- Page 1 ® C h e m G A R D Underwriter Laboratories Listed...
- Page 2 ChemGARD® Fume Hoods ChemGARD ChemGARD® fume hoods are designed for unparalleled safety for critical laboratory applications. • Substantially reduces roll effect (fluctuations in the airflow that may cause harm to the worker). • Offers a streamlined, unobstructed work area. • Minimizes lingering concentrations above and behind the viewscreen.
- Page 3 ChemGARD® Design Features Combination horizontal/vertical sash enhances both operator safety and energy savings. Sight-tight continuous bypass duct minimizes contaminant concentrations near the edge of the sash, reducing potential exposure hazard to personnel. Airwatch II air ow monitor provides for customized alarm/monitor con gurations. Angled entrance, airfoil and radius work surface for undisturbed air ow into work area.
- Page 4 Industry-Leading Technologies Provide Superior Protection and Maximum E ciency The aerodynamic ChemGARD® design employs xed air slots at maximum safety con guration to alleviate the need for cumbersome operator adjustments. • ChemGARD® construction materials are ame resistant. • Top-suspended, 12" wide safety plate glass sash panels are easily removed for cleaning.
-
Page 5: Customized Operation
Airwatch II Air ow Monitor and Controls for Customized Operation The microprocessor-based Airwatch II air ow monitor is fully programmable, o ering a range of features for safety, convenience and easier integration into the overall laboratory safety plan. • The Airwatch II air ow monitor activates an audible alarm if operating conditions deviate from preset parameters. - Page 6 Lighting and Electrical System • A sealed, uorescent light xture is located above gasketed safety-plate glass; uorescent lamps are replaced from the front. • Solid-state lamp ballasts reduce heat output and improve e ciency. • Two GFCI duplex outlets are protected by a single 10-amp self resetting circuit breaker to protect personnel and minimize tripping of breakers.
- Page 7 Solvent Storage Base Cabinet • Exhaust Plenum • Double wall construction creates a minimum 1½" air gap throughout the cabinet. • Interior back and side panels are 18-gauge stainless steel monolithic construction welded to top and bottom panels to form a unitized inner cabinet. •...
-
Page 8: Options And Accessories
For convenience, most options, accessories and modi cations are factory installed and should be speci ed when ordering. Commonly requested options are listed below. For detailed information on accessories and modi cations, contact The Baker Company. • Additional service xtures (air, gas, vacuum, cold or DI water, steam) •... -
Page 10: Warranty
Warranty The Baker Company, Inc., expressly represents and warrants all goods (a) to be as speci ed (and de- scribed) in The Baker Company catalogs and literature, and (b) to be free under normal use, service and testing (all as described in The Baker Company catalogs and literature) from defects in material and workmanship for a period of twelve months from the invoice date.
