— — Introduction BX-M2510 Series Reference Manual 1. Related Manuals The manuals related to the product are listed below. Read them as necessary along with this document. Must Read the Following Manuals. Name Purpose Contents How to get Product Guide...
2.5 inches SATA hard disk bay unit being installed, this product is best suited to displaying images including digital signage. Embedded-type CPU has been adopted. The use of readily available parts ensures the product to be applied easily. In addition, Contec- customized BIOS allows support to be provided at the BIOS level. - 7 -...
High-security design contributes to a highly reliable system The latest security functions such as TPM2.0 and Secure Boot, as well as CONTEC's original functions including the USB Boot Protect are provided. This product is designed with the high security required for industrial applications in mind.
Page 10
*3 It is the actual measured value when Windows 10 and HORM function are enabled at the factory. Time may vary depending on configuration. Note that TXE, TPM, Network Stack, and SMART Self Test are not supported when the CONTEC Fast Boot is enabled.
Adapter Product Guide * The Reference Manual of this product is provided as the PDF file in the CONTEC web page. Such information as hardware setup, component functions, and BIOS setup are indicated in the Manual, please refer to it if needed.
Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. - 13 -...
— — Safety Precautions BX-M2510 Series Reference Manual 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely.
Avoid installation in a location where people may come into contact with that section. CONTEC does not provide any guarantee for the integrity of data on SSD/HDD. ...
Page 16
— — Safety Precautions BX-M2510 Series Reference Manual CONTEC reserves the right to refuse to service a product modified by the user. In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord immediately and contact your retailer.
— — Safety Precautions BX-M2510 Series Reference Manual 1. FCC PART 15 Class A Notice NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
— — Safety Precautions BX-M2510 Series Reference Manual 3. Security Warning When connecting to the network, be aware of security-related problems. See the examples of Security measures below and set up the product properly along with the network devices. 1. Information security risks Unauthorized access from the outside through a network could cause the system halt, data ...
— — Product Nomenclature and Function BX-M2510 Series Reference Manual 1. Nomenclature of Product Components Component names of the product are shown in the figure below. Front Rear Name Function DC-IN DC power connector POWER SW PC Power switch...
ON (Red) You can control the behavior of LED from the user application. *1 *1 CONTEC Manager that controls STATUS LED is available. (It is already installed for the product OS pre-installed type when shipped from the factory) CONTEC Manager can be downloaded through the CONTEC's Web site. For more detailed information, contact your retailer.
— — Product Nomenclature and Function BX-M2510 Series Reference Manual Rise time for power supply Voltage 2 - 30mS Time 3. Power Switch: POWER SW The power switch is provided. The power of the product can be turned on or turned off with this switch.
— — Product Nomenclature and Function BX-M2510 Series Reference Manual 6. Serial-ATA: SATA 1, SATA 2 The product has two ports of serial ATA 3.0 compliant controllers. SATA connector Connector used on the product SATA connector PC15 Pin No. Signal name Pin No.
— — Product Nomenclature and Function BX-M2510 Series Reference Manual 7. Giga bit-Ethernet: LAN A, B This product is equipped with 2 ports for giga bit-Ethernet. Network type 1000BASE-T/100BASE-TX/10BASE-T Transmission speed * 1000M/100M/10M bps Max. network path length : 100m/segment ...
— — Product Nomenclature and Function BX-M2510 Series Reference Manual 8. USB 3.2 Gen2 Ports: USB 3.2 This product is equipped with 4 ports for USB 3.2 Gen2 TYPE-A interface. USB3.2 Gen2 Connector Pin No. Signal Name USB_VCC DATA- DATA+...
— — Product Nomenclature and Function BX-M2510 Series Reference Manual 10. Serial Port Interface: SERIAL A, B, C, D This product has 4 ports of RS-232C compliant serial ports supporting up to a baud rate of 115,200bps with a 16-byte transmission-dedicated data buffer and a 16-byte reception-dedicated data buffer.
Page 27
— — Product Nomenclature and Function BX-M2510 Series Reference Manual Serial A port connector Connector used on the product 9-pin D-SUB (MALE) Pin No. RS-232C RS-422 RS-485 DATA- DATA+ RTS- RTS+ CTS+ CTS- Serial B, C, D port connector Connector used on the product 9-pin D-SUB (MALE) Pin No.
This product is equipped with the remote power switch and 6 ports for non-isolated general I/O. * CONTEC Manager is necessary to use the General I/O. (It is already installed for the product OS pre-installed type when shipped from the factory.) CONTEC Manager can be downloaded through the CONTEC's Web site.
Page 29
— — Product Nomenclature and Function BX-M2510 Series Reference Manual Input equivalent circuit When selecting inputs (an example of connecting the product to a switch) When the switch is “ON”, the relevant bit indicates “0”. When the switch is “OFF”, the relevant bit indicates “1”.
