLE WINDOWS CAUTION! Many accessories that can be plugged in draw  OWER INDOW ONTROLS power from the vehicle's battery, even when not The window controls on the driver's door control all in use (i.e., cellular phones, etc.). Eventually, if the door windows.
Page 63: Automatic Window Features
GETTING TO KNOW YOUR VEHICLE NOTE: Auto-Up Feature With Anti-Pinch Protection 1. Pull the window switch up to close the window The power window switches will remain active for completely and continue to hold the switch up Lift the window switch up briefly and release; the for an additional two seconds after the up to 10 minutes after the ignition is placed in the window will go up automatically.
Page 64: Wind Buffeting
GETTING TO KNOW YOUR VEHICLE Push the switch forward and release it within UFFETING WARNING! one-half second and the sunroof will close Wind buffeting can be described as the perception automatically from any position. The sunroof will Never leave children unattended in a vehicle, ...
Page 65: Pinch Protect Feature
GETTING TO KNOW YOUR VEHICLE COMMANDVIEW SUNROOF WITH POWER INCH ROTECT EATURE WARNING! SHADE — IF EQUIPPED This feature will detect an obstruction in the Never leave children unattended in a vehicle,  closing of the sunroof during the Express Close or with access to an unlocked vehicle.
Page 66: Opening And Closing The Sunroof
GETTING TO KNOW YOUR VEHICLE NOTE: If the sunroof is open or vented, the sunshade PENING LOSING UNROOF cannot be closed beyond the half open position. If the sunshade is in the closed position when The sunroof has two programmed automatic stops Pushing the sunshade close switch when the Express or Manual Open operation is initiated the for the sunroof open position: a comfort stop...
Page 67: Pinch Protect Feature
GETTING TO KNOW YOUR VEHICLE Releasing the switch while the sunshade is in LOSE motion will stop the sunshade in a partially open In one continuous motion, pull down on the front position. edge ofthe hood with moderate force until the INCH ROTECT EATURE...
Page 68: To Lock/Close The Liftgate
GETTING TO KNOW YOUR VEHICLE NOTE: liftgate button on the key fob twice within five WARNING! seconds to open or close the power liftgate. When you push the button on the liftgate, either only the liftgate will unlock or all doors and the Driving with the liftgate open can allow NOTE: liftgate will unlock, depending on the selected...
Page 69: Cargo Area Features
GETTING TO KNOW YOUR VEHICLE NOTE: There are pinch sensors attached to the side of ARGO EATURES  the liftgate. Light pressure anywhere along In the event of a power malfunction to the lift-  Cargo Storage Bins — If Equipped these strips will cause the liftgate to return to gate, an emergency liftgate latch release can be the open position.
Page 70 GETTING TO KNOW YOUR VEHICLE Retractable Cargo Area Cover — Two additional storage bins may be located under WARNING! the load floor. To access the lower storage bins, If Equipped raise the load floor and if equipped, attach the In a collision, a loose cargo cover in the vehicle The purpose of this cover is for privacy, not to tether strap (attached to the bottom of the load could cause injury.
Page 71: Roof Luggage Rack - If Equipped
GETTING TO KNOW YOUR VEHICLE ROOF LUGGAGE RACK — IF EQUIPPED WARNING! WARNING! The crossbars and siderails are designed to carry To help protect against personal injury, The weight and position of cargo and  loads on vehicles equipped with a luggage rack. passengers should not be seated in the rear passengers can change the vehicle center of The load must not exceed 150 lb (68 kg), and...
Page 72 GETTING TO KNOW YOUR VEHICLE NOTE: CAUTION! CAUTION! To help control wind noise when the crossbars  To prevent damage to the roof of your vehicle, Place a blanket or other protection between are not in use, place the front and rear cross- ...
Page 73: Getting To Know Your Instrument Panel
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — GASOLINE...
Page 74: Instrument Cluster Descriptions
GETTING TO KNOW YOUR INSTRUMENT PANEL 4. Instrument Cluster Display NSTRUMENT LUSTER ESCRIPTIONS WARNING! The instrument cluster display features a  1. Tachometer A hot engine cooling system is dangerous. You or driver interactive display Ú page 73. Indicates the engine speed in revolutions others could be badly burned by steam or boiling ...
Page 75: Instrument Cluster Display
GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY The system allows the driver to select information by pushing the following buttons mounted on the Your vehicle is equipped with an instrument cluster steering wheel: display, which offers useful information to the driver.
Page 76: Oil Change Reset - If Equipped
GETTING TO KNOW YOUR INSTRUMENT PANEL Left And Right Arrow Buttons: Unless reset, this message will continue to display NSTRUMENT LUSTER ISPLAY each time you place the ignition in the ON/RUN TEMS Using the left or right arrow button allows position.
Page 77 GETTING TO KNOW YOUR INSTRUMENT PANEL Driver Assist — If Equipped ACC SET Tire Pressure Oil Pressure   When ACC is set, the set speed will display in the Transmission Oil Life Push and release the up or down arrow ...
Page 78 GETTING TO KNOW YOUR INSTRUMENT PANEL Fuel Economy Trip Info Audio Push and release the up or down arrow Push and release the up or down arrow Push and release the up or down arrow button until the Fuel Economy icon is highlighted in button until the Trip menu title is displayed in the button until the Audio menu title is displayed in the the instrument cluster display.
Page 79: (If Equipped)
GETTING TO KNOW YOUR INSTRUMENT PANEL Screen Setup Driver Selectable Items Gear Display Load reduction is only active when the engine is running. It will display a message if there is a risk Full  Upper Left of battery depletion to the point where the vehicle Single ...
Page 80: Trip Computer
GETTING TO KNOW YOUR INSTRUMENT PANEL TRIP COMPUTER Loss of the battery charge may indicate one or What to do when an electrical load reduction more of the following conditions: action message is present (“Battery Saver On” or “Battery Saver Mode”) Push and release the up or down arrow...
Page 81: Warning Lights And Messages
GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES Brake Warning Light NOTE: The light may flash momentarily during sharp This warning light monitors various brake The warning/indicator lights will illuminate in the cornering maneuvers, which change fluid level functions, including brake fluid level and instrument panel together with a dedicated conditions.
Page 82 GETTING TO KNOW YOUR INSTRUMENT PANEL Electric Power Steering (EPS) Fault NOTE: The light also will turn on when the parking brake is applied with the ignition switch in the ON/RUN This light may turn on if the accelerator and brake Warning Light position.
Page 83 GETTING TO KNOW YOUR INSTRUMENT PANEL Hood Open Warning Light Oil Temperature Warning Light WARNING! This indicator will illuminate when the This warning light will illuminate to If you continue operating the vehicle when the hood is ajar/open and not fully closed. indicate the engine oil temperature is Transmission Temperature Warning Light is high.
Page 84: Yellow Warning Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Electronic Stability Control (ESC) Active Electronic Stability Control (ESC) OFF ELLOW ARNING IGHTS Warning Light — If Equipped Warning Light — If Equipped Service Adaptive Cruise Control (ACC) This warning light will indicate when the This warning light indicates the ESC is off.
Page 85 GETTING TO KNOW YOUR INSTRUMENT PANEL Low Washer Fluid Warning Light — Service Forward Collision Warning (FCW) WARNING! If Equipped Light — If Equipped A malfunctioning catalytic converter, as This warning light will illuminate and a This warning light will illuminate to referenced above, can reach higher single chime will sound when the indicate a fault in the Forward Collision...
Page 86: Yellow Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Please note that the TPMS is not a substitute for CAUTION! CAUTION! proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, Do not continue driving with one or more flat The TPMS has been optimized for the original even if underinflation has not reached the level to tires as handling may be compromised.
Page 87: Green Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Air Suspension Entry/Exit Indicator Light — Forward Collision Warning (FCW) Off Adaptive Cruise Control (ACC) Set With If Equipped Indicator Light — If Equipped Target Light — If Equipped This light will illuminate when the vehicle This indicator light illuminates to indicate This will display when the ACC is set and is automatically lowered from ride height...
Page 88: White Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL Sport Mode Indicator Light LaneSense Indicator Light — If Equipped HITE NDICATOR IGHTS This light will turn on when Sport Mode is When the LaneSense system is ON, but Adaptive Cruise Control (ACC) Ready Light — active Ú...
Page 89: Blue Indicator Lights
GETTING TO KNOW YOUR INSTRUMENT PANEL If any of these systems require service, the OBD II NDICATOR IGHTS NBOARD IAGNOSTIC YSTEM system will turn on the Malfunction Indicator Light (OBD II) C YBERSECURITY High Beam Indicator Light (MIL). It will also store diagnostic codes and other information to assist your service technician in Your vehicle is required to have OBD II and a This indicator light will illuminate to...
Page 90: Emissions Inspection And Maintenance
GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND Your vehicle has a simple ignition actuated test, The MIL will not flash at all and will remain fully  which you can use prior to going to the test station. illuminated until you place the ignition in the off MAINTENANCE PROGRAMS To check if your vehicle's OBD II system is ready,...
Page 91: Starting And Operating
STARTING AND OPERATING STARTING THE ENGINE WARNING! CAUTION! Before starting your vehicle, adjust your seat, Do not leave the key fob in or near the vehicle, Shift into or out of PARK or REVERSE only after   adjust the inside and outside mirrors, fasten your or in a location accessible to children, and do the vehicle has come to a complete stop and seat belt, and if present, instruct all other...
Page 92: Autopark
STARTING AND OPERATING To Turn Off The Engine Using The ENGINE START/ ACC or ON/RUN (engine not running) position and STOP Button the transmission is in PARK. AutoPark is a supplemental feature to assist with ENGINE START/STOP Button Functions — With 1.
Page 93: Extended Park Starting
STARTING AND OPERATING If the vehicle is not in PARK and the driver turns off The message “AutoPark Engaged Shift to P then 4WD LOW — If Equipped the engine, the vehicle may AutoPark. Shift to Gear” will display in the instrument cluster. AutoPark will be disabled when operating the NOTE: vehicle in 4WD LOW.
Page 94: If Engine Fails To Start
STARTING AND OPERATING 3. If the engine fails to start within 10 seconds, EATHER PERATION WARNING! place the ignition in the OFF position, wait 10 –22°F O −30°C) ELOW to 15 seconds to allow the starter to cool, then Never pour fuel or other flammable liquid into ...
