7 Web Interface Operation

Access Web control interface of Pro HD through browser. Main operating steps,
functions and corresponding parameter configuration requirements are the same as
the operation of the controller. This chapter only covers network establishment,
motion description and features of Web interface operations. Please refer to the
relevant chapters of controller operation for specific parameter configurations and
configuration requirements.

7.1 Network Establishment

1) Connect Pro HD to the same LAN and network segment as the control
computer.
2) Turn on the power of Pro HD and set communication settings on the controller
referring to
automatically or manually if you know the IP address.
3) Open up the browser on control computer. Enter the local IP of Pro HD and
open up the web configuration interface.

7.2 Operating Motion Description

The Web interface of Pro HD is shown as the picture below. Compared with controller
operation, the operation with Web interface is more intuitional and clearer.
