TASKING iSYSTEM RH850 User Manual page 11

The following pinout is valid on the Active Probe side:
Signal Signal
Direction Description
I AGBT TX0_P
I AGBT TX0_N
Ground
Ground
Ground
Ground
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Signal Direction is described from the BlueBox perspective.
Signal Pin
TX0_P 1
TX0_N 3
GND 5
Reserved 7
Reserved 9
GND 11
Reserved 13
Reserved 15
GND 17
Reserved 19
Reserved 21
GND 23
NC 25
NC 27
GND 29
NC 31
NC 33
34-pin RH850 Aurora pinout
Pin Signal
2 Vref
4 LPDCLK
6 TMS
8 LPDI
10 LPDO
12 nTRST
14 FLMD0
16 nEVTI
18 nEVTO
20 FLMD1
22 nRESET
24 GND
26 CLK_P
28 CLK_N
30 GND
32 LPDCLKOUT
34 WDGDIS
Signal
SignalDirection
Description
Reference I
Voltage
Debug Clock O
JTAG O
Debug Signal O
Debug Signal I
Debug Signal O
Flash Mode O
Nexus Event O
Input
Nexus Event I
Output
Flash Mode
Reset I/O
Ground
AGBT Clock_P O
AGBT Clock_N O
Ground
Debug Clock I
Watchdog O
disable