Page 95: Engine Break-In Recommendations
STARTING AND OPERATING ENGINE BREAK-IN RECOMMENDATIONS and not interpreted as a problem. Please check NOTE: your oil level with the engine oil indicator often When the parking brake is applied and the  A long break-in period is not required for the during the break-in period.
Page 96: Automatic Transmission
STARTING AND OPERATING WARNING! CAUTION! WARNING! If the Brake Warning Light remains on with the Never leave children alone in a vehicle, or with The transmission may not engage PARK if the   parking brake released, a brake system vehicle is moving.
Page 97: Ignition Park Interlock
STARTING AND OPERATING RAKE RANSMISSION HIFT WARNING! CAUTION! (BTSI) S NTERLOCK YSTEM When exiting the vehicle, always make sure Do not shift between PARK, REVERSE,   the ignition is in the OFF position, remove the NEUTRAL, or DRIVE when the engine is above This vehicle is equipped with a BTSI system that key fob from the vehicle, and lock the vehicle.
Page 98: 8-Speed Automatic Transmission
STARTING AND OPERATING When the Fuel Economy (ECO) Mode is engaged, of PARK (P), the engine must be running and the (S) (AutoStick) shift positions. Manual shifts can be the vehicle control systems will change the brake pedal must be pressed. You must also press made using the AutoStick shift control.
Page 99 STARTING AND OPERATING Gear Ranges NEUTRAL (N) CAUTION! Use this range when the vehicle is standing for Do not press the accelerator pedal when shifting Before moving the transmission gear selector  prolonged periods with the engine running. Apply out of PARK or NEUTRAL. out of PARK, you must start the engine, and the parking brake and shift the transmission into NOTE:...
Page 100 STARTING AND OPERATING Transmission Limp Home Mode When frequent transmission shifting occurs (such 3. Push and hold the ignition switch until the as when operating the vehicle under heavy loading engine turns off. Transmission function is monitored electronically conditions, in hilly terrain, traveling into strong 4.
Page 101 STARTING AND OPERATING AutoStick mode has the following operational Transmission shifting will be more noticeable  benefits: when AutoStick is enabled. The transmission will automatically downshift The system may revert to automatic shift mode   as the vehicle slows (to prevent engine lugging) if a fault or overheat condition is detected.
Page 102: Sport Mode - If Equipped
STARTING AND OPERATING SPORT MODE — IF EQUIPPED FOUR-WHEEL DRIVE OPERATION II O UADRA PERATING — NSTRUCTIONS RECAUTIONS UADRA PERATING QUIPPED — NSTRUCTIONS RECAUTIONS The Quadra-Trac II transfer case is fully automatic QUIPPED in the normal driving 4WD AUTO mode. The Quadra-Trac II transfer case provides three The Quadra-Trac I is a single-speed (HI range only) positions:...
Page 103: Shift Positions
STARTING AND OPERATING Proper operation of four-wheel drive vehicles 4WD LOW HIFT OSITIONS depends on tires of equal size, type, and This range is for low speed four-wheel drive. It For additional information on the appropriate use circumference on each wheel. Any difference will provides an additional gear reduction which allows of each 4WD system mode position, see the adversely affect shifting and cause damage to the...
Page 104: Quadra-Drive Ii System - If Equipped
STARTING AND OPERATING NOTE: Shifting into or out of 4WD LOW is possible with will automatically transfer from the wheel that has  the vehicle completely stopped; however, diffi- less traction, to the wheel that has traction. While If shift conditions/interlocks are not met, or a culty may occur due to the mating clutch teeth the transfer case and axle coupling differ in design, transfer case motor temperature protection...
Page 105 STARTING AND OPERATING Off-Road 1 (OR1) (Raises the vehicle approxi- NRH from Aero Height if the vehicle speed  mately 1.1 inches [28 mm]) – This is the remains between 20 mph (32 km/h) and primary position for all off-road driving until OR2 25 mph (40 km/h) for greater than 20 seconds is needed.
Page 106: Air Suspension Modes
STARTING AND OPERATING To assist with changing a spare tire, the AUTO and the vehicle level is either in Normal or Auto Entry/Exit Mode Aero. The vehicle will not automatically lower if the Quadra-Lift air suspension system has a feature To assist in entering and exiting the vehicle, the air air suspension level is in OR2 or OR1.
Page 107: Instrument Cluster Display Messages
STARTING AND OPERATING Wheel Alignment Mode Pushing the UP button once will move the Automatic height changes will occur based on vehicle speed and the current vehicle height. The suspension one position higher from the current Before performing a wheel alignment this mode position, assuming all conditions are met (i.e.
Page 108: Selec-Terrain - If Equipped
STARTING AND OPERATING SELEC-TERRAIN — IF EQUIPPED AUTO – Fully automatic full-time four-wheel such as large rocks, deep ruts, etc. If equipped  drive operation can be used on and off-road. with air suspension, the vehicle level will change Balances traction with seamless steering feel to to Off-Road 2.
Page 109: Stop/Start System - If Equipped
STARTING AND OPERATING STOP/START SYSTEM — IF EQUIPPED If the Electric Power Steering warning The engine will shut down, the tachometer will icon is displayed and the “SERVICE move to the zero position and the Stop/Start The Stop/Start function is developed to reduce POWER STEERING”...
Page 110: To Start The Engine While In Autostop Mode
STARTING AND OPERATING HVAC is set to MAX A/C.  TART NGINE HILE ANUALLY Engine has not reached normal operating  UTOSTOP TART YSTEM temperature. While in a forward gear, the engine will start when The transmission is not in a forward gear. ...
Page 111: System Malfunction
STARTING AND OPERATING Only one Cruise Control feature can operate at a YSTEM ALFUNCTION  WARNING! time. For example, if Fixed Speed Cruise Control If there is a malfunction in the Stop/Start system, is enabled, Adaptive Cruise Control will be Cruise Control can be dangerous where the the system will not shut down the engine.
Page 112 STARTING AND OPERATING To Set A Desired Speed Metric Speed (km/h) WARNING! Pushing the SET (+), or SET (-) button once will Turn the Cruise Control on. When the vehicle has  Cruise Control can be dangerous where the result in a 1 km/h speed adjustment. Each reached the desired speed, push and release the system cannot maintain a constant speed.
Page 113: Adaptive Cruise Control (Acc)
STARTING AND OPERATING (ACC) DAPTIVE RUISE ONTROL WARNING! WARNING! Adaptive Cruise Control (ACC) increases the driving Adaptive Cruise Control (ACC) is a conve- Will bring the vehicle to a complete stop   convenience provided by Cruise Control while nience system. It is not a substitute for active while following a target vehicle and hold traveling on highways and major roadways.
Page 114 STARTING AND OPERATING Adaptive Cruise Control (ACC) Operation Adaptive Cruise Control (ACC) Menu The instrument cluster display will return to the last display selected after five seconds of no ACC The Cruise Control buttons (located on the right The instrument cluster display shows the current display activity.
Page 115 STARTING AND OPERATING To Activate/Deactivate Pushing the Fixed Speed Cruise Control on/off If you continue to accelerate beyond the set  button will result in turning on (changing to) Fixed speed while ACC is enabled, the system will not Push and release the Adaptive Cruise Control Speed Cruise Control mode.
Page 116 STARTING AND OPERATING To Turn Off Metric Speed (km/h) WARNING! Pushing the SET (+), or SET (-) button once will The system will turn off and erase the set speed in  The Resume function should only be used if result in a 1 km/h speed adjustment.
Page 117 STARTING AND OPERATING uphill or descending downhill. This is normal To increase the distance setting, push the NOTE: operation and necessary to maintain set speed. Distance Increase button and release. Each time The brake lights will illuminate whenever the ACC When driving uphill and downhill, the ACC the button is pushed, the distance setting system applies the brakes.
Page 118 STARTING AND OPERATING ACC Operation At Stop Display Warnings And Maintenance If weather conditions are not a factor, the driver should examine the sensor. It may require cleaning If the ACC system brings your vehicle to a standstill “WIPE FRONT RADAR SENSOR IN FRONT OF or removal of an obstruction.
Page 119 STARTING AND OPERATING When the condition that deactivated the system is This message can sometimes be displayed while SERVICE ACC/FCW WARNING no longer present, the system will return to the driving in adverse weather conditions. The ACC/ If the system turns off, and the instrument cluster “Adaptive Cruise Control Off”...
Page 120 STARTING AND OPERATING OFFSET DRIVING TURNS AND BENDS LANE CHANGING ACC may not detect a vehicle in the same lane that When driving on a curve with ACC engaged, the ACC may not detect a vehicle until it is completely is offset from your direct line of travel, or a vehicle system may increase or decrease the vehicle in the lane in which you are traveling.
Page 121: Parksense Front/Rear Park Assist
STARTING AND OPERATING PARKSENSE FRONT/REAR PARK ASSIST NARROW VEHICLES STATIONARY OBJECTS AND VEHICLES Some narrow vehicles traveling near the outer ACC does not react to stationary objects or SYSTEM — IF EQUIPPED edges of the lane or edging into the lane are not vehicles.
Page 122: Parksense Sensors
STARTING AND OPERATING The automatic braking function may only be ParkSense will retain the last system state 12 inches (30 cm) up to 79 inches (200 cm) from  applied if the vehicle deceleration is not enough (enabled or disabled) from the last ignition cycle the rear fascia/bumper.
Page 123 STARTING AND OPERATING Front/Rear ParkSense Arcs 1 — No Tone/Solid Arc 6 — Fast Tone/Flashing Arc 2 — No Tone/Flashing Arc 7 — Fast Tone/Flashing Arc 3 — Fast Tone/Flashing Arc 8 — Slow Tone/Solid Arc 4 — Continuous Tone/Flashing Arc 9 —...
Page 124 STARTING AND OPERATING The vehicle is close to the obstacle when the instrument cluster display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS FOR REAR Greater than Less than Rear Distance...
Page 125: Parksense Warning Display
STARTING AND OPERATING NOTE: NABLING ISABLING ENSE ERVICE ENSE SSIST ParkSense will reduce the volume of the radio, if YSTEM ParkSense can be enabled and disabled on, when the system is sounding an audio tone. with the ParkSense switch. During vehicle start up, when the ParkSense Front Park Assist Audible Alerts When the ParkSense switch is pushed to System has detected a faulted condition, the...
