Codelocks Support
KL1200 - Right Hand Programming & Operating
Instructions
Codes - The Basics
The KitLock has four code levels available:
1. Master Code
2. Sub-Master Code
3. User Code
4. Technician Code
The KitLock is supplied with two factory set codes:
1. Master Code: 55 44 33 22
2. User Code: 00 99
When fitted immediately change the Master Code and User Code.
All Master Codes and Sub-Master Codes are 8 digits long.
All User Codes are 4 digits long.
All Technician Codes are 6 digits long.
The lock 'open' time is set at 4 seconds.
Functions
Before programming, select the most appropriate function for the application:
A) PRIVATE USE
Important Note: This is the default function and is already pre-programmed in new locks. This is the most
common function and is used where the same code will be repeatedly used
https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1200-right-hand-programming-operating-instructions
Advertisement
Table of Contents
Related Manuals for CODELOCKS KL1200
Summary of Contents for CODELOCKS KL1200
- Page 1 Codelocks Support KL1200 - Right Hand Programming & Operating Instructions Codes - The Basics The KitLock has four code levels available: 1. Master Code 2. Sub-Master Code 3. User Code 4. Technician Code The KitLock is supplied with two factory set codes: 1.
- Page 2 A code cannot be programmed into more than one level Lost Code Procedure Note: The procedure requires the door to be open • Remove the rear-fixing bolt and swing the lock over the edge of the door to reveal the battery compartment https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1200-right-hand-programming-operating-instructions...
- Page 3 When the battery power is low the Red LED will flash 3 times before the Blue LED flashes to signal acceptance of the code. Batteries should be changed as soon as this happens. The lock will operate for 100 times with low battery. https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1200-right-hand-programming-operating-instructions...
- Page 4 #Master Code • 65 • New Master Code • New Master Code •• Example: #55443322 • 65 • 12345678 • 12345678 •• Result: Master Code has been changed to 12345678. Note: # prefix not required when in B) Public Use Set or change the USER CODE #Master Code • 60 • User Code •• Example: #55443322 • 60 • 9999 •• Result: New User Code 9999now operative. https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1200-right-hand-programming-operating-instructions...
- Page 5 Result: Sub-MasterCode has been changed to 10101010. Note: # prefix not required when in B) Public Use Set or Change the USER CODE #Sub-Master Code • 62 • User Code •• Example: #87654321 • 62 • 6666 •• Result: New User Code 6666 now operative. Delete USER CODE #Sub-Master Code • 67 •• Example: #87654321 • 67 •• Result: User Code deleted. https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1200-right-hand-programming-operating-instructions...
- Page 6 User Code. Please note that the keypad is now inactive when the lever is in the open position 2. Only the Master Code and Sub-Master Code will be retained from Private Use Function Changing from PUBLIC USE to PRIVATE USE #Master Code • 55 •• Example: #55443322 • 55 •• https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1200-right-hand-programming-operating-instructions...
- Page 7 Special Note : The number of hours the lock can be set to remain locked is 2, 4, 6, 8, 10 or 12 hours. On the KL1200 Right Hand version keypad this is set as follows: 2h=60, 4h=69, 6h=68, 8h=67, 10h=56 #Master Code • 56 • (Number of hours lock to remain...
- Page 8 POI_KL1200RH-v1_0318_OL © 2019 Codelocks Ltd. All rights reserved. https://codelocks.zohodesk.eu/portal/en/kb/articles/kl1200-right-hand-programming-operating-instructions...
