ELECTRIC OR MANUAL MODEL TO SUIT FORD RANGER
Electric Unit Weight: 45Kgs (100Lbs) | Manual Unit Weight: 40Kgs (88Lbs)
NOTE
Some images contained in these instructions are generic and are a representation
of the actual model and/or parts used. Some steps may also show parts out of
sequence to the instructional steps.
As per vehicle manufacturer advice, Ironman 4x4 recommend the load box (tub) reinforcement
brackets (FoMoCo part no. AMN1WJ27726AA) be fitted prior to Installing Slide-Away.
SAFETY WARNING
Ironman 4X4 requires you read and understand the safety and pre-install
directions on page 2 before commencing installation of this product.
We take every possible measure to prevent water/dust ingress,
but cannot be held accountable for holes/gaps in factory tubs
©Copyright 2023 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
INSTALLATION
INSTRUCTIONS
Next-Gen 2022+ (Non-Wildtrak)
ISLIDEAWAY110-E / ISLIDEAWAY110-M
Electric Slide-Away model shown. Sports bar adaptor fitted and is sold separately
SLIDE-AWAY
2-3 Hours
Approximately
Document Number: ISLIDEAWAY110/210823
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ironman4x4 ISLIDEAWAY110-E
Summary of Contents for Ironman4x4 ISLIDEAWAY110-E
- Page 1 INSTRUCTIONS SLIDE-AWAY ELECTRIC OR MANUAL MODEL TO SUIT FORD RANGER Next-Gen 2022+ (Non-Wildtrak) ISLIDEAWAY110-E / ISLIDEAWAY110-M Electric Slide-Away model shown. Sports bar adaptor fitted and is sold separately Electric Unit Weight: 45Kgs (100Lbs) | Manual Unit Weight: 40Kgs (88Lbs) NOTE...
-
Page 2: Pre-Installation Procedures
ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide Pre-Installation Procedures SAFETY WARNING • Ironman 4x4 includes specific mounting hardware to ensure correct fitment to your 4WD. The correct fitment of these components is critical for your safety. • Do not alter or modify this product in any way. Doing so may compromise the strength and integrity of the product. -
Page 3: Tools Required
Installation Guide Installation Guide ISLIDEAWAY110-E / ISLIDEAWAY110-M Parts List (Item) Parts List (Item) Part Description Main drum assembly Side track Top cover Positioning bar Drain tube Adhesive foam tape Bolt set Front end track rubber cover Drain tube rubber washer A10. -
Page 4: Important Note
ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide Before installation, unwrap the hardware. Open carton and unpack, taking care not to damage or scratch in the process. Inspect for any damage. Ensure installation is compatible with the vehicle make, model and year. IMPORTANT NOTE Ensure load box (tub) reinforcement brackets Generic image used as reference only. - Page 5 Installation Guide ISLIDEAWAY110-E / ISLIDEAWAY110-M Install aluminium extrusion to raise up the tub’s front edge. Secure through into factory holes using supplied screws Apply supplied foam tape to top of extrusion. NOTE Use a silicon sealeant, and additional foam if needed, to seal any open edges at tub front.
- Page 6 ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide Pull curtain forward at least two (2) slats. Using a 5mm hex key, remove the clutch protection plate. This can be found above the label on the left-hand side of the drum assembly. With a flat bladed screwdriver, turn the clutch screw 3-4 times anti-clockwise, or until the sliding cover rolls forward freely.
- Page 7 Installation Guide ISLIDEAWAY110-E / ISLIDEAWAY110-M Attach side tracks to main drum. Align slot in bottom of side track with the locator on the end of the main drum. Start sliding track on, but do not pull all the way back.
- Page 8 ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide Secure side tracks to main drum. For this step, it may be best to rest the main drum with loosely attached side tracks on its end as shown. Insert six (6) x fasteners - Three (3) per side (B2).
- Page 9 Installation Guide ISLIDEAWAY110-E / ISLIDEAWAY110-M Install top cover to Drum using fastener pack (B2). Separate tops and bottoms from plastic caps. Place top cover over drum. Align cover holes with threaded holes in the metal fingers on the drum. Place a plastic cap base in each hole.
-
Page 10: Front Brackets
ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide 10. Attach tub brackets. FRONT BRACKETS Using the factory holes, secure small L-bracket with threaded holes to tub. This is attached behind the indentation in the plastic tub cover. Insert small screw from inside edge. - Page 11 Installation Guide ISLIDEAWAY110-E / ISLIDEAWAY110-M 11. Attach tub brackets. MIDDLE BRACKETS Using the factory holes, place the two-hole spacer in the vertical indent in the plastic tub cover. Place the slotted L-bracket over this. Secure in place using screws, washers, and nuts.
- Page 12 ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide WARNING This is a minimum two person job. Lift drum and side track assembly onto vehicle tub. If the cabin end of the tub sits lower than the sides, apply foam tape (A6) to ensure a good Generic vehicle used as reference only.
- Page 13 Installation Guide ISLIDEAWAY110-E / ISLIDEAWAY110-M 15. Secure to brackets. Slide M6 x 25mm T-Bolts (B8) into the underside of the side tracks. Position T-bolts through tops of tub brackets installed in Step 10. If needed, fine adjust tub brackets up or down so they touch the underside of the Slide-Away side rails.
- Page 14 ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide 13. Pre-securing steps. Check side tracks are still and parallel. Use the supplied spacer bar to slide up and down tracksto ensure width is consistent Check that rubber on edges of tracks is not caught under the tub edges Close tailgate to check forwad/back positioning is correct.
- Page 15 Installation Guide ISLIDEAWAY110-E / ISLIDEAWAY110-M Power Routing - Electric Model Only Power Routing Notes Red with positive Recommend wiring route path is Black with negative engine compartment » wheel trims » bed. Most vehicles already have holes in bed. If available, route cabling through exiting holes.
-
Page 16: Clutch Operation
ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide Clutch Operation To disengage (manual operation) Undo the two screws with a 5mm hex key, and remove the plate. Using a flat-bladed screwdriver, rotate the screw counterclockwise 3-4 times. The cover can now be operated by hand, and is not locked. - Page 17 Installation Guide ISLIDEAWAY110-E / ISLIDEAWAY110-M Remote Controller Functions - Electric Model Only Button Name Description Eco button Opens Slide-Away unit to halfway point, at half speed. LED indicator light Illuminates when any button is pressed. 1. Press the button to start closing Slide-Away if static.
- Page 18 ISLIDEAWAY110-E / ISLIDEAWAY110-M Installation Guide Once Installed... • To ensure quiet and smooth operation of your Slide-Away, please regularly clean and lubricate the rail tracks and main drum assembly. We recommended every 3 months or 6,000km (3,700 miles), or when vehicle is used in muddy, sandy or dusty conditions.
