Table 3: FEC26 Terminal Blocks, Functions, Ratings, Requirements, and Cables
Terminal Block Label
CONFIGURABLE
(Outputs)
FEC26Field Equipment Controllers Installation Instructions
All manuals and user guides at all-guides.com
Terminal Label
OUTn
OCOMn
Function, Ratings,
Requirements
Analog Output - Voltage
Mode (0–10 VDC)
10 VDC maximum output
voltage
10 mA maximum output current
Required an external load of
1,000 ohms or more.
Binary Output - 24 VAC Triac
(External Power Source only)
Connects OUTn to OCOMn
when activated.
External Power Source
Requirements:
30 VAC maximum output
voltage
0.5 A maximum output current
1.3 A at 25% duty cycle
40 mA minimum load current
Analog Output Signal
Common All Configurable
Outputs (COs) defined as
Analog Outputs (AOs) share a
common, which is isolated from
all other commons except the
Binary Input common.
Binary Output Signal
Common All Configurable
Outputs (COs) defined as
Binary Outputs are isolated
from all other commons,
including other CO commons.
Determine Wire Size and
Maximum Cable Length
See Guideline A in Table 4.
See Guideline C in Table 4.
Same as (Configurable) OUTn.
