INA219 Software Overview
4 INA219 Software Overview
This section discusses the installation and operation of the INA219 software.
4.1 Operating Systems for INA219 Software
The INA219EVM software was tested on the Microsoft Windows XP operating system (OS) with United States
and European regional settings. The software should also function on other Windows operating systems.
4.2 INA219EVM Software Install
Follow these steps to install the INA219EVM software:
1. Software can be downloaded from the
INA219EVM, which contains a folder called Install_software/.
2. Find the file called setup.exe. Double-click the file to start the installation process.
3. Follow the on-screen prompts to install the software.
4. To remove the application, use the Windows Control Panel utility, Add/Remove Software.
4.3 Starting the INA219EVM Software
The INA219 software can be operated through the Windows Start menu. From Start, select All Programs;
then select the INA219EVM program.
properly. When started, the software may produce an error about "Invalid calibration information" as shown in
Figure
4-2. Dismiss this error and continue, as this error no longer affects the current hardware.
12
INA219EVM Rev A Model User's Guide and Software Tutorial
INA219EVM
web page, or from the disk included with the
Figure 4-1
shows how the software will appear if the EVM is functioning
Copyright © 2023 Texas Instruments Incorporated
SBOU074E – JANUARY 2009 – REVISED JULY 2023
