Commissioning
Two heat pumps, setting up primary and secondary functionality
On the secondary unit, go to the network settings menu and configure the machine to
be on the same subnet.
Finally, in the "primary/secondary" menu, configure the secondary unit.
No external network connection to the system. Ethernet cable: Standard Cat 5 network cable, RJ 45.
1
2
More than one secondary heat pump
1
3
4
5
20
DHP-H Varius Pro+/DHP-L Varius Pro+
1. Primary (controlling) heat pump with IP address e.g. 192.168.0.100
2. Secondary heat pump with IP address e.g. 192.168.0.102
The secondary heat pump must always point to the primary heat pump IP address.
2
8
7
6
VIJSG202
1
Router/Switch
2
Possibility of internet access via router
3
Primary (controlling) heat pump with IP address e.g.
192.168.000.100
4
Secondary heat pump with IP address e.g. 192.168.000.102
5
Secondary heat pump with IP address e.g. 192.168.000.103
6
Secondary heat pump with IP address e.g. 192.168.000.104
X
Secondary heat pump with IP address e.g. 192.168.000.XXX
7
Online Web server and database
8
Online web browser
The secondary heat pump must always point to the primary heat
pump IP address.
Danfoss Heating Solutions