Page 126: Cleaning The Parksense System
STARTING AND OPERATING If "PARKSENSE UNAVAILABLE WIPE REAR When you turn ParkSense off, the instrument ParkSense should be disabled when the liftgate   SENSORS" or "PARKSENSE UNAVAILABLE WIPE cluster will display “PARKSENSE OFF.” Further- is in the open position. An opened liftgate could FRONT SENSORS"...
Page 127: Parksense Active Park Assist System
STARTING AND OPERATING NOTE: NABLING ISABLING CAUTION! The driver is always responsible for controlling  ENSE CTIVE SSIST ParkSense is only a parking aid and it is unable  the vehicle, responsible for any surrounding YSTEM to recognize every obstacle, including small objects, and must intervene as required.
Page 128: Parallel/Perpendicular Parking Space Assistance Operation
STARTING AND OPERATING NOTE: Driver's door is opened  If the vehicle is driven above approximately Rear liftgate is opened  15 mph (25 km/h), the instrument cluster display Electronic Stability Control/Anti-Lock Braking  will instruct the driver to slow down. If the vehicle System intervention is driven above approximately 18 mph (30 km/h), 4WD Low is active or activated...
Page 129 STARTING AND OPERATING NOTE: When an available parking space has been found, and the vehicle is not in position, you will be When searching for a parking space, use the  instructed to move forward to position the vehicle turn signal indicator to select which side of the for a perpendicular or parallel parking sequence vehicle you want to perform the parking (depending on the type of maneuver being...
Page 130 STARTING AND OPERATING When the vehicle is in the parking position, the The system will cancel the maneuver if the  WARNING! maneuver is complete and the driver will be vehicle speed exceeds 5 mph (7 km/h) during instructed to check the vehicle's parking position, active steering guidance into the parking space.
Page 131: Lanesense - If Equipped
STARTING AND OPERATING The driver may manually override the haptic NOTE: CAUTION! warning by applying force to the steering wheel at The LaneSense system will retain the last system any time. state on or off from the last ignition cycle when the The vehicle must be driven slowly when using ...
Page 132 STARTING AND OPERATING Left Lane Departure — Only Left Lane Detected Left Lane Departure — Both Lanes Detected For example: If approaching the left side of the lane the steering wheel will turn to the right. When the LaneSense system is on, the When the LaneSense system is on, the lane ...
Page 133: Changing Lanesense Status
STARTING AND OPERATING The system will not apply torque to the steering When the vehicle is shifted out of REVERSE with  wheel whenever a safety system engages camera delay turned off, the rear camera mode is (Anti-Lock Brakes, Traction Control System, exited and the previous screen appears.
Page 134: Refueling The Vehicle
STARTING AND OPERATING Rear View Camera — Viewing At Speed 2. Open the fuel filler door. WARNING! When the vehicle is in PARK, NEUTRAL, or Drivers must be careful when backing up even DRIVE the Rear View Camera can be when using the ParkView Rear Back Up Camera.
Page 135: Emergency Fuel Filler Door Release
STARTING AND OPERATING 4. Fill the vehicle with fuel, when the fuel nozzle NOTE: MERGENCY ILLER “clicks” or shuts off, the fuel tank is full. If the fuel door does not latch after the use of the ELEASE manual release cable, the actuator latch should be 5.
Page 136: Trailer Towing
STARTING AND OPERATING Payload Curb Weight Improper weight distributions can have an adverse effect on the way your vehicle steers and handles The payload of a vehicle is defined as the allowable The curb weight of a vehicle is defined as the total and the way the brakes operate.
Page 137: Common Towing Definitions
STARTING AND OPERATING Gross Combination Weight Rating (GCWR) dampen any unwanted trailer swaying motions OMMON OWING EFINITIONS while traveling. The GCWR is the total allowable weight of your The following trailer towing related definitions will If equipped, the electronic TSC recognizes a vehicle and trailer when weighed in combination.
Page 138 STARTING AND OPERATING 8. Use the touchscreen radio settings and switch 4. Measure the height from the top of the front WARNING! wheel opening on the fender to the ground; off tire jack mode. Make sure the truck returns this is height H1. to normal ride height.
Page 139: Trailer Hitch Classification
STARTING AND OPERATING RAILER ITCH LASSIFICATION The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Classification Definitions Class Max.
Page 140: Trailer Hitch Receiver Cover Removal - If Equipped
STARTING AND OPERATING 2. Pull the bottom of the cover outward (towards RAILER ITCH ECEIVER OVER you), pull downwards to disengage the tabs — I EMOVAL QUIPPED located at the top of the hitch receiver cover. Your vehicle may be equipped with a trailer hitch receiver cover, this must be removed to access the trailer hitch receiver (if equipped).
Page 141: Towing Requirements
STARTING AND OPERATING NOTE: WARNING! WARNING! Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional Make certain that the load is secured in the Total weight must be distributed between the ...
Page 142 STARTING AND OPERATING NOTE: Check for signs of tire wear or visible tire  WARNING! damage before towing a trailer. Do not cut or splice wiring into the vehicle’s wiring harness. Towing any trailer will increase your stopping Replacing tires with a higher load carrying ...
Page 143: Towing Tips
STARTING AND OPERATING AutoStick OWING When using the AutoStick shift control, select  Before towing, practice turning, stopping, and the highest gear that allows for adequate perfor- backing up the trailer in an area located away from mance and avoids frequent downshifts. For heavy traffic.
Page 144: Recreational Towing (Behind Motorhome)
STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) OWING EHICLE EHIND NOTHER EHICLE Four-Wheel Drive Models Four-Wheel Drive Models Towing Condition Wheels OFF The Ground Two-Wheel Drive Models Without 4WD Low With 4WD Low See Instructions Transmission in PARK  Flat Tow NONE NOT ALLOWED NOT ALLOWED...
Page 145: Drive Models
STARTING AND OPERATING — T — ECREATIONAL OWING HEEL ECREATIONAL OWING CAUTION! –T II/Q –D RIVE ODELS UADRA UADRA RIVE Towing with the rear wheels on the ground will HEEL RIVE ODELS DO NOT flat tow this vehicle. Damage to the cause severe transmission damage.
Page 146 STARTING AND OPERATING The ignition must be in the ON/RUN position  CAUTION! CAUTION! for a shift to take place and for the position indicator lights to be operable. If the ignition It is necessary to follow these steps to be certain Before recreational towing, perform the proce- ...
Page 147 STARTING AND OPERATING 14. Attach the vehicle to the tow vehicle using a A flashing N (NEUTRAL) position indicator  suitable tow bar. light indicates that shift requirements have not been met. 15. Release the parking brake. 4. Press and hold the brake pedal. Shifting Out Of N (NEUTRAL) 5.
Page 148: Driving Tips
STARTING AND OPERATING 10. Disconnect vehicle from the tow vehicle. Lower Front Fascia Removal: RIVING 11. Start the engine. 1. Remove the seven quarter turn fasteners. NOTE: 12. Press and hold the brake pedal. 2. Starting on one side of the vehicle, disengage Prior to off-road driving with non-Summit models lower fascia from the upper fascia.
Page 149 STARTING AND OPERATING 2. Using a suitable tool, disconnect the wire clip NOTE: NOTE: from the bracket. Only models with the Off-Road Package are If you receive a fault, see an authorized dealer. equipped with a protective connector. They may need to perform a sensor alignment. NOTE: 5.
Page 150 STARTING AND OPERATING Quadra-Lift — If Equipped WARNING! CAUTION! When off-roading, it is recommended that the Do not drive in 4WD LOW on dry pavement; When driving through water, do not exceed lowest useable vehicle height that will clear the driveline damage may result.
Page 151 STARTING AND OPERATING Flowing Water Driving In Snow, Mud And Sand If you stall or begin to lose forward motion while climbing a steep hill, allow your vehicle to come to If the water is swift flowing and rising (as in storm In heavy snow, when pulling a load, or for a stop and immediately apply the brakes.
Page 152 STARTING AND OPERATING After Driving Off-Road Remember, never drive diagonally across a hill. After extended operation in mud, sand, water, or  Always drive straight up or down. similar dirty conditions, have the radiator, fan, Off-road operation puts more stress on your brake rotors, wheels, brake linings, and axle If the wheels start to slip as you approach the crest vehicle than does most on-road driving.
Page 153: Multimedia
MULTIMEDIA UCONNECT SYSTEMS NOTE: Your vehicle may be equipped with certain security features to reduce the risk of unauthorized and To help further improve user experience,  For detailed information about your Uconnect 4/ unlawful access to vehicle systems and wireless features, stability, etc., and minimize the poten- 4C/4C NAV With 8.4-inch Display system, refer to communications.
Page 154: Uconnect Settings
MULTIMEDIA UCONNECT SETTINGS NOTE: USTOMER ROGRAMMABLE EATURES All settings should be changed with the ignition  The Uconnect system uses a combination of in the ON/RUN position. buttons on the touchscreen and buttons on the Only one area of the touchscreen may be ...
Page 155 MULTIMEDIA Language When the Language button is pressed on the touchscreen, the system displays the different language options. Once an option is selected, the system will display in the chosen language. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will change the language of the Uconnect system and Instrument...
Page 156 MULTIMEDIA Setting Name Description This setting will allow you to set the brightness when the headlights are off. To Display Brightness With Headlights OFF access this setting, Display Mode must be set to “Manual”. The “+” setting will increase the brightness; the “-” will decrease the brightness. Set Theme This setting will allow you to change the display theme.
Page 157 MULTIMEDIA Units When the Units button is pressed on the touchscreen, the system displays the different measurement options. The selected unit of measurement will display in the instrument cluster display and Navigation system (if equipped). The available settings are: NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 158 MULTIMEDIA Clock When the Clock button is pressed on the touchscreen, the system displays the different options related to the vehicle’s internal clock. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will sync the time to the GPS receiver in the system. The system Sync Time With GPS will control the time via the GPS location.
Page 159 MULTIMEDIA Camera When the Camera button is pressed on the touchscreen, the system displays the options related to the vehicle’s camera features. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will add a delay to the ParkView Backup Camera when shifting out ParkView Backup Camera Delay of REVERSE.
Page 160 MULTIMEDIA Setting Name Description This setting will turn the Forward Collision Warning system on or off. The “Off” setting will deactivate the FCW system. The “Warning Only” setting will provide Forward Collision Warning only an audible chime when a collision is detected. The “Warning + Active Braking”...
