NovaStar MCTRL300 Manual page 7

MCTRL300 Independent Controller
Specifications
3.1 Front Panel
3.2 Rear Panel
Connector
Input
Output
Function
www.novastar.tech
Connector
Description
Name
DVI IN Single-link DVI connector

 Resolution up to 1920×1200@60Hz and downward
compatible
Custom resolutions supported:

Resolution with maximum width: 3840×600@60Hz
Resolution with maximum height: 800×2560@60Hz
AUDIO Audio input connector
RJ45 × 2  2 Gigabit Ethernet outputs
Maximum loading capacity of a single Ethernet port:

650,000 pixels
 Support redundancy between Ethernet ports.
LIGHT Connect to light sensor to monitor ambient brightness to
SENSOR realize automatic screen brightness adjustment.
3
Appearance
3 Appearance
2
