ISLIDEAWAY048-E
ISLIDEAWAY051-E / ISLIDEAWAY051-M
ISLIDEAWAY074-E
ISLIDEAWAY082-E / ISLIDEAWAY082-M
Electric Unit Weight: 45Kgs (100Lbs) | Manual Unit Weight: 40Kgs (88Lbs)
NOTE
Some images contained in these instructions are generic and are a representation
of the actual model and/or parts used. Some steps may also show parts out of
sequence to the instructional steps.
SAFETY WARNING
Ironman 4X4 requires you read and understand the safety and pre-install
directions on page 2 and 3 before commencing installation of this product.
We take every possible measure to prevent water/dust ingress,
Document Number: BBR074/070323
but cannot be held accountable for holes/gaps in factory tubs
©Copyright 2023 Ironman 4x4 Pty Ltd. No part of this publication may be reproduced or replicated without the prior written consent of Ironman 4x4 Pty Ltd
INSTALLATION
INSTRUCTIONS
ELECTRIC OR MANUAL TO SUIT MODELS LISTED
SLIDE-AWAY
Generic image used as reference only.
2-3 Hours
Approximately
Document Number: SLIDEAWAYUIM/210823
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ironman4x4 ISLIDEAWAY048-E
Summary of Contents for Ironman4x4 ISLIDEAWAY048-E
- Page 1 INSTALLATION INSTRUCTIONS SLIDE-AWAY ELECTRIC OR MANUAL TO SUIT MODELS LISTED ISLIDEAWAY048-E ISLIDEAWAY051-E / ISLIDEAWAY051-M ISLIDEAWAY074-E ISLIDEAWAY082-E / ISLIDEAWAY082-M Generic image used as reference only. Electric Unit Weight: 45Kgs (100Lbs) | Manual Unit Weight: 40Kgs (88Lbs) NOTE Some images contained in these instructions are generic and are a representation 2-3 Hours of the actual model and/or parts used.
-
Page 2: Pre-Installation Procedures
ISLIDEAWAY (048 / 051 / 074 / 082) Installation Guide Pre-Installation Procedures SAFETY WARNING • Ironman 4x4 includes specific mounting hardware to ensure correct fitment to your 4WD. The correct fitment of these components is critical for your safety. • Do not alter or modify this product in any way. Doing so may compromise the strength and integrity of the product. -
Page 3: Tools Required
Installation Guide Installation Guide ISLIDEAWAY (048 / 051 / 074 / 082) Parts List (Item) Part Description Main drum assembly Side track Top cover Positioning bar Drain tube Adhesive foam tape Bolt set Front end track rubber cover Drain tube rubber washer A10. - Page 4 ISLIDEAWAY (048 / 051 / 074 / 082) Installation Guide Before installation, unwrap the hardware. Open carton and unpack, taking care not to damage or scratch in the process. Inspect for any damage. Ensure installation is compatible with the vehicle make, model and year. It is good practice to lay out all hardware to Generic image used as reference only.
- Page 5 Installation Guide ISLIDEAWAY (048 / 051 / 074 / 082) Pull curtain forward at least two (2) slats. Using a 5mm hex key, remove the clutch protection plate. This can be found above the label on the left hand side of the drum assembly.
- Page 6 ISLIDEAWAY (048 / 051 / 074 / 082) Installation Guide Attach side tracks to main drum. Align slot in bottom of side track with the locator on the end of the main drum. Start sliding track on, but do not pull all the way back.
- Page 7 Installation Guide ISLIDEAWAY (048 / 051 / 074 / 082) Secure side tracks to main drum. For this step, it may be best to rest the main drum with loosely attached side tracks on its end as shown. Insert six (6) x fasteners - Three (3) per side (B2).
- Page 8 ISLIDEAWAY (048 / 051 / 074 / 082) Installation Guide Install top cover to Drum using fastener pack (B2). Separate tops and bottoms from plastic caps. Place top cover over drum. Align cover holes with threaded holes in the metal fingers on the drum.
- Page 9 Installation Guide ISLIDEAWAY (048 / 051 / 074 / 082) Check the rubber flap that runs the width of the unit is not touching the back of the cab. WARNING If the rubber flap is touching the back of the vehicle cab, it will rub paint off.
- Page 10 ISLIDEAWAY (048 / 051 / 074 / 082) Installation Guide 11. Attach tub brackets. Slide M6 x 25 mm T-Bolts (B8) into the underside of the side tracks. Attach the L-bracket with the long slot to the T-bolt, and loosely secure with an M6 nut using a 10mm spanner.
- Page 11 Installation Guide ISLIDEAWAY (048 / 051 / 074 / 082) 12. Install drain tubes. Attach using hose clamps (A10) the small drain tubes (A5) to rear of the tracks, and the large tubes to the underside of the drum. If existing access holes are present, use these. If not, use the supplied bit (A19) to drill these holes.
- Page 12 ISLIDEAWAY (048 / 051 / 074 / 082) Installation Guide Power Routing - Electric Model Only Power Routing Notes Red with positive Recommend wiring route path is Black with negative engine compartment » wheel trims » bed. Most vehicles already have holes in bed. If available, route cabling through exiting holes.
-
Page 13: Clutch Operation
Installation Guide ISLIDEAWAY (048 / 051 / 074 / 082) Clutch Operation To disengage (manual operation) Undo the two screws with a 5mm hex key, and remove the plate. Using a flat-bladed screwdriver, rotate the screw counterclockwise 3-4 times. The cover can now be operated by hand, and is not locked. - Page 14 ISLIDEAWAY (048 / 051 / 074 / 082) Installation Guide Remote Controller Functions - Electric Model Only Button Name Description Eco button Opens Slide-Away unit to halfway point, at half speed. LED indicator light Illuminates when any button is pressed. 1.
- Page 15 Installation Guide ISLIDEAWAY (048 / 051 / 074 / 082) Once Installed... • To ensure quiet and smooth operation of your Slide-Away, please regularly clean and lubricate the rail tracks and main drum assembly. This is recommended every 3 months or 6,000km (3,700 miles), or when you use it in muddy, sandy or dusty conditions.
