TLV320AIC12KEVM-K and TLV320AIC14KEVM-K User's
This user's guide describes the characteristics, operation, and use of evaluation modules
TLV320AIC12KEVM and TLV320AIC14KEVM, both as stand-alone and as kits (TLV320AIC12KEVM-K
and TLV320AIC14KEVM-K). This EVM is a complete audio codec with several analog audio inputs and
outputs. A complete circuit description, schematic diagram and bill of materials are also included.
The following related documents are available through the Texas Instruments web site at www.ti.com.
1
2
3
4
5
6
7
EVM Bill of Materials
Appendix A
TLV320AIC12KEVM/14KEVM Schematic
Appendix B
USB-MODEVM Schematic
1
2
Default Software Screen
3
Information Tab
4
Sounds and Audio Devices Properties
5
Preset Configurations
6
Device Controls Tab
7
Control Register 1 Tab
8
Control Register 2 Tab
9
Control Register 3 Tab
10
Control Register 4 Tab
11
Control Register 5 Tab
12
Control Register 6 Tab
SMARTDM is a trademark of Texas Instruments.
2
I
C is a trademark of Koninklijke Philips Electronics N.V.
Windows is a registered trademark of Microsoft Corporation.
LabView is a trademark of National Instruments.
SLAU229A - October 2007 - Revised June 2008
Submit Documentation Feedback
EVM-Compatible Device Data Sheets
Device
TLV320AIC12K/14K
TAS1020B
REG1117-3.3
TPS767D318
SN74LVC125A
SN74LVC1G125
SN74LVC1G07
...............................................................................................................
..............................................................................................................
..............................................................................................................
..............................................................................................................
...............................................................................................................
.................................................................................................................
.......................................................................................................
......................................................................................
..................................................................................................
.............................................................................................................
..................................................................................
......................................................................................................
.......................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
SLAU229A - October 2007 - Revised June 2008
Literature Number
SLWS115E
SLES025
SBVS001
SLVS209
SCAS290
SCES223
SCES296
Contents
.....................................................................
List of Figures
.....................................................................
TLV320AIC12KEVM-K and TLV320AIC14KEVM-K User's Guide
User's Guide
Guide
3
3
4
6
6
7
29
32
33
8
10
12
13
14
15
16
17
17
18
18
19
1
