Settings
On the menu pages 3 to 6 (Table 3) individual
settings can be made.
Changing settings
The device is switched on.
„ With the menu slider (10) load the required
menu page by wiping repeatedly (Table 3).
„ Press menu operation buttons
the parameter to be changed and confirm
with .
„ With the menu operation buttons
the desired settings (stepwise or hold down the
button).
„ Press to apply the settings.
Save/load settings
On the
press to save the individual settings
and press to reload them at a later
time.
no problem
save settings
load settings
load default settings
„ Select the desired option with
confirm with .
A prompt appears:
confirm action
cancel
save settings
„ Press to select the action again and press
to execute it.
or:
„ Press to cancel the action.
i
The option restores the
state that the device had when handed over by
the installer.
3 Elcom Kommunikation GmbH - Gottfried-Leibniz-Str.1 - D-74172 Neckarsulm - www.elcom.de -

Display Settings

Selecting language
The menu language is preset to English at the
factory. Under
„ To switch on the device, press any Softkey (6, 7
or 8), if this has not yet been done.
„ On the menu slider (10) wipe twice from right
/ to select
to left.
The
appears.
/ perform
menu page
„ Confirm
The list of available languages is displayed.
„ Press the
select the language and confirm with
Set display
In idle mode (display switched on, no call) under
can be selected at first. If a camera picture is
shown in the display, then the
/ and
and
ed incrementally.
OK
„ Press
changed and confirm with
„ Press
press
it can be changed.
menu page
video settings
language
with .
/ menu operation buttons to
only the language
,
of the display can also be adjust-
video settings
language
contrast
brightness
colour
/ to select the parameter to be
.
/ to perform the desired settings and
to apply them.

Audio settings

Under
volume and microphone sensitivity can be adjust-
ed. Here too, ring tone melodies can be selected
and assigned to calling stations.
audio settings
ring tone volume
ring melody door x1
microphone
Setting the microphone sensitivity
In hands-free mode, the changeover between
listening and speaking takes place automatically
depending on the volume. The changeover behav-
iour can be optimised by adjusting the microphone
sensitivity. As a result, the influence of background
noise in the area of the indoor station can be
reduced.
The adjustment can best be performed during an
active call.
.
„ Under
option.
„ Press / to adjust the microphone sensitivity
incrementally.
„ Press to apply the settings.
Activating Push-to-Talk
In Push-to-Talk mode the changeover between
listening and speaking takes place manually with
the speech button.
Speech button
keep pressed
release
„ During an active call connection, keep the
button pressed for more than 2 seconds.
For the current call, hands-free mode is
changed to Push-to-Talk mode. The display
shows the symbol.
i
To end the call, press the softkey
Selecting and assigning ring tone melodies
You can choose from 16 different ring tone melo-
dies. Individual ring tone melodies can be assigned
for door calls, storey calls and internal calls.
The indoor station creates a
each calling station or for the connected storey
push-button when an incoming call is received for
the first time. The assigned melody can be loaded
and changed via this entry under
„ Press / to select the
(e.g.
The melody assigned to the station sounds.
„ Press / to listen to other ring tone melodies
until the desired melody sounds.
„ Press to assign the ring tone melody.
i
Afterwards, another call event can be gener-
ated, e.g. storey call, and a separate ring tone
melody can be assigned to this according to the
same procedure.
Increasing/decreasing ring tone volume
Under audio settings the
also be adjusted in 3 levels.
the ring tone
select the
Function Display
speak
listen
.
entry for
.
entry
) and confirm with .
can
