UP Arrow Settings
With the unit turned off, hold the UP arrow button and simultaneously press the AUDIO
and FREQ buttons. Each successive press of the AUDIO button will step through the
setup screens.
•

Compatibility Mode

• Input Type
• RF Power Output

LCD Backlight

•
Frequency Step Size
•
Use the UP and DOWN arrow buttons to scroll through the options. The selected op-
tions will automatically be stored when the power is turned off. Press both the AUDIO
and FREQ buttons to exit the menu and turn the power off.
Note: The unit is automatically set to "standby" in this setup mode; with rF
OFF not displayed.
Compatibility Mode
• CP 400:
• CP IFb:
• CP 6:
• CP 100:
• CP 200:
• CP 3:
NOTE: If your Lectrosonics receiver does not have Nu Hybrid mode, set the receiver
to Euro Digital Hybrid Wireless® (EU Dig. Hybrid).
Input Type
• LInE:
• PH oFF:
• PH 2:
• PH 4:
The correct bias is specified by the microphone manufacturer. 4 volts is typical for most
electret lavaliere microphones. 2 volts is preferred by some mic manufacturers such as
Countryman for the very small B6 and E6 models.
RF Power Output
• Pr 50
• Pr 100
• Pr 250
NOTE: 10 mW is the only option for E02.
LCD Backlight
• bl 5
• bl 30
• bl on
Frequency Step Size
This menu item allows frequencies to be selected in either 25 kHz or 100 kHz incre-
ments. If the desired frequency ends in .025, .050 or .075 MHz, the 25 kHz step size
must be selected.
• Stp 100
• Stp 25
6
400 Series (Digital Hybrid) mode
IFB Series mode
Mode 6 (contact the factory for details)
100 Series mode
200 Series mode
Mode 3 (contact the factory for details)
Bias turned off; line level impedance
Bias turned off for dynamic mics
Bias at 2 volts for electret mics
Bias at 4 volts for electret mics
50 mW for maximum battery life
100 mW is an intermediate setting
250 mW for maximum operating range
Stay on for five minutes
Stay on for 30 seconds
Stay on continuously
Frequency steps in 100kHz increments
Frequency steps in 25 kHz increments
