NovaPro HD User's Manual
Mode 3: NovaLCT client operation. Connect NovaPro HD to control computer and all
configurations can be completed on NovaLCT-Mars client. Then send to NovaPro HD.
Note: Interlace operation of machine, LCT and Web is not allowed.
Please refer to the following chapter for detailed operation steps.

6 Machine Operation

LED display can be started with moderate brightness and used normally through five
simple steps.
Menus of Display Control, Advanced Settings, Communication Settings and Language
can help users to better control LED display.

6.1 Description of operation action

Knob: Press the knob to enter into menu and turn it to adjust values or select
submenus. At this time, enter into the submenus or confirm adjusted values by
pressing the knob.
【ESC】: Return key, exit from current menu or operation.
Option buttons of six input sources: Short press a button to set it as the input source
of main screen while long press to set as the source of PIP.
Lock: simultaneously press the knob and ESC button for more than three seconds to
lock the controller.
Unlock: simultaneously press the knob and ESC button for more than three seconds
to unlock the controller.
www.novastar.tech -9-