— — Product Nomenclature and Function BX-M2510 Series Reference Manual 12. DVI Interface: DVI-I This product is equipped with a connector for a DVI-I interface. A display of DVI-I interface can be connected. DVI connector Connector used on the product DVI-I connector 29 Pin (FEMALE) Pin No.
Page 31
— — Product Nomenclature and Function BX-M2510 Series Reference Manual DVI-analog RGB conversion adapter Connector used on the product DVI-I 29pin Analog RGB-side signals Pin No. Signal name Pin No. Signal name GREEN BLUE N.C. N.C. DDC DATA HSYNC VSYNC...
— — Product Nomenclature and Function BX-M2510 Series Reference Manual 13. DisplayPort Interface: Display port The product is equipped with a connector for DisplayPort interface. DisplayPort connector Connector used on the product Display Port 20 Pin Pin No. Signal name Pin No.
— — Hardware Setup BX-M2510 Series Reference Manual 1. Before Using the Product for the First Time Follow the next steps to set up this product: STEP1 By referring to the information in this section, install, connect and set up this product.
— — Hardware Setup BX-M2510 Series Reference Manual 2. Hardware Setup Before you start, be sure that the power is turned off. Remove only those screws that are explained. Do not move any other screws. Only 2.5 inches SATA HDD / SSD can be installed to this drive bay.
Page 36
— — Hardware Setup BX-M2510 Series Reference Manual Install the disk bracket equipped with the HDD/SSD into the product, and then fix it with screws. The specified tightening torque is 5kgf⋅cm. CAUTION When tightening the screws to fasten the HDD / SSD to the bracket or the HDD mounted ...
— — Hardware Setup BX-M2510 Series Reference Manual 2. Attaching the Attachment Fittings Use supplied screws to attach the bundled attachment fittings. Do not tighten screws with excess force. CAUTION Screw holes may be damaged if screws are tightened with a torque greater than the specified torque.
— — Hardware Setup BX-M2510 Series Reference Manual 3. Attaching the FG Use screws to attach the FG. CAUTION The FG pin of this product is connected to the GND signal. Note that the connection cannot be cut off. Screw holes may be damaged if screws are tightened with a torque greater than the specified torque.
— — Hardware Setup BX-M2510 Series Reference Manual 4. Fastening the Cable This product comes with the cable tie for fixing cables. Fastening the Audio cable, USB cable The product has a hole for attaching a cable tie. Using the tie for a connector that has no lock mechanism, such as the Audio and USB cables, prevents the connector from being unplugged.
— — Hardware Setup BX-M2510 Series Reference Manual 5. Setting the optional Fan Unit With the optional Fan Unit [BX-FAN-06], this product can be used at higher ambient temperatures in the zero-wind environment. Insert the connector of the fan unit into the product and secure the fan and finger guard with the supplied screws.
— — Hardware Setup BX-M2510 Series Reference Manual 6. Installation Requirements The product can be installed in any orientation (1) through (4). Increase the distance between the main unit and devices that generate heat or exhaust air, or take other measures to ensure the ambient temperature falls within the range specified in the installation environment requirements.
Page 42
— — Hardware Setup BX-M2510 Series Reference Manual Distances between the BOX-PC and its vicinity (Exemplar) Minimum distance for removing the SATA disk CAUTION The wall temperature must be under the product assurance temperature. Please adjust the air current to prevent the reject heat from the product staying around the ...
Page 43
— — Hardware Setup BX-M2510 Series Reference Manual Ambient temperature In this product, the ambient temperature is decided from the multiple measurement points as shown below. When making use of the product, the air current should be adjusted to prevent that all the temperatures measured at the measurement points exceed the specified temperature.
— — BIOS Setup BX-M2510 Series Reference Manual 1. Before Configuring BIOS Settings The BIOS software controls the hardware required for booting the system. The default BIOS settings are configured for optimal performance under normal use. These default settings are recommended under the following circumstances.
— — BIOS Setup BX-M2510 Series Reference Manual 1. Using Aptio Setup Utility This section explains how to use Aptio Setup Utility. Starting the Setup Utility Aptio Setup Utility can be started by any of the following methods. By pressing <Del> or <Esc> key immediately after turning on the pc.
Page 47
— — BIOS Setup BX-M2510 Series Reference Manual Key Operations Use the following keys to operate the setup utility. Function Up Arrow Move to the previous item Down Arrow Move to the next item Left Arrow Move to the item on the left (menu bar)
Page 48
— — BIOS Setup BX-M2510 Series Reference Manual Discard Changes and Exit Exit Aptio Setup Utility without saving the changed settings. Press the <Esc> key or select “Discard Changes and Exit” in the “Save & Exit” menu screen. The following message will be displayed.
— — BIOS Setup BX-M2510 Series Reference Manual 2. Setup Utility Menu The six menu options in Aptio Setup Utility are shown below. Use the right or left arrow key to navigate between menus, and use the up or down arrow key to access the settings.
— — BIOS Setup BX-M2510 Series Reference Manual 2. Main Menu Use this menu to check basic system configuration. The following items are displayed. (Actual display may differ) Display item in the main menu Item Options Description Project Version M2500x x.xx x64 This item displays the BIOS version.
