LOW BATTERY

When the battery power is low the
code. Fit new batteries as soon as this happens. The lock will operate for 100 times with low battery.

BATTERY FAILURE OVERRIDE

The KitLock has been designed so an external PP3 battery can be placed against the contact points surrounding
the Blue and Red LED's so the lock can be opened to replace the batteries should they fail.
The procedure is as follows:
Place the contact points of the PP3 battery against the contact points surrounding the Blue and Red LED's.
The positive + PP3 terminal against the Red LED and the negative - PP3 terminal against the Blue LED.
Enter the Master Code.
The motor will withdraw the locking pin allowing the lock to be opened.
Fit new batteries by removing the upper fixing bolt and swinging the lock down over the edge of the door.
Refit the lock.

PROGRAMMING

To program - the lock must be in the open position with the # button visible. Every program command must
commence by pressing the # button, followed by other the Master Code, Sub-Master Code or User Code.

MASTER CODE COMMANDS

CHANGE THE MASTER CODE
#Master Code • 01 • New Master Code • New Master
Example: #11335577 • 01 • 12345678 • 12345678 ••
Result: Master Code has been changed to 12345678.
SET OR CHANGE THE USER CODE
#Master Code • 02 • User
Example: #11335577 • 02 • 9999 ••
Result: New User Code 9999 now operative.
DELETE THE USER CODE
#Master Code • 03 ••
Example: #11335577 • 03 ••
Result: User Code deleted.
SET OR CHANGE THE SUB-MASTER CODE
#Master Code • 04 • Sub-Master Code • Sub-Master
Example: #11335577 • 04 • 87654321 • 87654321 ••
Result: Sub-Master Code 87654321 now operative.
DELETE THE SUB-MASTER CODE
https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1000-2017-programming-and-operating-instructions
• Red LED will flash 3 times before the
Code ••
Code ••
Code ••
• Blue LED lights, accepting the