Page 161 MULTIMEDIA Setting Name Description This setting will adjust the power steering modes. Setting options are Power Steering Default “Normal”, “Sport”, and “Comfort”. Hill Start Assist This setting will turn the Hill Start Assist system on or off. ParkView Backup Camera Active Guidelines This setting will turn the ParkView Backup Camera Active Guidelines on or off.
Page 162 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned On or Off. This feature is only allowed by law in the country of the vehicle purchased.
Page 163 MULTIMEDIA Doors & Locks When the Doors & Locks button is pressed on the touchscreen, the system displays the options related to locking and unlocking the vehicle’s doors. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will allow you to change if the doors lock automatically when the Auto Door Locks...
Page 164 MULTIMEDIA Setting Name Description This setting will recall preset radio stations and driver seat position that have Personal Settings Linked To Key Fob been linked to the key fob. Power Liftgate Alert This setting will allow you to turn the Power Liftgate on or off. Seats &...
Page 165 MULTIMEDIA Key Off Options When the Key Off Options button is pressed on the touchscreen, the system displays the options related to vehicle shut off. These settings will only activate when the ignition is set to OFF. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description Easy Exit Seat...
Page 166 MULTIMEDIA Suspension — If Equipped When the Suspension button is pressed on the touchscreen, the system displays the options related to the vehicle’s suspension system. NOTE: Depending on the vehicle’s options, feature settings may vary. Setting Name Description This setting will automatically lower the vehicle ride height for easier entry and Auto Entry/Exit Suspension exit.
Page 167 MULTIMEDIA Audio When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within the vehicle, adjust the bass or treble levels, and auto-play settings from an audio device or smartphone. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 168 MULTIMEDIA Phone/Bluetooth® When the Phone/Bluetooth® button is pressed on the touchscreen, the system displays the options related to Bluetooth® connectivity from an external audio device or smartphone. The list of paired audio devices or smartphones can be accessed from this menu. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 169 MULTIMEDIA SiriusXM® Setup When the SiriusXM® Setup button is pressed on the touchscreen, the system displays options related to SiriusXM® Satellite Radio. These settings can be used to skip specific radio channels and restart favorite songs from the beginning. NOTE: A subscription to SiriusXM®...
Page 170 MULTIMEDIA Reset When the Reset button is pressed on the touchscreen, the system displays the options related to resetting the Uconnect system back to its default settings. These settings can clear personal data and reset selected settings from other menus. NOTE: Depending on the vehicle’s options, feature settings may vary.
Page 171: Rear Seat Entertainment (Rse) System - If Equipped
MULTIMEDIA REAR SEAT ENTERTAINMENT (RSE) SYSTEM — 2. Place the ignition in the ON/RUN or ACC With the Video Screen system, Channel 1 on  position. the remote control and headphones refers IF EQUIPPED to Screen 1 (driver's side), and Channel 2 on NOTE: the remote control and headphones refers If equipped with a Blu-ray™...
Page 172: Video Screen
MULTIMEDIA ™ D The Blu-ray™ disc player is located in the center console. RSE System Headphone Channel Selectors IDEO CREEN NOTE: Blu-ray™ Disc Player Location Typically there are two different ways to operate the features of the Rear Seat Entertainment 1.
Page 173 MULTIMEDIA 3. To watch a Blu-ray™ disc on Channel 2 for 1. RSE Channel 1 Mode 6. RSE Source passenger’s side rear passengers, ensure the Indicates the current source for Screen 1/ Press this button to change the source for the remote control and headphone switches are Channel 1.
Page 174: Play Video Games
MULTIMEDIA Using The Remote Control NOTE: Pressing the screen on the Uconnect system while 1. Push the SOURCE button on the Remote a DVD or Blu-ray™ Disc is playing brings up the Control. basic remote control functions for DVD or Blu-ray™ 2.
Page 175: Important Notes For The Video Screen System
MULTIMEDIA ™ D When connecting an external source to the AUX/ Controls And Indicators LAYER EMOTE HDMI input, be sure to follow the standard color ONTROL — To hear audio while the screen is closed, coding (numbers 1-3) for the audio/video jacks: push the Power button to turn the headphone 1.
Page 176: Headphones Operation
MULTIMEDIA 13. Channel/Screen Selector Switch — Indicates EADPHONES PERATION ONTROLS which channel is being controlled by the The headphones receive two separate channels of The headphone power indicator and controls are remote control. When the selector switch is in audio using an infrared transmitter from the video located on the right ear cup.
Page 177: Replacing The Headphone Batteries
MULTIMEDIA 2. Push the SOURCE button on the remote so the above limitation may not apply to you. This TEREO EADPHONE IFETIME IMITED warranty gives you specific legal rights. You may control to advance to the next mode. ARRANTY also have other rights, which vary from jurisdiction 3.
Page 178 MULTIMEDIA Display Settings To change the current audio mode, push the DVD Region Codes  remote control’s SOURCE button. This will auto- The Blu-ray™ Disc player and many DVD discs are When watching a video source (Blu-ray™ Disc or matically select the next available audio mode coded by geographic region.
Page 179 MULTIMEDIA If you record a disc using a personal computer, Compressed Audio Files (MP3 and WMA) For both formats, the recommended sample there may be cases where the Blu-ray™ Disc player rate is either 44.1 kHz or 48 kHz. The Blu-ray™ Disc player is capable of playing MP3 may not be able to play some or the entire disc, (MPEG-1 Audio Layer 3) and WMA (Windows Media To change the current file, use the remote...
Page 180: Radio Operation And Mobile Phones
MULTIMEDIA OFF-ROAD PAGES — IF EQUIPPED Product Agreement EGULATORY AFETY This product incorporates copyright protection NFORMATION Your vehicle is equipped with Off-Road Pages, technology that is protected by US patents and which provides the vehicle status while operating US/CANADA other intellectual property rights. Use of this on off-road conditions.
Page 181: Off-Road Pages Status Bar
MULTIMEDIA Off-Road Pages has the following selectable pages: EHICLE YNAMICS Vehicle Dynamics  The Vehicle Dynamics page displays information Suspension  concerning the vehicle’s drivetrain. Pitch & Roll — If Equipped  The following information is displayed: Accessory Gauge  Steering angle in degrees ...
Page 182: Suspension - If Equipped
MULTIMEDIA — I & R USPENSION QUIPPED ITCH The Suspension page displays information The Pitch & Roll page displays the vehicle’s current regarding the vehicle’s suspension. pitch (angle up and down) and roll (angle side to side) in degrees. The Pitch & Roll gauges provide a The following information is displayed: visualization of the current vehicle angle.
Page 183: Accessory Gauges
MULTIMEDIA — I NOTE: CCESSORY AUGES ELEC ERRAIN QUIPPED While in the Selec-Terrain pages, the Off-Road The Accessory Gauges page displays the current The Selec-Terrain page displays the current Pages Status Bar will also display the current status of the vehicle’s Coolant Temperature, Oil Selec-Terrain mode through a high resolution Selec-Terrain mode.
Page 184: Safety
SAFETY SAFETY FEATURES The ABS is designed to function with the Original WARNING! Equipment Manufacturer (OEM) tires. Modification (ABS) may result in degraded ABS performance. The ABS cannot prevent collisions, including RAKE YSTEM  those resulting from excessive speed in turns, WARNING! The ABS provides increased vehicle stability and following another vehicle too closely, or hydro-...
Page 185: Electronic Brake Control (Ebc) System
SAFETY If the ABS Warning Light is on, the brake system Brake System Warning Light WARNING! should be serviced as soon as possible to restore The red Brake System Warning Light will turn on the benefits of Anti-Lock Brakes. If the ABS The Brake Assist System (BAS) cannot prevent when the ignition is placed in the ON/RUN mode Warning Light does not come on when the ignition...
Page 186 SAFETY NOTE: prevent wheel lift due to other factors, such as Oversteer — when the vehicle is turning more  road conditions, leaving the roadway, or striking than appropriate for the steering wheel position. The DST feature is only meant to help the driver objects or other vehicles.
Page 187 SAFETY Partial Off WARNING! WARNING! This mode may be useful if the vehicle becomes Electronic Stability Control (ESC) cannot Vehicle modifications, or failure to properly   stuck. This mode may modify TCS and ESC prevent the natural laws of physics from maintain your vehicle, may change the thresholds for activation, which allows for more acting on the vehicle, nor can it increase the...
Page 188 SAFETY ESC Activation/Malfunction Indicator Light NOTE: 3. Active (feature is enabled and actively controlling vehicle speed). And ESC OFF Indicator Light The ESC Activation/Malfunction Indicator Light  and the ESC OFF Indicator Light come on The ESC Activation/Malfunction Indicator Enabling HDC momentarily each time the ignition is placed in Light in the instrument cluster will come HDC is enabled by pushing the HDC switch, but the...
Page 189 SAFETY 4th = 2.5 mph (4 km/h) Disabling HDC The cluster icon and switch lamp will flash for   several seconds, then extinguish when HDC 5th = 3.1 mph (5 km/h) HDC will be deactivated and disabled if any of the ...
Page 190 SAFETY Disabling And Enabling HSA Rain Brake Support (RBS) The parking brake must be off.  The driver door must be closed. This feature can be turned on or turned off. To RBS may improve braking performance in wet  change the current setting using the Uconnect conditions.
Page 191 SAFETY 3. Active (feature is enabled and actively SSC Target Set Speeds Driver Override: controlling vehicle speed) 1st = .6 mph (1 km/h) The driver may override SSC activation with throttle  or brake application at any time. 2nd = 1.2 mph (2 km/h) ...
Page 192: Auxiliary Driving Systems
SAFETY Traction Control System (TCS) Feedback To The Driver: When TSC is functioning, the ESC Activation/ Malfunction Indicator Light will flash, the engine The instrument cluster has an SSC icon and the The TCS monitors the amount of wheel spin of power may be reduced and you may feel the SSC switch has an LED which offer feedback to the each of the driven wheels.
Page 193 SAFETY NOTE: The BSM system can become blocked if snow, ice, mud, or other road contaminations accumulate on The BSM system DOES NOT alert the driver  the rear fascia/bumper where the radar sensors about rapidly approaching vehicles that are are located.
Page 194 SAFETY The BSM system notifies the driver of objects in the Overtaking Traffic detection zones by illuminating the BSM warning If you pass another vehicle slowly with a relative light located in the outside mirrors. In addition, speed less than 15 mph (24 km/h) and the vehicle when the turn signal is activated during the alert on remains in the blind spot for approximately 1.5 the side of the vehicle corresponding to the alert,...
