User's Guide
INA220EVM (Rev C)
Precision Linear Products
This user's guide describes the characteristics, operation, and use of the INA220 evaluation module (Rev C)
hardware. The document covers all pertinent areas involved to properly use this EVM board. Throughout this
document, the terms evaluation board, evaluation module, and EVM are synonymous with the INA220EVM. This
document includes the physical printed circuit board layout, schematic diagrams, and circuit descriptions.
1
Overview..................................................................................................................................................................................2
Hardware.......................................................................................................................................................2
1.2 Related Documentation from Texas Instruments...............................................................................................................
2 System Setup..........................................................................................................................................................................
2.1 Theory of Operation for INA220_Test_Board Hardware....................................................................................................
2.2 Signal Definitions of J1 (25-Pin Male DSUB).....................................................................................................................
3.1 Electrostatic Discharge Warning........................................................................................................................................
3.2 Typical Hardware Connections..........................................................................................................................................
3.3 Connecting the Hardware................................................................................................................................................
Power............................................................................................................................................................10
3.6 INA220 Jumper Settings..................................................................................................................................................
3.8 Connecting External Signals to the INA220EVM.............................................................................................................
4 INA220 Software Overview..................................................................................................................................................
Software..............................................................................................................................................19
5 Bill of Materials.....................................................................................................................................................................
6 Revision History...................................................................................................................................................................
Trademarks
Microsoft
®
and Windows
All trademarks are the property of their respective owners.
SBOU079C - JULY 2009 - REVISED MARCH 2023
Submit Document Feedback
Table of Contents
Warnings.........................................................................................................................4
USB_DIG_Platform.....................................................................................................................8
Setup....................................................................................................................................9
INA220EVM................................................................................................................11
INA220EVM...............................................................................................................15
Install............................................................................................................................................16
Software...................................................................................................................................16
®
are registered trademarks of Microsoft Corporation.
Copyright © 2023 Texas Instruments Incorporated
ABSTRACT
Table of Contents
3
5
5
7
9
9
10
12
15
16
21
22
INA220EVM (Rev C)
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments INA220EVM
Summary of Contents for Texas Instruments INA220EVM
-
Page 1: Table Of Contents
The document covers all pertinent areas involved to properly use this EVM board. Throughout this document, the terms evaluation board, evaluation module, and EVM are synonymous with the INA220EVM. This document includes the physical printed circuit board layout, schematic diagrams, and circuit descriptions. -
Page 2: Overview
1 Overview This document provides the information needed to set up and operate the INA220EVM evaluation module, a test platform for the INA220, a high or low side, bidirectional current and power monitor with an I C interface. For a... -
Page 3: Related Documentation From Texas Instruments
The following document provides information regarding Texas Instruments integrated circuits used in the assembly of the INA220EVM. This user's guide is available from the TI website under literature number SBOU079. Any letter appended to the literature number corresponds to the document revision that is current at the time of the writing of this document. -
Page 4: Information About Cautions And Warnings
The information in a caution or a warning is provided for your protection. Remember to read each caution statement carefully. INA220EVM (Rev C) SBOU079C – JULY 2009 – REVISED MARCH 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 5: System Setup
2 System Setup Figure 2-1 shows the system setup for the INA220EVM. The PC runs software that communicates with the USB DIG Platform. The USB DIG Platform generates the analog and digital signals used to communicate with the INA220_Test_Board. Users can connect the INA220_Test_Board to the system and monitor the power, current, and voltage of the system under test conditions. - Page 6 A0 and A1. Connector T4 allows the connection of the shunt and bus voltages. Figure 2-3. INA220_Test_Board Schematic INA220EVM (Rev C) SBOU079C – JULY 2009 – REVISED MARCH 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 7: Signal Definitions Of J1 (25-Pin Male Dsub)
No connection Common or ground connection for power SPI_SCK No connection SPI_CS1 No connection SPI_DOUT No connection SPI_DIN1 No connection SBOU079C – JULY 2009 – REVISED MARCH 2023 INA220EVM (Rev C) Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 8: Theory Of Operation For Usb_Dig_Platform
Figure 2-4 shows the block diagram for the USB DIG Platform. This platform is a general-purpose data acquisition system used on other Texas Instruments evaluation modules. The details of the USB DIG Platform operation are included in a separate document (available for download at www.ti.com). -
Page 9: Ina220Evm (Rev C) Hardware Setup
INA220EVM (Rev C) Hardware Setup 3 INA220EVM (Rev C) Hardware Setup The INA220EVM (Rev C) hardware setup involves connecting the two PCBs of the EVM together, applying power, connecting the USB cable, and setting the jumpers. This section details this procedure. -
Page 10: Connecting The Hardware
INA220EVM (Rev C) Hardware Setup www.ti.com 3.3 Connecting the Hardware To connect the two PCBs of the INA220EVM together, gently push on both sides of the D-SUB connectors (as shown in Figure 3-2). Ensure the two connectors are completely pushed together; loose connections may cause intermittent operation. -
Page 11: Connecting The Usb Cable To The Ina220Evm
INA220EVM (Rev C) Hardware Setup 3.5 Connecting the USB Cable to the INA220EVM Figure 3-3 shows the typical response to connecting the USB DIG platform to a PC USB port for the first time. Note that the EVM must be powered on before connecting the USB cable. Typically, the computer will respond with a Found New Hardware, USB Device pop-up. -
Page 12: Ina220 Jumper Settings
3.6 INA220 Jumper Settings Figure 3-4 shows the default jumpers configuration for the INA220EVM. In general, the jumper settings of the USB DIG Platform will not need to be changed, but you may want to change some of the jumpers on the INA220_Test_Board to match your specific configuration. - Page 13 INA220EVM (Rev C) Hardware Setup Table 3-2. USB DIG Platform Jumper Settings JUMPER DEFAULT PURPOSE JUMP1 This jumper selects external power or bus power. External power is applied on J5 (on USB DIG board) or T3 (9 V ). Bus power is 5 V from the USB.
