Mounting indoor station (display & operating
unit) (Figure 9)
„ Mount design frame (2) in correct position on
the back of the cover.
(21)
(22)
(2)
Figure 9: Installation
(21) Velcro fastening (optional)
(22) Pin header of the operating unit
(23) Cable connector of the connection terminal
block
(24) Locking hook
„ For installation on smooth walls the velcro
fastening (21) may be used. To do this, remove
adhesive foil.
i
When using the velcro fastening the surface
must be clean and free of dust. Do not use on
sensitive wallpapers or badly adhering surfac-
es.
„ Align the indoor station (3) so that the backside
pin header (22) is pointing to the pin header of
the connection terminal block (23).
„ Mount the indoor station onto the supporting
plate and carefully press on until the locking
hooks (24) interlock.
„ When using the velcro fastening: Press indoor
station above onto the wall at the height of the
Velcro fastening.
5 Elcom Kommunikation GmbH - Gottfried-Leibniz-Str.1 - D-74172 Neckarsulm - www.elcom.de -
Expanded settings
The
information about the device address, current DIP
switch setting and firmware version. It also enables
expanded settings.
service
add:1/E DIP:0010
(23) manual on
internal call FF
internal call FE
camera search
load factory settings
(24)
Allowing/preventing manual switching-on of
the camera
The video connection to the video door station is
established automatically during the door call and
(3)
terminated again automatically after the end of the
call.
With the
to enable the camera of the door station that last
called to be switched on via the indoor station
without a door call.
If the checkmark is set, the camera symbol
appears at the bottom right of the start page.
The camera can be switched on manually with
the associated Softkey (8).
If several video door stations or additional
cameras are installed in the same line, it is
possible to toggle between the camera pictures
by pressing
The device is not suitable for video
ç
monitoring!
Searching for cameras
The
determine all additional video cameras installed in
the line.
i
Please note: If this function is called, all current
door cameras will be deleted from the memory
of the indoor station. During the next respective
door call, the door cameras are then reas-
signed.
Enabling/disabling internal call addresses
Before using the internal call function, the
options and/or
activated on the
the two internal call addresses was activated, the
Resetting to factory settings
The device software can be reset to factory
settings. The DIP-switch configuration remains
unchanged.
„ Under
select the
confirm with
A prompt appears:
confirm action
load factory settings
„ Press to select
reset the software with
or:
„ Press to cancel the action.
menu page provides
V....
function it is also possible
repeatedly.
function starts a search to
must be
menu page. If neither of
menu page is not available.
press / to
option and
.
cancel
OK
and
.
Appendix
Technical data
Supply voltage X/X via bus
Current consumption (operation)
Current consumption (Stand-by)
Sound pressure level ring tone via
loudspeaker at a distance of 0.5 m
Call volume (hands-free)
TFT display size
Resolution of graphical display
Degree of protection
Operating temperature
Connecting terminal for
conductor cross-section
Dimensions including
design frame (W x H x D)
Standards
Ring tone volume (signal) according to EN 50486

Warranty

We reserve the right to realise technical and formal
changes to the product in the interest of technical
progress.
Our products are under guarantee within the scope
of the statutory provisions.
In case of service issues, please contact your
systems' engineer.
22 ... 24 V=
max. 220 mA
≈ 12 mA
78 dB(A)
max. 65 dB(A)
3.5"
320 x 240 px
IP 30
5 °C ... 50 °C
max. 0.75 mm²
93 x 163.5 x 16 mm
6LE001303B - 09/2015
