Instructions
Condensing Units
Optyma™ Integral range
Designation system for the Optyma™ Integral range
OP - LCQN 048 MT A02 E
1 2 3 4 5
OP - Optyma™
1 Application: M = Medium Back Pressure ; L = Low Back Pressure
Platform:
2 C: Air cooled condensing unit with single fan
G: Air cooled condensing unit with dual fan
Refrigerant:
3 R: R134a, R404A/R507, R407C, R407A, R407F, R448A, R449A, R452A;
Q: R452A, R404A/R507
Condenser design:
4
N: Microchannel condenser, ambient temperature up to 46°C
5 Compressor displacement: Example 068 = 68 cm3
Reciprocating compressor platform:
6
NT = NTZ, MT = MTZ
7 Version: A14 (See version table below)
Electrical code:
8 G: Compressor 230V/1P/50Hz, fan 230V/1P/50Hz
E: Compressor 400V/3P/50Hz, fan 230V/1P/50Hz
H
X
D
Danfoss | Climate Solutions (CU) | 2022.07
6 7 8
MBP application
50 Hz
OP-MCRN038
OP-MCRN048
OP-MCRN060
OP-MCRN086
OP-MCRN096
OP-MCRN108
LBP application
Y
OP-LCQN068
OP-LCQN108
W
OP-LCQN136
OP-LGQN096
OP-LGQN215
Version Information
Specifications
Version
Compressor technology
Microchannel condenser
Filter drier (Solder connections)
Sight glass (Solder connections)
Crankcase heater
HP/LP adjustable Pressure switch
Electrical Box design
Liquid Receiver
Contactor
Overload Relay
Fuses (fan motor, control circuit)
Compressor
MTZ022
MTZ028
MTZ036
MTZ050
MTZ056
MTZ064
50 Hz Compressor
NTZ068
NTZ108
NTZ136
NTZ096
NTZ215
www.danfoss.com

Optyma™
A14
Reciprocating (MTZ & NTZ)
Yes (Up to 46°C Ambient)
Yes
Yes
Yes
Yes
LP – Auto reset,
HP – Manual reset (convertible)
IP54
Yes (with Rotolock connection)
Yes
Yes
Yes
H W D
(mm) (mm) (mm) (mm)
545 900 900 600
705 900 900 600
836.5 1200 800 500
H W D
(mm) (mm) (mm) (mm)
705 900 900 600
836.5 1200 800 500
693.5 1500 870 580
836.5 1500 870 580
Optyma™
by Danfoss
118U5272 - AN368656896297en-AU0102 | 1
X Y
(mm)
865
865
1165
X Y
(mm)
865
1165
1465
1465
