Gas consumption/ environmental control problems

Bugbox Ax is fitted with a gas demand indicator (item 7 in Figure 7). The indicator illuminates when
gas is injected into the workstation chamber. When the workstation is at rest, the gas demand
indicator should illuminate once every 20 minutes. At rest is defined as the workstation chamber
is in an anaerobic condition with no access to the interlock chamber, i.e. the glove ports are closed,
the interlock is closed and, if fitted, the SPES is closed. Figure 36 gives some common gas
consumption and environmental control problems and solutions;
Figure 36: Gas consumption/ environmental control problems and solutions
Problem
The workstation is failing to
reach an anaerobic
condition.
High gas consumption when
at rest.
High gas consumption when
in use.
The N low indicator
2
illuminated.
The ANO low indicator is
2
illuminated.
An audible alarm can be
heard.
Cause
The catalyst sachet has
not been installed.
The catalyst sachet needs
replacing.
The anoxic mixed
supply has run out.
The glove port cover has
been left open.
The SPES has been left
open.
The interlock inner and
outer doors are both open.
The Ezee Sleeves have not
been correctly fitted.
The Ezee Sleeves are not
sealing around the users
wrists.
is Low pressure
nitrogen supply caused by
an empty
cylinder.
Low pressure in the anoxic
mixed gas supply caused
by an empty
cylinder.
Low pressure in the gas
supply, caused
empty gas cylinder.
Solution
Install a
section 9.2.1 for more details.
Replace the catalyst sachet. See
section 9.2.1 for more details.
Replace the anoxic mixed gas
gas cylinder.
Close the glove port cover.
Close the SPES. See section 8.7.1 for
more details.
Close the interlock inner and/ or
outer door.
Refit the Ezee Sleeves.
Ensure that the Ezee Sleeves are the
correct size for the user. Ensure that
any clothing and/ or jewellery that
may foul the Ezee Sleeves is
removed/ rolled back. Ensure that
the Ezee Sleeves are pulled tight
around the user's wrists.
in the Replace
check
nitrogen canister and canister head for
leaks.
Replace the nitrogen cylinder.
nitrogen
Replace the empty gas cylinder.
by an The alarm can be muted by
pressing the gas alarm switch
(item 3 in Figure 7)
catalyst sachet.
the nitrogen cylinder,
connections between
Page 53 of 55
See