Page 195 SAFETY Rear Cross Path (RCP) RCP is a feature that is intended to aid the driver when backing out of parking spaces where their vision of oncoming vehicles may be blocked. Proceed slowly and cautiously out of the parking space until the rear end of the vehicle is exposed. The RCP system will then have a clear view of the cross traffic and if an oncoming vehicle is detected, alert the driver.
Page 196: Forward Collision Warning (Fcw) With Mitigation
SAFETY NOTE: Blind Spot Alert Lights Only Blind Spot Alert Off In a parking lot situation, oncoming vehicles can be When operating in Blind Spot Alert mode, the BSM When the BSM system is turned off, there will be blocked by vehicles parked on either side. If the system will provide a visual alert in the appropriate no visual or audible alerts from either the BSM or sensors are blocked by other structures or...
Page 197 SAFETY level of active braking to help slow the vehicle and NOTE: FCW Braking Status And Sensitivity mitigate the potential forward collision. If the driver The minimum speed for FCW activation is  The FCW Sensitivity and Active Braking status are reacts to the warnings by braking and the system 1 mph (2 km/h).
Page 198: Tire Pressure Monitoring System (Tpms)
SAFETY NOTE: FCW Limited Warning RESSURE ONITORING YSTEM The “Near” setting may result in a lesser number of (TPMS) If the instrument cluster displays “ACC/FCW FCW possible collision warnings experienced. Limited Functionality” or “ACC/FCW Limited The TPMS will warn the driver of a low tire pressure NOTE: Functionality Clean Front Windshield”...
Page 199 SAFETY The TPMS will continue to warn the driver of low situation, the TPMS Warning Light will turn off only CAUTION! after the tires have been inflated to the vehicle’s tire pressure as long as the condition exists, and will not turn off until the tire pressure is at or above recommended cold tire pressure value.
Page 200 SAFETY Tire Pressure Monitoring System Low The TPMS uses wireless technology with wheel vehicle’s recommended cold tire pressure rim-mounted electronic sensors to monitor tire displayed in the “Inflate to XX” message. Pressure Warnings pressure levels. Sensors, mounted to each wheel NOTE: The TPMS Warning Light will illuminate in as part of the valve stem, transmit tire pressure...
Page 201 SAFETY flash, the "SERVICE TPM SYSTEM" message will five seconds and then display dashes (- -) in place To deactivate the TPMS, first, replace all four wheel of the pressure value. For each subsequent not be present, and a pressure value will be and tire assemblies (road tires) with tires not displayed instead of dashes.
Page 202: Occupant Restraint Systems
SAFETY OCCUPANT RESTRAINT SYSTEMS the appropriate child restraint or WARNING! belt-positioning booster seat in a rear seating Some of the most important safety features in your position Ú page 216. Never place a rear-facing child restraint in  vehicle are the restraint systems: front of an air bag.
Page 203 SAFETY Enhanced Seat Belt Use Reminder System BeltAlert Warning Sequence The outboard front passenger seat BeltAlert is not active when the outboard front passenger seat is (BeltAlert) The BeltAlert warning sequence is activated when unoccupied. BeltAlert may be triggered when an the vehicle is moving above a specified vehicle Driver And Passenger BeltAlert —...
Page 204 SAFETY Lap/Shoulder Belts WARNING! WARNING! All seating positions in your vehicle are equipped A lap belt worn too high can increase the risk It is dangerous to ride in a cargo area, inside   with lap/shoulder belts. of injury in a collision. The seat belt forces or outside of a vehicle.
Page 205 SAFETY Lap/Shoulder Belt Operating Instructions WARNING! 1. Enter the vehicle and close the door. Sit back A seat belt that is worn under your arm is  and adjust the seat. dangerous. Your body could strike the inside 2. The seat belt latch plate is above the back of surfaces of the vehicle in a collision, the front seat, and next to your arm in the rear increasing head and neck injury.
Page 206 SAFETY Adjustable Upper Shoulder Belt Anchorage NOTE: 5. Position the shoulder belt across the shoulder and chest with minimal, if any slack so that it The adjustable upper shoulder belt anchorage is In the driver and outboard front passenger seats, is comfortable and not resting on your neck.
Page 207 SAFETY Seat Belt Extender Seat Belts And Pregnant Women Seat Belt Pretensioner If a seat belt is not long enough to fit properly, even The front outboard seat belt system is equipped when the webbing is fully extended and the with pretensioning devices that are designed to adjustable upper shoulder belt anchorage (if remove slack from the seat belt in the event of a...
Page 208 SAFETY Switchable Automatic Locking Retractor 3. Allow the seat belt to retract. As the seat belt comfortably wrap around the occupant’s mid-section. Slide the latch plate into the buckle retracts, you will hear a clicking sound. This (ALR) until you hear a "click." indicates the seat belt is now in the Automatic The seat belts in the passenger seating positions Locking Mode.
Page 209 SAFETY Supplemental Active Head Restraints Active Head Restraint (AHR) Components: WARNING! (AHR) Do not place items over the top of the Active  These head restraints are passive, deployable Head Restraint, such as coats, seat covers or components, and vehicles with this equipment portable DVD players.
Page 210: Supplemental Restraint Systems (Srs)
SAFETY Air Bag Warning Light Resetting Active Head Restraints (AHR) UPPLEMENTAL ESTRAINT YSTEMS (SRS) The Occupant Restraint Controller (ORC) monitors the readiness of the electronic Some of the safety features described in this parts of the air bag system whenever the section may be standard equipment on some ignition switch is in the START or ON/RUN models, or may be optional equipment on others.
Page 211 SAFETY The Air Bag Warning Light does not come on Redundant Air Bag Warning Light  during the four to eight seconds when the igni- If a fault with the Air Bag Warning Light is tion switch is first in the ON/RUN position. detected, which could affect the The Air Bag Warning Light remains on after the Supplemental Restraint System (SRS),...
Page 212 SAFETY Front Air Bag Operation This vehicle may be equipped with a driver and/or WARNING! front passenger seat belt buckle switch that Front Air Bags are designed to provide additional detects whether the driver or front passenger seat Never place a rear-facing child restraint in ...
Page 213 SAFETY The steering wheel hub trim cover and the upper Supplemental Side Air Bags When the SAB deploys, it opens the seam on the outboard side of the seatback’s trim cover. The passenger side of the instrument panel separate Supplemental Seat-Mounted Side Air Bags (SABs) and fold out of the way as the air bags inflate to inflating SAB deploys through the seat seam into This vehicle is equipped with Supplemental...
Page 214 SAFETY vehicle during impacts that require Side Air Bag WARNING! occupant protection. In side impacts, the Side Air Bags deploy independently; a left side impact Do not mount equipment, or stack luggage or  deploys the left Side Air Bags only and a right-side other cargo up high enough to block the impact deploys the right Side Air Bags only.
Page 215 SAFETY NOTE: Air Bag System Components WARNING! Air bag covers may not be obvious in the interior NOTE: trim, but they will open during air bag deployment. Seat belts (and child restraints where appro-  The Occupant Restraint Controller (ORC) monitors priate) are necessary for your protection in all Rollover Events the internal circuits and interconnecting wiring...
Page 216 SAFETY If you do have a collision which deploys the air Turn on the interior lights, which remain on as  WARNING! bags, any or all of the following may occur: long as the battery has power or for 15 minutes from the intervention of the Enhanced Accident Deployed air bags and seat belt pretensioners The air bag material may sometimes cause...
Page 217 SAFETY NOTE: Maintaining Your Air Bag System Event Data Recorder (EDR) After an accident, remember to cycle the ignition to This vehicle is equipped with an event data WARNING! the STOP (OFF/LOCK) position and remove the key recorder (EDR). The main purpose of an EDR is to from the ignition switch to avoid draining the record, in certain crash or near crash-like Modifications to any part of the air bag system...
Page 218: Child Restraints
SAFETY NOTE: Children 12 years or younger should ride properly Before buying any restraint system, make sure that buckled up in a rear seat, if available. According to it has a label certifying that it meets all applicable EDR data are recorded by your vehicle only if a crash statistics, children are safer when properly Safety Standards.
Page 219 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and who Either an Infant Carrier or a Convertible Child Infants and Toddlers have not reached the height or weight limits of their Restraint, facing rearward in a rear seat of the child restraint...
Page 220 SAFETY Older Children And Child Restraints 3. Does the shoulder belt cross the child’s WARNING! shoulder between the neck and arm? Children who are two years old or who have After a child restraint is installed in the  4. Is the lap part of the belt as low as possible, outgrown their rear-facing convertible child seat vehicle, do not move the vehicle seat forward touching the child’s thighs and not the...
Page 221 SAFETY Recommendations For Attaching Child Restraints Use Any Attachment Method Shown With An “X” Below Combined Weight of Restraint Type the Child + Child LATCH – Lower Anchors LATCH – Lower Anchors Seat Belt + Top Tether Seat Belt Only Restraint Only + Top Tether Anchor...
Page 222 SAFETY Lower Anchors And Tethers For CHildren LATCH Positions For Installing Child Your vehicle is equipped with the child restraint anchorage system called LATCH, which stands for (LATCH) Restraint System Restraints In This Vehicle Lower Anchors and Tethers for CHildren. The LATCH system has three vehicle anchor points for installing LATCH-equipped child seats.
Page 223 SAFETY Frequently Asked Questions About Installing Child Restraints With LATCH Use the LATCH anchorage system until the What is the weight limit (child’s weight + weight of combined weight of the child and the child restraint the child restraint) for using the LATCH anchorage 65 lbs (29.5 kg) is 65 lbs (29.5 kg).
Page 224 SAFETY Locating The LATCH Anchorages LATCH-compatible child restraint systems will be equipped with a rigid bar or a flexible strap on each The lower anchorages are round bars side. Each will have a hook or connector to attach that are found at the rear of the seat to the lower anchorage and a way to tighten the cushion where it meets the seatback, connection to the anchorage.
Page 225 SAFETY Vehicle With A Center Arm Rest Tether 2. Place the child seat between the lower anchorages for that seating position. If the For rear-facing child restraints secured in the second row seat can be reclined, you may center seat position with the vehicle seat belts, the recline the seat and/or raise the head restraint rear center seat position has an armrest tether (if adjustable) to get a better fit.
Page 226 SAFETY How To Stow An Unused Switchable-ALR clip. The ALR retractor can be “switched” into a WARNING! locked mode by pulling all of the webbing out of the (ALR) Seat Belt: retractor and then letting the webbing retract back Child restraint anchorages are designed to ...
