- Page 1 PCAN-USB Pro FD User Manual User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 2: Imprint
IPEH-004061 Imprint PCAN and PLIN are registered trademarks of PEAK-System Technik GmbH. CiA® is a registered community trade mark of CAN in Automation e.V. All other product names in this document may be the trademarks or registered trademarks of their respective companies. -
Page 3: Table Of Contents
5.1 Initialize CAN interface 5.2 Transmit CAN message 5.3 Additional Tabs 6 API PCAN-Basic 6.1 Features of PCAN-Basic 6.2 Principle Description of the API 7 LIN Monitor PLIN-View Pro 7.1 Features 7.2 Start and Initialize PLIN-View Pro Contents PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... - Page 4 7.7 LIN Interface Tab 8 PLIN-API 8.1 Features 9 Technical Data Appendix A CE Certificate Appendix B UKCA Certificate Appendix C Dimension Drawings Appendix D Quick Reference Appendix E Linux Appendix F Disposal Contents PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 5: Introduction
CAN device drivers and application information for Linux: www.peak-system.com/quick/DL-Driver-E At the end of this manual you can find a Quick Reference with brief information about the installation and operation of the interface. 1 Introduction PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 6: Properties At A Glance
CAN termination can be activated through solder jumpers, separately for each ■ CAN channel Measurement of bus load including error frames and overload frames on the ■ physical bus Induced error generation for incoming and outgoing CAN messages ■ 1 Introduction PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 7: System Requirements
USB port (USB 1.1, USB 2.0, or USB 3.0) or ■ a vacant USB port at a self-powered USB hub ■ Per channel a supply voltage between 8 and 18 V for the LIN transceiver 1 Introduction PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 8: Scope Of Supply
Programming interface PLIN-API for developing applications with LIN ■ connection Programming interfaces for standardized protocols from the automotive sector ■ Manual in PDF format ■ Optional accessories Pre-configured cable set for PCAN-USB Pro FD and PLIN-USB (IPEK-003013) 1 Introduction PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 9: Configuration
Risk of short circuit! Soldering on the interface may only be performed by qualified electrical engineering personnel. Attention! Electrostatic discharge (ESD) can damage or destroy components on the card. Take precautions to avoid ESD. 2 Configuration PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 10: Open The Casing
Close interface 1. Slide the circuit board back into the lower part of the casing. 2. Close the casing cover. 3. Tighten the screws at the front and back side. 2 Configuration PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 11: Voltage Supply Of External Devices
Set the solder bridge(s) according to the desired configuration. D-Sub connector Solder field 5-Volt supply at Pin 1 Without Active (Standard) CAN 1 5V ext. CAN 2 5V ext. 2 Configuration PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... - Page 12 For PCAN-USB Pro FD to S/N 24547 Set the solder bridge(s) according to the desired configuration. D-Sub connector Solder field 5-Volt supply at Pin 1 Without Active (Standard) CAN 1 CAN 2 2 Configuration PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 13: Internal Termination
For PCAN-USB Pro FD from S/N 24548 Set the solder bridges corresponding to the desired settings. D-Sub connector Solder field Termination Without Active (Standard) CAN 1 Term. CAN 2 Term. 2 Configuration PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... - Page 14 For PCAN-USB Pro FD to S/N 24548 Set the solder bridges corresponding to the desired settings. D-Sub connector Solder field Termination Without Active (Standard) CAN 1 JP1 and JP2 CAN 2 JP5 and JP6 2 Configuration PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 15: Installation
Install the driver package before you connect the PCAN-USB Pro FD. 3.1 Install Device Driver Setup 1. Download the device driver setup from our website: www.peak-system.com/quick/DL-Driver-E 2. Unpack the file PEAK-System_Driver-Setup.zip 3. Double-click the file PeakOemDrv.exe The driver setup starts. 4. Confirm the Start and the License agreements. -
Page 16: Connection
2. Check the LEDs on the interface. If the LED „USB“ is blinking and the other LEDs light up green, the driver was initialized successfully. 3.3 Check Operational Readiness 1. Open the Windows Start menu. 2. Type Peak Settings and press |Enter|. The window PEAK-Settings appears. 3. Select CAN Hardware. The connected CAN interface is displayed. -
Page 17: Can Cabling
CAN_High Not assigned LIN_V PEAK System offers a pre-configured LIN connection cable (IPEK-003013), wich allows the tapping of individual lines. The LIN and the supply lines are lead directly out to separate plugs and the CAN lines are forwarded to a D-Sub plug. -
Page 18: Example Application Under Windows
