Test Data and Performance Curves

3.2 Waveforms

CH 1 ( VIN )
CH 2 ( VOUT )
CH 3 ( PG )
Figure 3-5. Start-Up to V

Figure 3-7. Enable ON and OFF

F = 1 MHz I
SW OUT
Figure 3-9. Infrared Thermal Image V
8 TLVM13610EVM Buck Regulator Evaluation Module
= 24 V
IN
= 8 A P = 3.49 W
DIS
= 12 V, V
IN
= 5 V
Copyright © 2023 Texas Instruments Incorporated

Figure 3-6. Shutdown

CH 4 ( IOUT )
CH 3 ( VOUT )
Figure 3-8. Load Transient, 4 A to 8 A at 1 A/µs
F = 1 MHz
SW
Figure 3-10. Infrared Thermal Image V
OUT
www.ti.com
I = 8 A P = 4.06 W
OUT DIS
= 24 V,
IN
V = 5 V
OUT