Page 227 SAFETY Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + weight of the Always use the tether anchor when using the seat belt child restraint) for using the Tether Anchor with the Weight limit of the Child Restraint to install a forward facing child restraint, up to the seat belt to attach a forward facing child restraint?
Page 228 SAFETY Installing Child Restraints Using The Top 5. To lock the seat belt, pull down on the shoulder 1. Look behind the seating position where you part of the belt until you have pulled all the plan to install the child restraint to find the Tether Anchorage: seat belt webbing out of the retractor.
Page 229: Safety Tips
SAFETY WARNING! If your vehicle is equipped with a split rear  seat, make sure the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap. SAFETY TIPS RANSPORTING ASSENGERS Top Tether Strap Anchorage (Located On Seatback) Top Tether Strap Mounting NEVER TRANSPORT PASSENGERS IN THE CARGO 3.
Page 230: Transporting Pets
SAFETY Defroster RANSPORTING AFETY HECKS HOULD Check operation by selecting the defrost mode and NSIDE EHICLE Air Bags deploying in the front seat could harm place the blower control on high speed. You should your pet. An unrestrained pet will be thrown about Seat Belts be able to feel the air directed against the and possibly injured, or injure a passenger during...
Page 231: Periodic Safety Checks You Should Make Outside The Vehicle
SAFETY WARNING! WARNING! WARNING! ALWAYS securely attach your ONLY use the driver’s side floor mat on the If the vehicle carpet has been removed and    floor mat using the floor mat driver’s side floor area. To check for interfer- re-installed, always properly attach carpet to fasteners.
Page 232: Exhaust Gas
SAFETY Lights ARBON ONOXIDE ARNINGS WARNING! Have someone observe the operation of brake If you are required to drive with the trunk/lift-  WARNING! lights and exterior lights while you work the gate/rear doors open, make sure that all controls. Check turn signal and high beam Carbon monoxide (CO) in exhaust gases is windows are closed and the climate control indicator lights on the instrument panel.
Page 233: In Case Of Emergency
IN CASE OF EMERGENCY HAZARD WARNING FLASHERS When you must leave the vehicle to seek If equipped, the rearview mirror contains a SOS assistance, the Hazard Warning Flashers will and an ASSIST button. The Hazard Warning Flashers button is located on continue to operate even though the ignition is WARNING! the switch bank just above the climate controls.
Page 234 IN CASE OF EMERGENCY NOTE: ASSIST Call 2. The LED light located between the ASSIST and SOS buttons on the rearview Mirror will turn The ASSIST Button is used to automatically Your vehicle may be transmitting data as  green once a connection to a SOS operator has authorized by the subscriber.
Page 235 IN CASE OF EMERGENCY SOS Call System Limitations WARNING! WARNING! Vehicles sold in Mexico DO NOT have SOS Call Never place anything on or near the vehicle’s The Occupant Restraint Control module turns   system capabilities. operable network and GPS antennas. You on the air bag Warning Light on the instrument SOS or other emergency line operators in Mexico could prevent operable network and GPS...
Page 236: Jacking And Tire Changing
IN CASE OF EMERGENCY NOTE: Operator error by the SOS operator  WARNING! Changes or modifications not expressly approved LTE (voice/data) or 4G (data) network  by the party responsible for compliance could void Being under a jacked-up vehicle is dangerous. congestion ...
Page 237: Jack Location
IN CASE OF EMERGENCY For vehicles equipped with Quadra-Lift, to disable the automatic leveling feature Ú page 148. 1. Park the vehicle on a firm, level surface. Avoid ice or slippery surfaces. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic.
Page 238: Spare Tire Stowage - If Equipped
IN CASE OF EMERGENCY — I PARE TOWAGE QUIPPED WARNING! The spare tire is stowed under the load floor in the Apply the parking brake firmly and set the  rear cargo area and is secured to the body with a transmission in PARK.
Page 239 IN CASE OF EMERGENCY 1. Remove the spare tire, jack, and tools from storage. Turn the fastener counterclockwise to remove the spare tire. Loosen Lug Nuts Jacking Locations 3. Assemble the jack and jacking tools. 4. For the front axle, place the jack on the body flange just behind the front tire as indicated by the triangular lift point symbol on the sill Removing Spare Tire Fastener...
Page 240 IN CASE OF EMERGENCY NOTE: CAUTION! Depending on vehicle trim level, certain models come equipped with Rock Rails which have a Do NOT raise the vehicle by the body side sill different front lifting point location. Also, the trian- molding. Be sure the jack is placed in the proper gular symbols are not visible for this trim package.
Page 241 IN CASE OF EMERGENCY CAUTION! Be sure to mount the spare tire with the valve stem facing outward. The vehicle could be damaged if the inflatable spare tire is mounted incorrectly. Rear Lifting Point - Rock Rail Rear Jacking Location - Rock Rail 6.
Page 242: Jump Starting
IN CASE OF EMERGENCY JUMP STARTING 10. Finish tightening the lug nuts. Push down on the wrench while at the end of the handle for If your vehicle has a discharged battery, it can be increased leverage. Tighten the lug nuts in a jump started using a set of jumper cables and a star pattern until each nut has been tightened battery in another vehicle, or by using a portable...
Page 243: Preparations For Jump Start
IN CASE OF EMERGENCY 3. Pull upward and remove the protective cap REPARATIONS TART TARTING ROCEDURE over the remote positive (+) battery post. The battery in your vehicle is located under the 4. If using another vehicle to jump start the WARNING! passenger's front seat.
Page 244: Refueling In Emergency
IN CASE OF EMERGENCY REFUELING IN EMERGENCY 4. Connect the opposite end of the negative (-) Disconnecting The Jumper Cables jumper cable to the remote negative (-) post 1. Disconnect the negative (-) end of the jumper The vehicle is equipped with a refueling funnel (exposed metallic/unpainted post of the cable from the remote negative (-) post of the Ú...
Page 245: If Your Engine Overheats
IN CASE OF EMERGENCY See the following steps for refueling: 5. Remove funnel from filler pipe, clean off prior WARNING! to putting back in the spare tire storage area. 1. Retrieve funnel from the spare tire storage You or others can be badly burned by hot engine area.
Page 246: Manual Park Release
IN CASE OF EMERGENCY MANUAL PARK RELEASE You can also turn the temperature control to In order to move the vehicle in cases where the  maximum heat, the mode control to floor and transmission will not shift out of PARK (P) (such as the blower control to high.
Page 247 IN CASE OF EMERGENCY 3. Press and maintain firm pressure on the brake To Disengage The Manual Park Release Lever: pedal. 1. To disengage the Manual Park Release, apply 4. Using a screwdriver or similar tool, push the tension upward while pushing the release metal latch in towards the tether strap.
Page 248: Freeing A Stuck Vehicle
IN CASE OF EMERGENCY FREEING A STUCK VEHICLE WARNING! CAUTION! If your vehicle becomes stuck in mud, sand or Fast spinning tires can be dangerous. Forces When “rocking” a stuck vehicle by shifting  snow, it can often be moved using a rocking generated by excessive wheel speeds may between DRIVE and REVERSE, do not spin the motion.
Page 249: Towing A Disabled Vehicle
IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. If the transmission and drivetrain are operable, disabled vehicles may also be towed as described on Ú page 142. NOTE: Vehicles equipped with Quadra-Lift must be placed in Transport mode, before tying them down (from the body) on a trailer or flatbed truck Ú...
Page 250: Two-Wheel Drive Models
IN CASE OF EMERGENCY If the transmission is not operable, or the vehicle IF the transfer case is in NEUTRAL (N) and the CAUTION! must be towed faster than 30 mph (48 km/h) or transmission is in PARK Ú page 142. farther than 30 miles (48 km), tow with the rear Do not use sling type equipment when towing.
Page 251: Enhanced Accident Response System (Ears)
IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM WARNING! (EARS) Do not use a chain for freeing a stuck vehicle.  Chains may break, causing serious injury or This vehicle is equipped with an Enhanced death. Accident Response System. Stand clear of vehicles when pulling with tow ...
Page 252: Servicing And Maintenance
SERVICING AND MAINTENANCE SCHEDULED SERVICING An authorized dealer will reset the oil change Once A Month Or Before A Long Trip: indicator message after completing the scheduled Check engine oil level  Your vehicle is equipped with an automatic oil oil change.
Page 253: Maintenance Plan
SERVICING AND MAINTENANCE AINTENANCE Refer to the Maintenance Plans for required maintenance. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter.  Rotate the tires at the first sign of irregular wear, even if it occurs before the oil indicator system turns on. ...
Page 254 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, and replace if necessary. Inspect the front and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing.
Page 255 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Replace accessory drive belt. Inspect accessory drive belt tensioner and pulley, replace if necessary.
Page 256: Engine Compartment
SERVICING AND MAINTENANCE ENGINE COMPARTMENT 3.6L E NGINE 1 — Remote Jump Start Negative Terminal 6 — Brake Fluid Reservoir Cap 2 — Remote Jump Start Positive Terminal 7 — Engine Coolant Pressure Cap 3 — Power Distribution Center (Fuses) 8 —...
Page 257: Checking Oil Level
SERVICING AND MAINTENANCE HECKING EVEL CAUTION! WARNING! To ensure proper engine lubrication, the engine oil Overfilling or underfilling the crankcase will Commercially available windshield washer must be maintained at the correct level. Check the cause aeration or loss of oil pressure. This could solvents are flammable.
Page 258: Pressure Washing
SERVICING AND MAINTENANCE RESSURE ASHING WARNING! WARNING! Cleaning the engine compartment with a high You can be badly injured working on or around a Battery posts, terminals, and related accesso-  pressure washer is not recommended. motor vehicle. Only do service work for which ries contain lead and lead compounds.
Page 259: Engine Oil Filter
SERVICING AND MAINTENANCE American Petroleum Institute (API) Materials Added To Engine Oil NGINE LEANER ILTER Approved Engine Oil The manufacturer strongly recommends against For the proper maintenance intervals Ú page 251. the addition of any additives (other than leak These symbols mean that the oil has been certified NOTE: detection dyes) to the engine oil.
Page 260: Air Conditioner Maintenance
SERVICING AND MAINTENANCE Engine Air Cleaner Filter Inspection and ONDITIONER AINTENANCE Replacement For best possible performance, the air conditioner Engine Air Cleaner Filter Removal should be checked and serviced by an authorized dealer at the start of each warm season. This 1.