3.6 Example Application under Windows As an example application for accessing the interface, run the CAN monitor PCAN-View and/or the LIN monitor PLIN-View Pro from the Windows Start menu. 3 Installation PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 19: Operation
The LIN channel is initialized with a valid bit Green slow blinking rate. A software application is connected to the LIN channel. Data is transmitted via the connected LIN bus. Green quick blinking 4 Operation PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 20: Unplugging The Usb Connection
2. Enter a hexadecimal number with suffix “h” as the new hardware ID. 3. Confirm the entry with Set. PEAK-Settings To set the device ID in PEAK-Settings: 1. Click on CAN Hardware or LIN Hardware. The connected hardware is displayed. 2. Enter a hexadecimal number with suffix “h” as the new hardware ID. -
Page 21: Can Monitor Pcan-View
In the following the initialization of a CAN interface is described as an example. Detailed information about using PCAN-View can be found in the program window under the menu item Help. 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 22: Initialize Can Interface
Depending on the CAN interface the Connect dialog is displayed with or without settings for CAN FD. CAN FD CAN interface List entry in Available Hardware USB Interface, 1-channel see example above USB Interface, 2-channel PCIe Interface, 2-channel 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... - Page 23 4. Confirm the entries with OK. The main window appears and displays the Receive / Transmit tab. 5. For initializing another channel or CAN interface, open another instance of PCAN-View. 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 24: Transmit Can Message
4. To send the message manually, select the menu command Transmit > Send or press the |space| bar. The manual transmission process is performed additionally for periodically transmitted CAN messages. 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 25: Additional Tabs
5.3.1 Trace Tab The tracer (data logger) records the communication of the CAN bus in linear or ring buffer mode. The trace data can be saved to a file. 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... - Page 26 For interfaces with CAN FD a transmission according to "ISO" or "Non-ISO" can be set as default of the hardware. 5.3.3 Bus Load Tab 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
- Page 27 The Bus Load tab displays the current bus load, its time history and statistical information of the connected CAN channel. 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
- Page 28 You can destroy CAN frames with the error generator by one of two methods: once after activation ■ repeatedly at specific intervals related to a CAN ID ■ 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
- Page 29 4. Determine the Number of Frames to destroy. 5. Confirm the entries with Apply to activate the error generator. 6. Stop destroying further CAN frames with Disable. 5 CAN Monitor PCAN-View PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 30: Api Pcan-Basic
The programming interface (API) PCAN-Basic provides basic functions for the connection of own programs to the CAN and CAN FD Interfaces of PEAK-System. PCAN-Basic is the interface between the program and the device driver. In Windows operating systems this is a DLL (Dynamic Link Library) and in Linux operating systems an SO (Dynamic Shared Object). -
Page 31: Features Of Pcan-Basic
Use of a single DLL for all supported hardware types ■ Use of up to 16 channels for each hardware type (depending on the PEAK CAN ■ interface used) Simple switching between channels of a PEAK CAN interface ■... -
Page 32: Principle Description Of The Api
To end the communication the function CAN_Uninitialize is called in order to release the reserved resources for the CAN channel, among others. In addition the CAN channel is marked as "Free" and is available to other applications. 6 API PCAN-Basic PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 33: Lin Monitor Plin-View Pro
In the following the initialization of a LIN interface is described as an example. Detailed information on the use of PLIN-View Pro can be found in the program window under the menu item Help. 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 34: Features
Integrated text editor for C# with syntax highlighting ■ Separate views for: ■ Transmit and Receive ■ Trace (data logger) ■ Scripting ■ Connected LIN interface ■ 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 35: Start And Initialize Plin-View Pro
2. If there are several LIN interfaces, select the desired interface. If there are several channels, select the desired channel from the list. 3. Determine the operation Mode to be used for the LIN connection. 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... - Page 36 Bit rate detection as master. Bit rate detection as slave. 5. Confirm the settings with OK. 6. Optional: To initialize another channel or LIN interface, open another instance of PLIN-View Pro. 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 37: Receive / Transmit Tab
