- Page 1 UM200B FREQUENCY-AGILE UHF BELT-PACK TRANSMITTER OPERATING INSTRUCTIONS and trouble-shooting guide LECTROSONICS, INC. Rio Rancho, NM...
-
Page 2: Table Of Contents
A6U UHF ANTENNA .................... 13 TROUBLESHOOTING ..................14 SPECIFICATIONS AND FEATURES ..............15 SERVICE AND REPAIR ..................16 RETURNING UNITS FOR REPAIR ..............16 WARRANTY .................... Back cover The UM200B transmitter is FCC type accepted under Part 74: 470-608MHz and 614-802MHz... -
Page 3: Introduction
US. The specific concerns and needs brought up in these conversations led directly to the develop- ment of the operational features offered on the UM200B. Two hundred fifty six fre- quencies are user selectable in 100kHz steps to alleviate interference problems in travelling venues, and the low frequency roll-off is user adjustable to adapt to varying acoustic environments and preferences. -
Page 4: General Technical Description
GENERAL TECHNICAL DESCRIPTION The UM200B transmitters are comprised of a number of functional sub-systems as shown in the block diagram below. GENERAL The 200 system uses 75kHz wide deviation for an extremely high signal to noise ratio. The transmitter circuits are all regulated to allow full output power from the beginning (9 Volts) to the end (6.5 Volts) of battery life. -
Page 5: Pilot Tone Squelch
At UHF frequencies, where wavelengths and antennas are shorter than at VHF frequencies, a resonant length wire is preferred over using the microphone cable as the antenna. The antenna on the UM200B consists of a flexible 1/4 wavelength bronze cable, detachable via an SMA connector. The impedance of this connector is 50 Ohms. -
Page 6: Controls And Functions
LF ROLL OFF INPUT JACK The input on the UM200B accommodates virtually every lavalier, hand-held or shotgun microphone available. Line level signals can also be accommodated. Use a Switchcraft TA5F connector on the cord. See the separate sheet titled “Transmitter 5-Pin Input Jack Wiring” regarding the correct connections for various microphones, and other sources. -
Page 7: Modulation Leds
USE ONLY THE SCREW THAT IS SUPPLIED The circuitry is tightly packed into this unit. A longer screw will permanently damage the transmitter! Use only Lectrosonics PN:28528 which is a Phillips head, 4-40 x 3/16", FL100 screw. Rio Rancho, NM – USA... -
Page 8: Battery Installation
BATTERY INSTALLATION The transmitter is powered by a standard alkaline or lithium 9 Volt battery. It is important that you use ONLY an ALKALINE or LITHIUM battery for longest life. Standard zinc-carbon batteries marked “heavy-duty” or “long-lasting” are not adequate. Ni-cad rechargeable batteries will only provide 1.5 hours of operation, or less, and will run down quite abruptly. -
Page 9: Operating Notes
Frequency Agile UHF Belt-Pack Transmitter 7) While speaking or singing at the same voice level that will actually be used, observe the MODULATION LEDs. Adjust the AUDIO LEVEL control knob until the LEDs begin to light. Start at a low setting where neither LED lights as you speak. -
Page 10: Microphone Cord Termination
MICROPHONE CORD TERMINATION TA5F Connector Assembly VIEW FROM SOLDER SIDE OF PINS 0.15" Heatshrink Tubing 0.3" Mic Cord Stripping Instructions Caution! Do not allow the shield wire to touch any metal part of the connector shell. The shield wire is the antenna on VHF models and poor operating range will result. -
Page 11: 5-Pin Input Jack Wiring
UHF Transmitter Equivalent Input Circuit VHF transmitters use the shield of the microphone cord as the antenna. The UM200B uses a 1/4 wave flexible wire to radiate the RF signal. There is really not much difference between these two approaches, with respect to the effect of the RF on the microphone capsule. -
Page 12: Line Level Signals
Leaded capacitors: P/N 15117 Leadless capacitors: P/N SCC330P All Lectrosonics lavalier mics are already bypassed and do not need any additional capacitors installed for proper operation. BODY GROUND Caution - When wiring the connector, do not use the connector body for any electrical connections. A common mistake is to use the connector body as an audio ground. -
Page 13: A6U Uhf Antenna
Frequency Agile UHF Belt-Pack Transmitter A6U UHF ANTENNA This is a full size cutting template. Lay the actual antenna on top of this drawing and cut at the mark for the desired frequency group. Install cap on end of antenna after cutting to length. -
Page 14: Troubleshooting
*IMPORTANT TROUBLESHOOTING Before going through the following chart, be sure that you have a good battery in the transmitter. It is important that you follow these steps in the sequence listed. SYMPTOM POSSIBLE CAUSE TRANSMITTER BATTERY LED OFF 1) Battery is inserted backwards. 2) Battery is dead. -
Page 15: Specifications And Features
Frequency Agile UHF Belt-Pack Transmitter SPECIFICATIONS AND FEATURES Operating frequencies: 537.600 to 588.700 MHz 614.400 to 793.500 MHz Frequency selection: 256 frequencies in 100kHz steps RF Power output: 70 mW (nominal) Pilot tone: 32.764 kHz (± 2Hz); 5kHz deviation Frequency stability: ±... -
Page 16: Service And Repair
There are no adjustments inside that will make a malfunctioning unit start working. LECTROSONICS service department is equipped and staffed to quickly repair your equipment. In-warranty repairs are made at no charge in accordance with the terms of the warranty. Out of warranty repairs are charged at a modest flat rate plus parts and shipping. - Page 17 Frequency Agile UHF Belt-Pack Transmitter This page intentionally blank. Rio Rancho, NM – USA...
-
Page 18: Limited One Year Warranty
This warranty applies only to items returned to us, shipping costs prepaid, within one year from the date of purchase. This warranty gives you specific legal rights. You may have additional legal rights which vary from state to state. LECTROSONICS, INC. 581 LASER ROAD RIO RANCHO, NM 87124 USA June 21, 2000...
