Table 2: Termination Details
Type of Field Device Type of
Input/Output
Network Stat with SA Bus
Terminals Addressable
Network Stat with SA Bus
Terminals (Fixed
Address = 199)
Terminal Wiring Guidelines,
Functions, Ratings, and
Requirements

Input and Output Wiring Guidelines

Table 1 provides information and guidelines about the
functions, ratings, and requirements for the controller
input and output terminals; and references guidelines for
determining proper wire sizes and cable lengths.
In addition to the wiring guidelines in
these guidelines when wiring controller inputs and
outputs:
• Run all low-voltage wiring and cables separate from
high-voltage wiring.
• All input and output cables, regardless of wire size or
number of wires, should consist of stranded, insulated,
and twisted copper wires.
• Shielded cable is not required for input or output
cables.
• Shielded cable is recommended for input and output
cables that are exposed to high electromagnetic or
radio frequency noise.
• Inputs/outputs with cables less than 30 m (100 ft)
typically do not require an offset in the software setup.
FEC26Field Equipment Controllers Installation Instructions
All manuals and user guides at all-guides.com
Termination Diagrams
FEC2511 and FEC26 Series Point Type
Counts per Model
Table 3
available in the FEC2511 and FEC26 Series controllers.
Field Equipment Controller (FEC)2511 and FEC26 Series
Point Type Counts per Model
Table 1, observe
Cable runs over 30 m (100 ft) may require an offset
in the input/output software setup.
shows the different point types and counts
