Commissioning
7
Starting and tuning the system
7.1
Enable functions
N
Below is an example where the Distribution Circuit function is enabled.
Other functions are enabled in a similar way.
1. Press
in the upper left corner of the Start screen.
2. Press
.
3. Continue with to the menu page for Mix valves.
4. Press the text Distribution Circuit 1.
5. Press
to enable the Distribution Circuit 1 function.
6. Adjust the settings appropriately.
7. Press
to confirm the setting.
8. Press
to return to the Menu screen.
7.2
Activate / deactivate functions
N
Below is an example where the Distribution Circuit function is deactivated.
Other functions are activated in a similar way.
1. Press
in the upper left corner of the Start screen.
2. Press
.
3. Continue with to the menu page to activate/deactivate Distribution Circuit 1.
4. Press
to activate Distribution Circuit 1 or press
5. Press
to return to the Menu screen.
7.3
Selecting operating mode
N
Set the heat pump to the desired operating mode in the menu:
1. Press
on the Start screen to open the Menu screen.
2. Press
. A new window opens.
3. Press the appropriate symbol for the desired operating mode.
26
DHP-H Varius Pro+/DHP-L Varius Pro+
Functions not activated/enabled from factory must be enabled and
activated in the control system before they can be used.
Functions not activated/enabled from factory must be enabled and
activated in the control system before they can be used.
The heat pump has a starting time of about 5 - 10 minutes.
The delay does not apply to the auxiliary operating mode.
VIJSG202
to deactivate Distribution Circuit 1.
Danfoss Heating Solutions
