MAX25460 Evaluation Kit
MAX25460 EV Kit Bill of Materials
QTY REFERENCE
1 C1
1 C2
6 C3, C4, C12, C16, C18, C20
1 C5
1 C7
2 C8, C17
1 C15
2 D1, D3
1 D2
1 DS1
2 FB1, FB2
5 GND_1, GND_2, USB_5V, VBAT, VBAT_FLT
1 HOST_VBUS
1 J1
1 J2
1 J3
1 L5
1 MOD1
1 R1
6 L1, L2, L4, L6, R2, R6
4 R8-R11
4 R12, R17, R18, R21
2 R13, R14
2 R15, R16
1 R20
1 SW1
1 U1
1 U2
1 PCB
