North
South
Figure 9
Step 2: Console operation set to Southern Hemispheres( SOU
in the time area) in Location division. (Check the detailed step
of setting the time area in the part 17 of Chapter 7.2)
Note: The location division (NOR or SOU) on the Display
Console and the directions of the sensor have to be adjusted
to match with your real location.
If the wind direction sensor is not positioned correctly during
installation, permanent wind direction error will be introduced.
5.1.3 Mounting & Fixing the Sensor Horizontally
Fasten the integrated outdoor sensor to the mounting pole
brackets with two foot-mounting screws Ø3 bolts and M3 nuts.
Then, tighten the mounting pole to your existing mounting pole
with the four bolts ( Ø5) and nuts (M5) , or fix it on the flat
surface with four tapping screws, as show in Figure 10.
- 17 -
