Patton SmartNode 4520 Series Quick Start Manual page 3

Option 1: Connect to a network that has a DHCP server (SN4520 & SN4110). Using
the included black Ethernet cable, connect the SmartNode RJ-45 Ethernet WAN port,
labeled ETH0/0 (see
your PC. WAN interface ETH0/0 is configured as DHCP client.
DHCP
Server
PC
Figure 1.
PC
Option 2: Connect directly to a PC (SN4520 only).
LAN interface ETH0/1 is configured as DHCP server (see
1. Configure your PC as a DHCP client.
Note
The procedures below are for Microsoft Windows. For another operating
system, refer to the operating instruction that came with your PC.
2. Right-click on My Network Places and select Properties in the context menu (see
figure 3).
SmartNode 4520 & 4110 Quick Start Guide
figure 1), to an Ethernet hub or switch on the same network as
Connecting the SmartNode to your PC through a hub or switch
Figure 2.
Connecting the SmartNode directly to your PC
SmartNode
ETHO/O
V o
E T
i c e
H
0 / 0
0 / 3
0 / 2
Ethernet Hub
or Switch
SmartNode
4520
E T
H
0 / 0
V o
E T i c e
H
P o
0 / 1
ETHO/1
0 / 3
0 / 2
figure
P o
r t s
0 / 1
F X
S
0 / 0
r t s
0 / 1
F X
S
0 / 0
2).
3
