Cable and Wire Length
Guidelines
Table 4: Cable Length Guidelines for Recommended Wire Sizes for Low-Voltage (<30V) Inputs and Outputs
Guideline Wire Size/Gauge and Type
A 2
1.5 mm (18 AWG) stranded copper
0.8 mm (20 AWG) stranded copper
0.6 mm (22 AWG) stranded copper
N/A (24 AWG) stranded copper
B 2
1.5 mm (18 AWG) stranded copper
0.8 mm (20 AWG) stranded copper
0.6 mm (22 AWG) stranded copper
N/A (24 AWG) stranded copper
C See Figure 8 to select wire size/gauge.
Use stranded copper wire
Maximum Cable Length versus
Load Current
Use Figure 8 to estimate the maximum cable length
relative to the wire size and the load current (in mA) when
wiring inputs and outputs.
Figure 8: Maximum Wire Length for Low-Voltage (<30V) Inputs and Outputs by Current and Wire Size
FEC26Field Equipment Controllers Installation Instructions
All manuals and user guides at all-guides.com
Table 4
wire sizes that may be used for wiring low-voltage (<30V)
input and outputs.
Maximum Cable
Length and Type
457 m (1,500 ft) twisted
wire
297 m (975 ft) twisted wire
183 m (600 ft) twisted wire
107 m (350 ft) twisted wire
229 m (750 ft) twisted wire
137 m (450 ft) twisted wire
91 m (300 ft) twisted wire
61 m (200 ft) twisted wire
See Figure 8
cable length. Use twisted
wire cable.
Note:
defines cable length guidelines for the various
Assumptions
100 mV maximum voltage drop
Depending on cable and the connected input
or output device, you may have to define an
offset in the setup software for the input or
output point.
100 mV maximum voltage drop
Depending on cable and the connected input
or output device, you may have to define an
offset in the setup software for the input or
output point.
to determine N/A
Figure 8 applies to low-voltage (<30V) inputs and
outputs only.