Page 261 SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling The cabin air filter is located in the fresh air inlet CAUTION! behind the glove compartment. Perform the R-1234yf — If Equipped following procedure to replace the filter: Do not use chemical flushes in your air R-1234yf Air Conditioning Refrigerant is a Hydroflu- conditioning system as the chemicals can 1.
Page 262: Accessory Drive Belt Inspection
SERVICING AND MAINTENANCE 3. Pull the right hand side of the glove 5. Remove the filter cover by disengaging the CAUTION! compartment door toward the rear of the retaining tab and mid way snap that secures vehicle to disengage the glove compartment the filter cover to the HVAC housing.
Page 263: Body Lubrication
SERVICING AND MAINTENANCE Conditions that would require replacement: protect against rust and wear. Prior to the WARNING! application of any lubricant, the parts concerned Rib chunking (one or more ribs has separated  should be wiped clean to remove dust and grit; You can be badly injured working on or around ...
Page 264 SERVICING AND MAINTENANCE NOTE: 1. Lift the wiper arm to raise the wiper blade off of the glass, until the wiper arm is in the full Life expectancy of wiper blades varies depending up position. on geographical area and frequency of use. If chat- tering, marks, water lines or wet spots are present, clean the wiper blades or replace as necessary.
Page 265 SERVICING AND MAINTENANCE 3. Insert the hook on the tip of the arm through the opening in the wiper blade under the release tab. 4. Slide the wiper blade up into the hook on the wiper arm and rotate the wiper blade until it is flush against the wiper arm.
Page 266: Exhaust System
SERVICING AND MAINTENANCE NOTE: without unsnapping the wiper arm pivot cap may WARNING! damage the vehicle. Resistance will be accompanied by an audible snap. Exhaust gases can injure or kill. They contain 2. Insert the wiper blade pivot pin into the ...
Page 267: Cooling System
SERVICING AND MAINTENANCE To minimize the possibility of catalytic converter CAUTION! WARNING! damage: Damage to the catalytic converter can result if When working near the radiator cooling fan,   Do not interrupt the ignition when the transmis-  your vehicle is not kept in proper operating disconnect the fan motor lead or turn the igni- sion is in gear and the vehicle is in motion.
Page 268 SERVICING AND MAINTENANCE Cooling System — Drain, Flush And Refill Do not use water alone or alcohol-based engine Material Standard MS.90032. When adding  coolant products. Do not use additional rust engine coolant: NOTE: inhibitors or antirust products, as they may not We recommend using Mopar®...
Page 269 SERVICING AND MAINTENANCE Mixing engine coolant types is not recom- Disposal Of Used Coolant Cooling System Notes  mended and can result in cooling system Used ethylene glycol-based coolant (antifreeze) is NOTE: damage. If HOAT and OAT coolant are mixed in a regulated substance requiring proper disposal.
Page 270: Brake System
SERVICING AND MAINTENANCE Fluid Level Check — Brake Master Cylinder Make sure that the coolant expansion bottle  WARNING! overflow hoses are not kinked or obstructed. The fluid level of the master cylinder should be To avoid contamination from foreign matter or Keep the front of the radiator clean.
Page 271: Automatic Transmission
SERVICING AND MAINTENANCE UTOMATIC RANSMISSION CAUTION! CAUTION! Special Additives If a transmission fluid leak occurs, visit an Using a transmission fluid other than the authorized dealer immediately. Severe manufacturer recommended fluid may cause The manufacturer strongly recommends against transmission damage may occur. An authorized deterioration in transmission shift quality and/or using any special additives in the transmission.
Page 272: Transfer Case
SERVICING AND MAINTENANCE Rear Axle Fluid Level Check Adding Fluid USES The rear axle oil level needs to be no lower than With the vehicle in a level position, fill the transfer General Information 1/8 inch (3 mm) below the bottom of the fill hole. case to bottom edge of fill plug opening.
Page 273 SERVICING AND MAINTENANCE Underhood Fuses CAUTION! The Power Distribution Center is located in the If it is necessary to wash the engine engine compartment on the passenger’s side, compartment, take care not to directly hit the directly behind the headlamp. This center contains fuse box, and the windshield wiper motors with cartridge fuses, micro fuses, relays, and circuit water.
Page 274 SERVICING AND MAINTENANCE Power Distribution Center Location Cavity Cartridge Fuse Micro Fuse Description * If Equipped – – Spare – – Spare 60 Amp Yellow – Rad Fan * – – Spare...
Page 275 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 40 Amp Green – Air Suspension Comp * 40 Amp Green – ABS Pump MTR 30 Amp Pink – Starter Solenoid – – Spare 30 Amp Pink – VAC Pump * 40 Amp Green –...
Page 276 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped 30 Amp Pink – Ft Wipers 30 Amp Pink – ESP / ECU Valves – – Spare 20 Amp Blue – TRLR Tow B/U * 20 Amp Blue –...
Page 277 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 5 Amp Tan Cyber Security Mod – – Spare – – Spare – – Spare – 10 Amp Red ICS / HVAC – 20 Amp Yellow Air Suspension MOD * / ELSD * –...
Page 278 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 25 Amp Clear Fuel Injectors / LTR Control / ECM – – Spare Sunroof * / LRSM * / RVM / DSCR / – 10 Amp Red USB Port / DTV * –...
Page 279 SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped – 10 Amp Red Fuel Door – 15 Amp Blue Cluster – 10 Amp Red ORC (Airbag) – 10 Amp Red ORC (Airbag) – 10 Amp Red Air Susp Mod * –...
Page 280: Bulb Replacement
SERVICING AND MAINTENANCE Cavity Cartridge Fuse Micro Fuse Description * If Equipped F102 – 15 Amp Blue Spare F103 – – Spare F104 – 20 Amp Yellow Pwr Out-IP / Console /TRNK EPLACEMENT Replacement Bulbs, Names, And Part Numbers In the instance a bulb needs to be replaced, this section includes bulb description and replacement part numbers. NOTE: See an authorized dealer for LED bulb replacement.
Page 281 SERVICING AND MAINTENANCE Exterior Bulbs Bulb Name Bulb Number Headlamps (Low Beam) — If Equipped Premium Headlamps (Low/High Beam) D3S (Serviced at an authorized dealer) Headlamps (High Beam) — If Equipped Premium Park/Turn Signal Lamp Premium Daytime Running Lamp (DRL) Front Fog Lamps Front Side Marker —...
Page 282 SERVICING AND MAINTENANCE Bulb Replacement HALOGEN HEADLAMPS — IF EQUIPPED NOTE: HIGH INTENSITY DISCHARGE HEADLAMPS Lens fogging can occur under certain atmospheric (HID) — IF EQUIPPED conditions. This will usually clear as atmospheric The headlamps are a type of high voltage conditions change to allow the condensation to discharge tube.
Page 283 SERVICING AND MAINTENANCE 7. Turn the low or high beam bulb a quarter turn FRONT FOG LAMPS 3. Grab the tail lamp and pull firmly rearward to counterclockwise to remove from housing. disengage the lamp from the aperture panel. Please see an authorized dealer for service on LED 8.
Page 284 SERVICING AND MAINTENANCE REAR LIFTGATE MOUNTED TAIL LAMP — IF EQUIPPED Liftgate Lower Trim Rear Of Liftgate Tail Lamp 3. Continue removing the trim. 1 — Auxiliary LED Tail Connector – Do Not Remove 2 — Backup Bulb Socket 4. Disconnect the two trim panel lights. Rear Liftgate Tail Lamps 5.
Page 285: Tires
SERVICING AND MAINTENANCE CENTER HIGH MOUNTED STOP LAMP (CHMSL) Tire Markings NOTE: P (Passenger) — Metric tire sizing is based on US The CHMSL is an LED. Service at an authorized  design standards. P-Metric tires have the letter dealer. “P”...
Page 286 SERVICING AND MAINTENANCE TIRE SIZING CHART EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
Page 287 SERVICING AND MAINTENANCE EXAMPLE: Service Description: 95 = Load Index A numerical code associated with the maximum load a tire can carry  H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions ...
Page 288 SERVICING AND MAINTENANCE Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
Page 289 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition The vehicle B-pillar is the structural member of the body located behind the B-pillar front door. Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) Cold Tire Inflation Pressure after sitting for a minimum of three hours.
Page 290 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: 1. Number of people that can be carried in the NOTE: vehicle. The proper cold tire inflation pressure is listed on the driver’s side B-pillar or the rear edge of the 2.
Page 291 SERVICING AND MAINTENANCE (4) The resulting figure equals the To determine the maximum loading conditions of Metric Example For Load Limit your vehicle, locate the statement “The combined available amount of cargo and luggage For example, if “XXX” amount equals 635 kg and weight of occupants and cargo should never load capacity.
Page 292 SERVICING AND MAINTENANCE WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them.
Page 293: Tires - General Information
SERVICING AND MAINTENANCE — G Tread Wear IRES ENERAL NFORMATION WARNING! Improper cold tire inflation pressures can cause Tire Pressure Unequal tire pressures can cause steering  abnormal wear patterns and reduced tread life, problems. You could lose control of your Proper tire inflation pressure is essential to the resulting in the need for earlier tire replacement.
Page 294 SERVICING AND MAINTENANCE Tire Pressures For High Speed Operation Radial Ply Tires Inflation pressures specified on the placard are always “cold tire inflation pressure”. Cold tire The manufacturer advocates driving at safe inflation pressure is defined as the tire pressure WARNING! speeds and within posted speed limits.
Page 295 SERVICING AND MAINTENANCE Damaged Run Flat tires, or Run Flat tires that have It is not recommended driving a vehicle loaded at Tread Wear Indicators experienced a loss of pressure should be replaced full capacity or to tow a trailer while a tire is in the Tread wear indicators are in the original equipment immediately with another Run Flat tire of identical Run Flat mode.
Page 296 SERVICING AND MAINTENANCE Life Of Tire Keep dismounted tires in a cool, dry place with as WARNING! little exposure to light as possible. Protect tires The service life of a tire is dependent upon varying from contact with oil, grease, and gasoline. Do not use a tire, wheel size, load rating, or ...
Page 297: Tire Types
SERVICING AND MAINTENANCE While studded tires improve performance on ice, YPES WARNING! skid and traction capability on wet or dry surfaces All Season Tires — If Equipped may be poorer than that of non-studded tires. Do not use Summer tires in snow/ice conditions. Some states prohibit studded tires;...
