ANTENNA AND ACTIVATION INFORMATION

Chapter 4 – Antenna and Activation Information

The cellular/wireless performance depends on the implementation and antenna design. The integration of the

antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early

so the performance is not compromised. Devices were approved with the following antenna(s) and for alternate

antennas meeting the given specifications.

This device has been designed to operate with the antennas listed below and having a maximum antenna gain of

6.18 dBi for the 700 MHz band, 6.00 dBi for 1700 MHz band, and 9.01 dBi for the 1900 MHz frequency band.

Antennas not included in this list or that have a gain greater than specified are strictly prohibited for use with this

device. The required antenna impedance is 50 ohms.

Devices were approved with the following antenna or for alternate antennas meeting the given specifications:

Manufacturer:

Description:

Model Number

MultiTech ordering information:

Model

ANLTE4-1HRA

ANLTE4-2HRA

ANLTE4-10HRA

ANLTE4-50HRA
