Instructions
Code
Data display contents
No.
C36
Relay output
C37
Relay output
C38
Relay output
C39
Relay output
C40
Relay output/external output
C41
External output
(*1) 7 segment display of C24, C25 indicates 10 min
(*2) When the pulse input is set, 0 and 1 are switched if it changes Open→Short.
(*3) 0: OLS OFF (No oil), 1: OLS ON (With oil)
<Unit information>
C44
Compressor total operation time (CM1)
C46
Medium pressure saturation temp.
C47
Suction pressure saturation temp.
C48
Subcooling coil temp. sensor 1 saturation pressure
C49
Suction superheat degree 1
C51
Subcooling coil superheat degree
C52
Under-dome superheat degree 1
Compressor total operation time after previous
C54
maintenance (CM1)
C61
Demand rate display
(*1) 7 segment display of C44, C54 indicates 100 h/count.
<Control status>
C66
Control status
C67
Protective control status
C68
Cause of compressor stop
C73
Cause of compressor error detection 1
C74
Cause of compressor error detection 2
C75
Cause of compressor error detection 3
© Danfoss | Climate Solutions | 2023.02 | LCA012A024
Data
display
Min. unit
range
0, 1
(0: Open
1: Short)
0, 1
(0: Open
1: Short)
0, 1
(0: Open
1: Short)
0, 1
(0: Open
1: Short)
0, 1
(0: Open
1: Short)
0, 1
(0: Open
1: Short)
-1
/count.
0~655
1(100h)
(*1)
-50~30
0.1°C
-50~30
0.1°C
0~8.5
0.1 bar
0~50
0.1deg
0~50
0.1deg
0~50
0.1deg
0~655
1(100h)
(*1)
0~100
0~127
0~127
0~127
0~127
0~127
0~127
100's place: Crankcase heater 1
10's place: Spare
1's place: Spare
100's place: Cooling fan
10's place: Ventilation fan
1's place: Spare
100's place: SVHG1
10's place: Spare
1's place: SV-INJ1
100's place: Spare
10's place: Spare
1's place: SV-OIL1-2
100's place: Spare
10's place: Spare
1's place: External output (CNZ1)
100's place: External output (CNZ2)
10's place: Operation output (CNH)
1's place: Error output (CNY)
In the unit of 1°C in the range beyond display (-10°C
or under)
In the unit of 1°C in the range beyond display (-10°C
or under)
1%
1
Digital→Analog display
1
Digital→Analog display
1
Displays No. of error detection, which occurred
most frequently, out of error detections occurred
after turning power on and starting operation.
1
This is retained in EEPROM memory till the cause of
compressor stop by first error occurs after turning
power on.
Displays No. of error detection, which occurred at
second place frequently, out of error detections
occurred after turning power on and starting
1
operation.
This is retained in EEPROM memory till the cause of
compressor stop by first error occurs after turning
power on.
Displays No. of error detection, which occurred
at third place frequently, out of error detections
occurred after turning power on and starting
1
operation.
This is retained in EEPROM memory till the cause of
compressor stop by first error occurs after turning
power on.
118A5495A - AN405821998738en-000102 | 27
Remarks
