Summary of Contents for Peak PCAN-Optoadapter
- Page 1 PCAN-Optoadapter User Manual User Manual 4.1.0 © 2023 PEAK-System Technik GmbH...
-
Page 2: Imprint
PCAN-Optoadapter IPEH-002038 Imprint PCAN® is a registered trademark of PEAK-System Technik GmbH.CANopen® and CiA® are registered community trade marks of CAN in Automation e.V. All other product names mentioned in this document may be the trademarks or registered trademarks of their respective companies. They are not explicitly marked by “™” or “®”. -
Page 3: Table Of Contents
2.2 Connection Secondary Side 3 Operation 3.1 Operation 3.2 Signal Delay 3.3 Status LED 4 Technical Specification Appendix A CE Certificate Appendix B UKCA Certificate Appendix C Dimension Drawing Appendix D Disposal Contents PCAN-Optoadapter User Manual 4.1.0 © 2023 PEAK-System Technik GmbH... -
Page 4: Introduction
Its integrated logic means that decoupling can be installed at any point in the CAN network. The PCAN-Optoadapter can be used in CAN FD buses with data bit rates up to 2 Mbit/s and nominal bit rates up to 1 Mbit/s. Properties at a Glance... -
Page 5: System Requirements
The power supply is done via pin 1 of the 9-pin female D-Sub connector (primary side). Therefore the attached CAN interface must provide 5 Volts. Since the PCAN-Optoadapter already contains a CAN bus termination on the primary side, the connected CAN adapter doesn’t need to be terminated separately on this side. -
Page 6: Connectors
Top view PCAN-Optoadapter 2.1 Connection Primary Side The PCAN-Optoadapter is connected to the CAN interface on the primary side. Pin assignment at the primary side (D-Sub female) The lines for the differential CAN signal CAN_H and CAN_L are terminated on the adapter with a 120-Ohms resistor (fixed). -
Page 7: Connection Secondary Side
A High-speed CAN bus (ISO 11898-2) is connected to the 9-pin D-Sub connector. The pin assignment for CAN corresponds to the specification CiA® 106. Pin assignment at the secondary side (D-Sub male) 2 Connectors PCAN-Optoadapter User Manual 4.1.0 © 2023 PEAK-System Technik GmbH... -
Page 8: Operation
3 Operation 3.1 Operation A configuration of the PCAN-Optoadapter is not needed. You can use it instantly. For general supply the adapter uses a direct voltage of +5 V. This must be applied to pin 1 of the CAN connector. The CAN interfaces of the PCAN series are able to provide 5 Volts on pin 1. -
Page 9: Signal Delay
3.2 Signal Delay The PCAN-Optoadapter has a transit time delay of approx. 80 ns. This corresponds to a cable length of 16 m. Therefore, you should consider the dependence of the maximum length of a CAN bus on the bit rate at the installation of the PCAN-Optoadapter. -
Page 10: Technical Specification
−40 to +85 °C (-40 to +185 °F) Temperature for storage and transport −40 to +100 °C (-40 to +212 °F) Relative humidity 15 to 90 %, not condensing 4 Technical Specification PCAN-Optoadapter User Manual 4.1.0 © 2023 PEAK-System Technik GmbH... - Page 11 Conformity RoHS EU Directive 2011/65/EU (RoHS 2) + 2015/863/EU DIN EN IEC 63000:2019-05 EU Directive 2014/30/EU DIN EN 55032:2022-08 DIN EN 55035:2018-04 4 Technical Specification PCAN-Optoadapter User Manual 4.1.0 © 2023 PEAK-System Technik GmbH...
-
Page 12: Appendix A Ce Certificate
German version of EN 55032:2015 + AC:2016 + A11:2020 + A1:2020 DIN EN 55035:2018-04 Electromagnetic compatibility of multimedia equipment - Immunity requirements (CISPR 35:2016, modified); German version of EN 55035:2017 Darmstadt, 07 September 2023 Uwe Wilhelm, Managing Director Appendix A CE Certificate PCAN-Optoadapter User Manual 4.1.0 © 2023 PEAK-System Technik GmbH... -
Page 13: Appendix B Ukca Certificate
German version of EN 55032:2015 + AC:2016 + A11:2020 + A1:2020 DIN EN 55035:2018-04 Electromagnetic compatibility of multimedia equipment - Immunity requirements (CISPR 35:2016, modified); German version of EN 55035:2017 Darmstadt, 07 September 2023 Uwe Wilhelm, Managing Director Appendix B UKCA Certificate PCAN-Optoadapter User Manual 4.1.0 © 2023 PEAK-System Technik GmbH... -
Page 14: Appendix C Dimension Drawing
Appendix C Dimension Drawing Appendix C Dimension Drawing PCAN-Optoadapter User Manual 4.1.0 © 2023 PEAK-System Technik GmbH... -
Page 15: Appendix D Disposal
Appendix D Disposal The product must not be disposed of in household waste. Dispose of the product properly in accordance with local regulations. Appendix D Disposal PCAN-Optoadapter User Manual 4.1.0 © 2023 PEAK-System Technik GmbH...