- Page 14 INA220EVM (Rev C) Hardware Setup www.ti.com Table 3-3. Power-Supply Jumper Configuration #1 MODE JUMPER COMMENT External Power—5V JUMP17 = BUS (not used) In this mode, all power is supplied to the EVM by J5 (on USB DIG board) (default jumper settings) JUMP13 = REG or T3.
-
Page 15: Connecting External Power To The Ina220Evm
INA220EVM (Rev C) Hardware Setup 3.7 Connecting External Power to the INA220EVM The INA220 power supply (V ) operates in the range of 3 V to 5.5 V (see the INA220 product data sheet). The default jumper position provides 5 V to the INA220 from the USB-DIG-Platform. The power from the USB-DIG-Platform can be changed to 3 V using JUMP9. -
Page 16: Ina220 Software Overview
4 INA220 Software Overview This section discusses the installation and operation of the INA220 software. 4.1 INA220EVM Software Install Follow these steps to install the INA220EVM software: 1. Software can be downloaded from the INA220EVM web page, or from the disk included with the INA220EVM, which contains a folder called Install_software/. - Page 17 If the sound is on, you will hear the distinctive sound that you expect when a USB device is properly connected to the PC. Figure 4-2. INA220EVM Software—No Communication with the USB DIG Platform SBOU079C – JULY 2009 – REVISED MARCH 2023...
- Page 18 Platform. If you see this error, check the connectors between the two boards; make sure the 25-pin connectors are completely pushed together. Also make sure the INA220_Test_Board jumpers are set in the right position. Figure 4-3. INA220EVM Software—No Communication with the USB DIG Platform and INA220 INA220EVM (Rev C) SBOU079C –...
-
Page 19: Using The Ina220 Software
4.3 Using the INA220 Software The INA220EVM software has six different tabs that allow access to the different features of the INA220. The first four tabs are designed to allow for complete configuration of the device by stepping through the tabs in order. - Page 20 The Help...About feature can be used to check the current software revision, as Figure 4-5 illustrates. This document is based on revision 1.0.35. Figure 4-5. Current Software Revision INA220EVM (Rev C) SBOU079C – JULY 2009 – REVISED MARCH 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 21: Bill Of Materials
ED300/2 Cage Clamp, 45°, 15A, Dove-tailed 3-pin connector 3-Position Terminal Strip, On-Shore Technology Inc ED300/3 Cage Clamp, 45°, 15A, Dove-tailed SBOU079C – JULY 2009 – REVISED MARCH 2023 INA220EVM (Rev C) Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 22: Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version. Changes from Revision B (May 2016) to Revision C (March 2023) Page • Changed user guide title for INA220EVM (Rev C) hardware support..............Changes from Revision A (February 2010) to Revision B (May 2016) Page •... - Page 23 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
- Page 24 www.ti.com Regulatory Notices: 3.1 United States 3.1.1 Notice applicable to EVMs not FCC-Approved: FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software associated with the kit to determine whether to incorporate such items in a finished product and software developers to write software applications for use with the end product.
- Page 25 www.ti.com Concernant les EVMs avec antennes détachables Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à...
- Page 26 www.ti.com EVM Use Restrictions and Warnings: 4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS. 4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling or using the EVM, including without limitation any warning or restriction notices.
- Page 27 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2023, Texas Instruments Incorporated...
- Page 28 TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for TI products. TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2023, Texas Instruments Incorporated...
