ANTENNAS

Antennas

Antenna System Cellular Devices

The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. If changes are made to the device's certified antenna system, then
recertification will be required by specific network carriers.

Requirements for Cellular Antennas with regard to FCC/IC Compliance

There cannot be any alteration to the authorized antenna system. The antenna system must maintain the same
specifications. The antenna must be the same type, with similar in-band and out-of-band radiation patterns.

PTCRB Requirements

There cannot be any alteration to the authorized antenna system. The antenna system must be the same type with
similar in-band and out-of-band radiation patterns and maintain the same specifications.

Antenna Overview

■
For MTSMC-LAT1 models, we tested with the Laird LTE Antenna.
■
For MTSMC-LEU1 or MTSMC-LVW2 models, we tested with the Wieson LTE Antenna

Laird Antenna

The cellular radio portion of the device is approved with the following antenna or for alternate antennas meeting
the given specifications.
Manufacturer:
Description:
Model Number:
MultiTech Part Number:
MultiTech ordering information:
Model
ANLTE1-2HRA
ANLTE1-10HRA
ANLTE1-50HRA
20
Laird Technologies
Dipole Blade Antenna for LTE
DBA6927C1-FSMAM
95218149LF
Quantity
2
10
50
®
