5.0 Download a configuration example, adapt it to your net-
work, and load it onto the SmartNode
Patton provides a collection of configuration templates on the support page at
www.patton.com/smartnode—one of which may be similar enough to your application
that you can use it to speed up configuring the SmartNode. Simply download the con-
figuration note that matches your application to your PC. Adapt the configuration as
described in the configuration note to your network (remember to modify the IP
address) and copy the modified configuration to a TFTP server. The SmartNode can
now load its configuration from this server.
Note
If your application is unique and not covered by any of Patton's configu-
ration templates, you can manually configure the SmartNode instead of
loading a configuration file template. In that case, refer to the Smart-
Node Series SmartWare Software Configuration Guide for information
on configuring the SmartNode device.
In this example we assume an TFTP server resides on the host with the IP address
10.10.1.11 and the configuration file named SN.cfg resides in the root directory of the
TFTP server.
10.10.22.50(if-ip)[eth0]#copy tftp://10.10.1.11/SN.cfg startup-
config
Download...100%
10.10.22.50(if-ip)[eth0]#
After you reboot the SmartNode the new startup configuration will become active.
IMPORTANT
10.10.22.50(if-ip)[eth0]#reload
Running configuration has been changed.
Do you want to copy the 'running-config' to the 'startup-config'?
Press 'yes' to store, 'no' to drop changes : no
Press 'yes' to restart, 'no' to cancel : yes
The system is going down
For detailed information about configuring and operating guidance, set up procedures,
and troubleshooting, refer to the SN4520 & 4110 User Manual available online at
www.patton.com/manuals/SN4520-4110.pdf
tion Guide available online at www.patton.com/smartnode.
SmartNode 4520 & 4110 Quick Start Guide
When you issue the reload command, the SmartNode will
ask if you want to copy the running configuration to the
startup configuration. Since you just downloaded a configu-
ration file to the startup configuration you must answer this
question with NO. Otherwise, the downloaded configuration
will be overwritten and lost!

6.0 Additional Information

and the SmartWare Software Configura-
7