Properties window. 7.4 Transmit a LIN Frame Depending on the customer's requirements, different scenarios for sending LIN frames are possible. 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... - Page 38 Note: In the following example, a frame is sent manually from a master as publisher without a scheduler. For automated sending, further expertise in configuring LIN frames and at least one additional LIN node are required. 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
- Page 39 |Space bar|. The message is sent on the LIN bus and appears in the Receive window. „1" for Transmit and Receive is displayed in the Count column. 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 40: Trace Tab
Newly recorded LIN frames are appended to the bottom of the list. Depending on the selected setting, recording is done temporarily or directly to a file. 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 41: Scripting Tab
C# assemblies can optionally be included via the menu Tools > Options > Tab References > Assemblies. For more details open the Help with the key |F1|. 7 LIN Monitor PLIN-View Pro PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 42: Lin Interface Tab
The LIN Interface tab receives the name of the connected hardware and shows information about the hardware and the firmware used. In this example for the interface PCAN-USB Pro FD. To distinguish several LIN interfaces of the same type, the Hardware ID of the LIN interface can be determined here. -
Page 43: Plin-Api
The programming interface PLIN-API provides basic functions for the connection of own programs to the LIN hardware of PEAK-System. PLIN-API is the interface between the program and the device driver. In Windows operating systems this is a DLL (Dynamic Link Library). -
Page 44: Features
Notification of the application through Windows events when a message is ■ received and on plug-in or plug-out of a device Function to get error code descriptions in 4 languages ■ 8 PLIN-API PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 45: Technical Data
Initiated by software, processing by hardware Scheduler 8 schedule tables with a total of 256 slots configurable Galvanic isolation up to 500 V against USB and CAN, no isolation between LIN channels 9 Technical Data PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... - Page 46 15 to 90 %, not condensing Ingress protection IP20 (IEC 60529) Conformity Directive 2011/65/EU (RoHS 2) + 2015/863/EU RoHS DIN EN IEC 63000:2019-05 Directive 2014/30/EU DIN EN 55032:2022-08 DIN EN 55035:2018-04 9 Technical Data PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 47: Appendix Ace Certificate
German version of EN 55032:2015 + AC:2016 + A11:2020 + A1:2020 DIN EN 55035:2018-04 Electromagnetic compatibility of multimedia equipment - Immunity requirements (CISPR 35:2016, modified); German version of EN 55035:2017 Darmstadt, 19 January 2023 Uwe Wilhelm, Managing Director Appendix A CE Certificate PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 48: Appendix B Ukca Certificate
German version of EN 55032:2015 + AC:2016 + A11:2020 + A1:2020 DIN EN 55035:2018-04 Electromagnetic compatibility of multimedia equipment - Immunity requirements (CISPR 35:2016, modified); German version of EN 55035:2017 Darmstadt, 19 January 2023 Uwe Wilhelm, Managing Director Appendix B UKCA Certificate PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 49: Appendix C Dimension Drawings
Appendix C Dimension Drawings Appendix C Dimension Drawings PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH... -
Page 50: Appendix D Quick Reference
Windows and the driver is initialized. The LED „USB“ on the interface then lights up green. Check the operational readiness. Open the Windows Start menu. Type Peak Settings and press |Enter|. The window PEAK Settings appears. The connected CAN interface is displayed under CAN Hardware. - Page 51 The LIN channel is initialized with a valid bit Green slow blinking rate. A software application is connected to the LIN channel. Data is transmitted via the connected LIN bus. Green quick blinking Appendix D Quick Reference PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
- Page 52 D-Sub assignment Assignment D-Sub socket CAN_V+ (external, optional) CAN_Low CAN_GND LIN_GND LIN_GND CAN_High Not assigned LIN_V Appendix D Quick Reference PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
-
Page 53: Appendix E Linux
Appendix E Linux Depending on the Kernel version, device drivers for the CAN interfaces from PEAK- System are already included in the operating system. The PCAN interfaces are handled as network devices (SocketCAN, netdev). You can find the documentation for SocketCAN under: https://www.kernel.org/doc/Documentation/networking/can.txt... -
Page 54: Appendix F Disposal
Appendix F Disposal The PCAN-USB Pro FD must not be disposed of in household waste. Dispose of the PCAN-USB Pro FD properly in accordance with local regulations. Appendix F Disposal PCAN-USB Pro FD User Manual 2.0.0 © 2023 PEAK-System Technik GmbH...
