FEU16x0 Field Equipment Controller
Installation Instructions
MS-FEU1610-0U
Applications
The FEU16x0 Controller is a member of the Metasys® system Field Equipment Controller (FEC) family. The
controller is designed exclusively for use in a Metasys Release 8.1 smoke control application that is UL 864 UUKL/
UUKLC 10th Edition Smoke Control Listed. For Metasys system smoke control applications, you must refer to the
Metasys® System UL 864 10th Edition UUKL/ORD-C100-13 UUKLC Smoke Control System (LIT-12012487) for
detailed requirements and procedures for installing, commissioning, and operating UL 864 UUKL/UUKLC Listed
Metasys system devices. For example, the MS-FEU1610-0U can only be used with the Firefighters Smoke Control
Station (FSCS) panel manufactured by Automation Displays, Inc. (ADI). The UL 864 UUKL/UUKLC listing for
Smoke Control Equipment is voided if (1) you do not use the required software tools at the required versions; or (2)
you do not meet the requirements or do not follow the procedures as documented in the Metasys® System UL 864
10th Edition UUKL/ORD-C100-13 UUKLC Smoke Control System Technical Bulletin (LIT-12012487).
North American Emissions Compliance
Canada
This Class (A) digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la Classe (A) respecte toutes les exigences du Règlement sur le matériel brouilleur
du Canada.
United States
This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when this equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be required to correct the interference at his/her
own expense.
Installation
Observe these guidelines when installing the FEU controller:
•
Transport the controller in the original container to minimize vibration and shock damage to the controller.
•
Verify that all parts shipped with the controller.
•
Do not drop the controller or subject it to physical shock.
Parts Included
•
one MS-FEU1610-0U Controller with removable Terminal Plugs
•
one Installation Instructions sheet
Materials and Special Tools Needed
•
three fasteners appropriate for the mounting surface (#8 screws or M4 screws)
FEU16x0 Field Equipment Controller Installation Instructions
Part No. 24-10143-535, Rev. B
1
Release 8.1
Issued March 2018
Advertisement
Table of Contents
Related Manuals for Johnson Controls Metasys MS-FEU1610-0U
Summary of Contents for Johnson Controls Metasys MS-FEU1610-0U
- Page 1 FEU16x0 Field Equipment Controller Installation Instructions MS-FEU1610-0U Part No. 24-10143-535, Rev. B Release 8.1 Issued March 2018 Applications The FEU16x0 Controller is a member of the Metasys® system Field Equipment Controller (FEC) family. The controller is designed exclusively for use in a Metasys Release 8.1 smoke control application that is UL 864 UUKL/ UUKLC 10th Edition Smoke Control Listed.
- Page 2 • one 15.2 cm (6 in.) or longer piece of DIN rail and appropriate hardware for mounting the DIN rail • small straight blade screwdriver for securing communication wires in the terminal blocks • one phone jack splitter (optional) Figure 1: FEU16 Controller Physical Features and Wiring Terminals FEU16x0 Field Equipment Controller Installation Instructions...
-
Page 3: Wall Mount Applications
Mounting Observe these guidelines when mounting a field controller: • Ensure the mounting surface can support the controller, DIN rail, and any user-supplied enclosure. • Mount the controller horizontally on 35 mm DIN rail whenever possible. • Mount the controller in the proper orientation. If wall mount applications are not allowed for the FEU1610-0U, then proper mounting position will only be as shown in Figure •... -
Page 4: Hard-Wired Installation
3. Hand the controller by the hooks at the top of the DIN rail channel on the back of the controller, and position the controller snugly against the DIN rail. 4. Push the bottom mounting clips inward (up) to secure the controller on the DIN rail tracks. To remove the controller from the DIN rail, pull the bottom mounting clips out to the extended position and carefully lift the controller off the DIN rail. - Page 5 Figure 3: SA Bus Terminal Block Wiring FC Bus Terminal Block Wire the Field Controller (FC) Bus in a daisy chain to other devices on the FC Bus and the supervisory controller (Figure Figure 4: FC Bus Terminal Block Wiring Note: The Shield terminal (SHLD) on the FC Bus terminal block is isolated and can be used as a convenient terminal for connecting the bus cable shield (Figure...
-
Page 6: Supply Power Terminal Block
Figure 6: 24 VAC Supply Power Terminal Block Wiring Supply Power Terminal Block 24V~ Supply Power Terminal Block Plug Wires from Johnson Controls 24 VAC, Class 2 Power Transformer Brown Wire Orange Wire (COM) (24 VAC) FEU16x0 Field Equipment Controller Installation Instructions... - Page 7 <30 m (90 ft) Internal 12 V, 15k ohm Pullup Table 2 (See Row A in RTD (1k Nickel [Johnson Controls], 1k Platinum, A99B Silicon Temperature Sensor) Negative Temperature Coefficient (NTC) Sensor (10k Type L, 2.252k Type 2) Binary Input, Dry Contact Maintained Mode 0.6 mm (22 AWG) stranded, 2-wire...
- Page 8 Table 1: FEC Terminal Blocks, Functions, Ratings, Requirements, and Cables (Part 2 of 3) Terminal Terminal Function and Electrical Ratings/Requirements Recommended Cable Type Block Labels and Length Binary OUT OUT n Binary Output, 24 VAC Triac 0.6 mm (22 AWG) stranded, 2-wire (Jumper set twisted, non-shielded cable for Connects OUT to OCOM when activated...
- Page 9 Table 1: FEC Terminal Blocks, Functions, Ratings, Requirements, and Cables (Part 3 of 3) Terminal Terminal Function and Electrical Ratings/Requirements Recommended Cable Type Block Labels and Length 24~ Power AC Supply Input 0.8 mm to 1.0 mm (20 to 18 AWG) 2-wire Supply 20-30 VAC (Nominal 24 VAC) SHLD Provides an optional shield connection.
-
Page 10: Setup And Adjustments
Wiring Requirements Figure 7 to determine the maximum wire length allowable when alternative wire gauges are required. Figure 7: Maximum Wire Length by Current and Wire Size Length 137.2 m (450 ft) 121.9 m (400 ft) 106.7 m (350 ft) 1.0 mm (18 AWG) 91.4 m (300 ft) 76.2 m (250 ft) - Page 11 Setting the FC Bus Address Set the address of the FEU16 using the DIP switches on the face of the FEU16. The address equals the sum of the numbers set to ON. For example, if the first (1), the third (4), and the fifth (16) DIP switches are set to ON, the device address is 21 (1 + 4 + 16 = 21).
-
Page 12: Troubleshooting
Commissioning Commission the controller with the Controller Configuration Tool (CCT), either through the BTCVT or in passthrough mode when connected via a Network Application Engine (NAE) or Network Control Engine (NCE). Refer to CCT Help. Troubleshooting Table 4 to troubleshoot the controller. Table 4: Status LEDs Name Color... -
Page 13: Repair Information
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these specifications, consult the local Johnson Controls office. Johnson Controls shall not be liable for damages resulting from misapplication or misuse of its products. - Page 14 507 E. Michigan Street, Milwaukee, WI 53202 Metasys® and Johnson Controls® are registered trademarks of Johnson Controls. All other marks herein are the marks of their respective owners. © 2018 Johnson Controls. FEU16x0 Field Equipment Controller Installation Instructions Published in U.S.A.
