Commissioning
Symbol description
Fig. 1: The figure shows the standard curve 40
Symbol
(+2)
45
40
40
Danfoss Heating Solutions
DHP-H Varius Pro+/DHP-L Varius Pro+
description
Shows when the curve is comfort-adjusted. The digit shows how much.
Shows that the comfort adjustment window is inactive. Press on the symbol to open comfort
adjustment.
Shows that the comfort adjustment window is active.
Shows that the heat curve window is inactive. Press on the symbol to open heat curve settings.
Shows that the heat curve window is active. This window is the default window.
Shows that the heating settings window is inactive. Press on the symbol to open heating set-
tings.
Shows that the heating settings window is active.
When the curve indicator is lit, press
When the curve indicator is not lit, press
downwards.
Press to reset to factory settings.
Indicates that underfloor heating is active and radiator heating is deactivated.
See chapter Default Heating Settings for more information.
Indicates that radiator heating is active and underfloor heating is deactivated.
See chapter Default Heating Settings for more information.
or to move whole curve upwards or downwards.
or to move individual curve points upwards or
VIJSG202
