Signal Level
Less than -20 dB
-20 dB to -10 dB
-10 dB to +0 dB
+0 dB to +10 dB
Greater than +10 db
AUDIO Button
The AUDIO button is used to display the gain and low frequency roll-off settings. The
UP and DOWN arrows adjust the values. This button is also used with the FREQ button
to enter standby mode and to power the transmitter on or off.
FREQ Button
The FREQ button displays the selected operating frequency and also toggles the LCD
between displaying the actual operating frequency in MHz and a two-digit hexadecimal
number that corresponds to the equivalent Lectrosonics Frequency Switch Setting.
This button is also used with the AUDIO button to enter standby mode and to power the
transmitter on or off.
Up/Down Arrows
The Up and Down arrow buttons are used to select the values on the various setup
screens and to lock out the control panel. Pressing both arrows simultaneously enters
the lock countdown. When an attempt is made to change a setting while the control
panel is locked, a message will flash on the LCD as a reminder that the unit is locked.
Once locked, the buttons can only be unlocked by removing the batteries, or with the
RM remote control.
Antenna
The fixed whip antenna is made of a flexible, woven, galvanized steel mesh cable.
www.lectrosonics.com
-20 LED -10 LED
Off Off
Green Off
Green Green
Red Green
Red Red
