MCTRL600 Independent Controller
Specifications
Connector
Output
Function
Control
Power
www.novastar.tech
Connector
Description
Name
HDMI IN
HDMI 1.3 compliant
Resolution up to 1920×1080@60Hz and downward
compatible
Custom resolutions supported:
Resolution with maximum width: 3840×600@60Hz
Resolution with maximum height: 800×2560@60Hz
Support HDCP.
AUDIO
Audio input connector
RJ45 × 4
4 RJ45 Gigabit Ethernet outputs
Maximum loading capacity of a single Ethernet port:
650,000 pixels
Support redundancy between Ethernet ports.
LIGHT
Connect to light sensor to monitor ambient brightness to
SENSOR
realize automatic screen brightness adjustment.
USB
USB control port for connecting to PC
UART IN
Input port for cascading devices
UART OUT
Output port for cascading devices. Up to 20 controllers
can be cascaded.
AC 100V~240V-50/60Hz
3 Appearance
4