Page 298 SERVICING AND MAINTENANCE Spare Tire Matching Original Equipped Tire Collapsible Spare Tire — If Equipped Do not install a wheel cover or attempt to mount a conventional tire on the compact spare wheel, And Wheel — If Equipped The collapsible spare is for temporary emergency since the wheel is designed specifically for the use only.
Page 299: Wheel And Wheel Trim Care
SERVICING AND MAINTENANCE Limited Use Spare — If Equipped HEEL HEEL WARNING! The limited use spare tire is for temporary All wheels and wheel trim, especially aluminum Compact and Collapsible spares are for emergency use only. This tire is identified by a label and chrome plated wheels, should be cleaned temporary emergency use only.
Page 300 SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or Low CAUTION! CAUTION! Gloss Clear Coat Wheels Avoid products or automatic car washes that use Do not use scouring pads, steel wool, a bristle CAUTION! acidic solutions or strong alkaline additives or brush, metal polishes or oven cleaner.
Page 301: Snow Traction Devices
SERVICING AND MAINTENANCE RACTION EVICES Use of traction devices require sufficient tire-to-body clearance. Due to limited clearance, the following snow traction devices are recommended. Follow these recommendations to guard against damage: Snow traction device must be of proper size for the tire, as recommended by the snow traction device manufacturer. ...
Page 302: Tire Rotation Recommendations
SERVICING AND MAINTENANCE For the proper maintenance intervals Ú page 251. WARNING! CAUTION! More frequent rotation is permissible if desired. The reasons for any rapid or unusual wear should Using tires of different size and type (M+S, Do not drive for a prolonged period on dry ...
Page 303: Department Of Transportation Uniform
SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION depends upon the actual conditions of EMPERATURE RADES their use, however, and may depart UNIFORM TIRE QUALITY GRADES The Temperature grades are A (the significantly from the norm due to highest), B, and C, representing the tire's variations in driving habits, service The following tire grading categories resistance to the generation of heat and...
Page 304: Storing The Vehicle
SERVICING AND MAINTENANCE STORING THE VEHICLE The following maintenance recommendations will Do not use abrasive cleaning components, enable you to obtain maximum benefit from the solvents, steel wool or other aggressive material to If you are storing your vehicle for more than three corrosion resistance built into your vehicle.
Page 305: Interiors
SERVICING AND MAINTENANCE INTERIORS Special Care WARNING! If you drive on salted or dusty roads or if you  A frayed or torn seat belt could rip apart in a EATS ABRIC ARTS drive near the ocean, hose off the undercarriage collision and leave you with no protection.
Page 306: Leather Surfaces
SERVICING AND MAINTENANCE Cleaning Plastic Instrument Cluster NOTE: LASS URFACES If equipped with light colored leather it may show Lenses All glass surfaces should be cleaned on a regular any foreign material, dirt, and fabric dye transfer The lenses in front of the instruments in this basis with Mopar®...
Page 307: Technical Specifications
TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER (VIN) BRAKE SYSTEM WHEEL AND TIRE TORQUE SPECIFICATIONS The VIN is found on a label located on the left front Your vehicle is equipped with dual hydraulic brake Proper lug nut/bolt torque is very important to corner of the instrument panel pad, visible from systems.
Page 308: Fuel Requirements
TECHNICAL SPECIFICATIONS Inspect the wheel mounting surface prior to Poor quality gasoline can cause problems such as mounting the tire and remove any corrosion or hard starting, stalling, and hesitations. If you loose particles. experience these symptoms, try another brand of gasoline before considering service for the vehicle.
Page 309: Materials Added To Fuel
TECHNICAL SPECIFICATIONS E-85 I ATERIALS DDED ASOLINE XYGENATE LENDS EHICLES Besides using unleaded gasoline with the proper Some fuel suppliers blend unleaded gasoline with octane rating, gasolines that contain detergents, oxygenates such as ethanol. Non-Flex Fuel Vehicles (FFV) are compatible with corrosion and stability additives are gasoline containing up to 15% ethanol (E-15).
Page 310: Cng And Lp Fuel System Modifications
TECHNICAL SPECIFICATIONS CNG A LP F The MMT content of gasoline may not be YSTEM CAUTION! indicated on the gasoline pump; therefore, you ODIFICATIONS should ask your gasoline retailer whether the The use of fuel additives, which are now being ...
Page 311: Fluid Capacities
TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 3.6L Engine 24.6 Gallons 93.1 Liters Engine Oil With Filter 3.6L Engine 6 Quarts 5.6 Liters Cooling System* 3.6L Engine 10.4 Quarts 9.9 Liters * Includes heater and coolant recovery bottle filled to MAX level. ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part...
Page 312: Chassis Fluids And Lubricants
TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid or Automatic Transmission equivalent. Failure to use the correct fluid may affect the function or performance of your transmission. Transfer Case We recommend using Mopar®...
Page 313: Customer Assistance
CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE Any communication to FCA US LLC’s customer make these arrangements when you call for an appointment. center should include the following information: FOR YOUR VEHICLE Owner's name and address  IF YOU NEED ASSISTANCE Owner's telephone number (home, mobile, and ...
Page 314: Mexico
CUSTOMER ASSISTANCE Canadian residents with hearing difficulties that FCA US LLC is not responsible for any service EXICO require assistance can use the special needs relay contract you may have purchased from another Av. Prolongacion Paseo de la Reforma, 1240 service offered by Bell Canada.
Page 315: Warranty Information
CUSTOMER ASSISTANCE WARRANTY INFORMATION REPORTING SAFETY DEFECTS To contact NHTSA, you may call the Vehicle Safety Hotline toll free at See the Warranty Information for the terms and 50 U NITED TATES 1-888-327-4236 (TTY: provisions of FCA US LLC warranties applicable to , D.C.
Page 316: Publication Order Forms
CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS To access your Owner's Information online, visit Le présent appareil est conforme aux CNR www.mopar.com/om d`Innovation, Science and Economic Development (US) or To order the following manuals, you may use either applicables aux appareils radio exempts de www.owners.mopar.ca (Canada).
Page 317 INDEX ......... 208 ......61 Air Bag Light Auto Down Power Windows .........305 ... 257 ........61 About Your Brakes Air Cleaner, Engine (Engine Air Cleaner Filter) Auto Up Power Windows ......109 ......258 .......37 ACC (Adaptive Cruise Control Air Conditioner Maintenance Automatic Dimming Mirror ......109 ....
Page 318 ......230 Carbon Monoxide Warning Console ............80 ........67 ............56 Battery Cargo Area Cover Storage ......... 80 ........67 ...........57 Charging System Light Cargo Compartment Console, Overhead ....15 ..........68 ........... 312 Keyless Key Fob Replacement Cargo Tie-Downs Contract, Service ........47 ..........
Page 319 Disabled Vehicle Towing ........247 Emission Control System Maintenance ...88 Disposal Engine ............254 Filters Antifreeze (Engine Coolant) .......267 Air Cleaner ..........257 Air Cleaner ..........257 Door Ajar ........... 80 Block Heater ..........92 Air Conditioning ......55 Door Ajar Light ..........
Page 320 ...............306 Fuel ............132 ......231 .............17 Adding Hazard Warning Flashers Ignition ...........307 ..........34 ............17 Additives Head Restraints Switch ............306 ............34 ........231 Clean Air Head Rests Inside Rearview Mirror ..........95 Economy Mode Headlights Instrument Cluster ............307 ........... 302 ..........86 Ethanol Cleaning Descriptions...
Page 321 Lights ............230 Lights On Reminder ........46 Key Fob 4WD Low .............85 Low Fuel ............82 Arm The System .......... 21 Air Bag ........79 Malfunction Indicator (Check Engine) ..83 Disarm The System ........21 Air Suspension ........84 .............48 Programming Additional Key Fobs ....
Page 322 ....... 77 .............37 ..........256 Load Shed Battery Saver Mode Mirrors Oil, Engine ......77 ........37 ............ 309 Load Shed Battery Saver On Automatic Dimming Capacity ....77 ...........39 ........... 255 Load Shed Electrical Load Reduction Electric Remote Checking ....77 ..........39 .............
Page 323 Pregnant Women And Seat Belts ....205 Remote Keyless Entry ........14 Paddle Shifters ..........98 Preparation For Jacking ........ 234 Arm The Alarm ..........21 Paint Care ............302 Pretensioners Disarm The Alarm ........21 Parking Brake ..........93 Seat Belts ..........205 Programming Additional Key Fobs ....16 ParkSense Active Park Assist...
Page 324 ..........200 ..........29 ..........202 Seat Belts Seats Shoulder Belts ......204 ...........29 ......... 86 Adjustable Shoulder Belt Adjustment Signals, Turn ..204 ............33 ......299 Adjustable Upper Shoulder Anchorage Easy Entry Snow Chains (Tire Chains) ..204 ...........34 ............ 295 Adjustable Upper Shoulder Belt Anchorage Head Restraints Snow Tires ....206...
Page 325 Steering Radial ............292 Power ............106 Telescoping Steering Column ......26 Replacement ..........294 Tilt Column ..........26 Temperature Control, Automatic (ATC) .....54 Rotation ............ 300 Wheel, Heated ........26 Tie Down Hooks, Cargo ........68 Safety ..........283 Wheel, Tilt ........... 26 Tilt Steering Column ........26 Sizes...
Page 326 ..........190 Traction Control ......190 ......231 Trailer Sway Control (TSC) Uconnect Settings Warning Flashers, Hazard ..........134 .....23 Trailer Towing Customer Programmable Features Warning Lights ............137 ......23 ....82 Hitches Passive Entry Programming (Instrument Cluster Descriptions) ......139 .......36 ..........9 Minimum Requirements Uconnect Voice Command Warnings, Roll Over ............141...
Page 327 It is always the driver’s responsibility to comply with all local laws. This Owner’s Manual has been prepared to help you get acquainted with your new Jeep brand vehicle and to provide a convenient ®...
Page 328 ©2022 FCA US LLC. All Rights Reserved. Tous droits réservés. Jeep is a registered trademark of FCA US LLC. Jeep est une Second Edition V1 marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.

Jeep GRAND CHEROKEE WK 2022 Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jeep GRAND CHEROKEE WK 2022

Summary of Contents for Jeep GRAND CHEROKEE WK 2022
