IMPORTANT: MUST BE USED IN CONJUNCTION
WITH AN IRONMAN 4X4 BULL BAR
ISUZU D-MAX 2012+ MU-X 2014+
HOLDEN COLORADO 2012+
•
Ironman 4x4 Recovery Points fit to the chassis
•
It will take about 45 mins to install, or 10 mins
if installed with fitment of bull bar
•
Below is a list of required tools for installing
your Ironman 4x4 Recovery Points:
-
13, 17, and 19mm socket
-
19mm spanner
IMPORTANT: Recovery Point installations should only be done by a qualified person
and it is the responsibility of this person to ensure correct fitment.
INSTALLATION
GUIDE
IRP058
