EVAL-AD5932EBZ User Guide
ORDERING INFORMATION
BILL OF MATERIALS
Table 2.
Item
Qty
Reference
1
3
C1, C2, C6
2
1
C10
3
2
C18, C26
4
1
C24
5
1
C23
6
20
C3 to C5, C7, C8, C12, C14, C15,
C17, C20, C27, C28, C30 to C37
7
6
C9, C11, C13, C16, C19, C29
8
1
D2
9
1
J1
10
2
J2, J14
11
10
J3 to J11, J13
12
1
L1
13
7
LK1 to LK6, LK8
14
1
LK7
15
2
R1, R2
16
3
R10 to R12
17
1
R15
18
1
R16
19
1
R17
20
1
R3
21
2
R4, R5
22
1
R9
23
26
T1 to T26
24
1
U1
25
1
U2
26
1
U3
27
1
U4
28
1
U5
29
1
U7
30
1
Y1
Description
22 pF, 0603 ceramic capacitor
2.2 µF, 0805 ceramic capacitor
0603 capacitor
0805 capacitor
0.01 µF, 0603, ceramic capacitor
0.1 µF, 0603, ceramic capacitor
10 µF, TAJA, tantalum capacitor
Green LED
USB mini-B connector (USB-OTG)
2-pin terminal block (5 mm pitch)
Subminiature BNC connector (SMB)
Ferrite bead (600 Ω at 100 MHz)
3-pin SIL header (with shorting block)
2-pin SIL header (with shorting block)
2.2 kΩ, 0603 resistor
10 kΩ, 0603 resistor
0603, resistor
1.5 Ω, 0603 resistor
0 Ω short
1 kΩ, 0603 resistor
100 kΩ, 0603 resistor
50 Ω, 0603 resistor
Test point
AD5932
IC, serial EEPROM, 64k, 2.5 V, 8-SOIC
Precision voltage regulator
CY7C68013-CSP USB microcontroller
Quad SPDT switch/2:1 mux
50 MHz, CMOS/TTL, crystal (and 14-pin DIP)
24 MHz, CM309S, SMD, crystal
Rev. A | Page 9 of 10
UG-796
Supplier/Part No.
FEC 722-005
Digikey 445-1588-1-ND
Not Inserted
Not Inserted
FEC 722-066
FEC 499-675
FEC 331-3888
FEC 515-620
FEC 476-8309
FEC 151-785
FEC 310-682
FEC 581-094
FEC 512-047 and 150-411
FEC 511-705 and 150-411
FEC 911-276
FEC 911-355
Not Inserted
FEC 758-267
FEC 772-227
FEC 911-239
FEC 911-471
FEC 422-1825
FEC 240-333
AD5932
Digikey 24LC64-I/SN-ND
ADP3303AR-3.3
Embassy CY7C68013-56LFC
ADG774BRQ
FEC 788-480/97103
FEC 569-872
