Option 3: Connect the SmartNode console port to your PC (SN4520 & SN4110). If
your PC has an RS-232 serial COM port, you may use it to connect the SmartNode Con-
sole port. Refer to the SmartNode 4520/4110 User Manual located at www.patton.com/
manuals/SN4520-4110.pdf for the procedure.
Note
SN4112S does not have a console port, please see section 3.0 Start
the SmartNode Discovery Tool

3.0 Start the SmartNode Discovery Tool

1. Open a web browser and go to www.patton.com/SNDiscovery. A list of Smart-
Node utilities displays. Identify the SmartNode Discovery Tool item in the list.
Click the Download link and agree to the service terms to save the file to your PC.
2. At your PC, double-click the SNDiscovery.exe file name to activate the tool. The
SmartNode Discovery Tool window will display the IP Address, MAC Address,
Device Type (model number) and Build (software release) of your SmartNode.
If your SmartNode does not appear:
•
• Make sure the SmartNode and your PC are on the same routed subnet
•
• Make sure any firewall programs on your PC are disabled
SmartNode 4520 & 4110 Quick Start Guide 5