— — BIOS Setup BX-M2510 Series Reference Manual 3. Advanced Menu Use the Advanced menu to configure the settings for the CPU and other devices on the motherboard. The following items are available: (Actual display may differ) CPU Configuration Use this menu to configure the CPU configuration.
Page 52
— — BIOS Setup BX-M2510 Series Reference Manual Super IO Configuration Use this menu to configure the operation settings for Super IO. H/W Monitor Use this menu to check hardware monitors such as the CPU temperature. USB Configuration Use this menu to specify USB controller settings.
Page 53
— — BIOS Setup BX-M2510 Series Reference Manual CPU Configuration Use this menu to configure the information of CPU. Display items differ depending on the installed CPU. CPU Configuration Item Options Description Intel (VMX) Virtualization Configure the Intel (VMX) Virtualization...
Page 54
— — BIOS Setup BX-M2510 Series Reference Manual SATA Configuration Use this menu to specify the SATA controller settings. (Actual display may differ) SATA Configuration Item Options Description Configure the SATA controller operation settings. SATA Controller(S) Enabled / Disabled If the settings are changed, the drive on SATA will not be identified.
Page 55
— — BIOS Setup BX-M2510 Series Reference Manual PCH-FW Configuration Use this menu to configure the version of PCH-FW and configure the TPM. (Actual display may differ) PCH-FW Configuration Item Options Description ME State Disabled / Enabled Do not change this setting.
Page 56
— — BIOS Setup BX-M2510 Series Reference Manual Intel(R) Rapid Storage Technology CAUTION If SATA Mode Selection is not set to Intel RST(RAID), Intel(R) Rapid Storage Technology will not be displayed. Refer to "Software RAID Setup (page83)" for the setting procedure.
Page 57
— — BIOS Setup BX-M2510 Series Reference Manual Create RAID Volume Create RAID volume. Create RAID Volume Item Options Description Name Volume1 Set the volume name of RAID volume. RAID0 (Stripe) Set the type of RAID volume. Do not set other than...
Page 58
BX-M2510 Series Reference Manual CAUTION Always refer to "Software RAID Setup (page83)" when creating RAID volume. The CONTEC only supports mirroring. If you intend to create RAID volume other than mirroring, we leave it as user’s option. - 58 -...
Page 59
— — BIOS Setup BX-M2510 Series Reference Manual Trusted Computing Use this menu to configure the Trusted Computing. (Actual display may differ) Trusted Computing Item Options Description TPM 2.0 Support Disabled / Enabled Configure the TPM 2.0 settings. SHA-1 PCR Bank Disabled / Enabled Do not change this setting.
Page 60
— — BIOS Setup BX-M2510 Series Reference Manual ACPI Settings Use this menu to configure ACPI power management settings. ACPI Settings Item Options Description Disabled / Enabled Configure the Enable Hibernation function settings. Enable Hibernation Suspend Disabled Configure the ACPI Sleep State function settings.
Page 61
— — BIOS Setup BX-M2510 Series Reference Manual SMART Settings Use this menu to check the SMART settings. SMART Settings Item Options Description SMART Self-Test Disabled / Enabled Run the SMART Self Test to SATA device during POST. - 61 -...
Page 62
— — BIOS Setup BX-M2510 Series Reference Manual Super IO Configuration Use this menu to configure the operation settings for Super IO. Super IO Configuration Item Options Description Serial Port 1 Configuration Refer to "Serial Port 1 Configuration" Configure the serial A settings.
Page 63
— — BIOS Setup BX-M2510 Series Reference Manual Item Options Description high/low is necessary. When this is enabled, hardware controlling will be automatically performed and it eliminates software controlling. This function is only available when "RS-485" is selected for Mode Select.
Page 64
— — BIOS Setup BX-M2510 Series Reference Manual H/W Monitor Use this menu to check hardware monitor information such as the CPU temperature. (Actual display may differ) - 64 -...
Page 65
— — BIOS Setup BX-M2510 Series Reference Manual USB Configuration Use this menu to configure the USB controllers. (Actual display may differ) USB Configuration Item Options Description Configure the USB storage support settings USB Mass Storage Driver Support Enabled / Disabled with BIOS.
Page 66
— — BIOS Setup BX-M2510 Series Reference Manual Item Options Description Enabled : The information should be compared. Disabled : The information should not be compared. *When this device is found, it indicates the information is not the same. Ignored : Even when this device cannot be found, the comparison will be ignored.
— — BIOS Setup BX-M2510 Series Reference Manual 4. Chipset Menu Specify the detailed chipset functions. The following items are available. System Agent (SA) Configuration Use this menu to check the System Agent configuration. PCH-IO Configuration Use this menu to specify the PCH-IO configuration.
Page 68
— — BIOS Setup BX-M2510 Series Reference Manual System Agent (SA) Configuration Use this menu to configure the System Agent configuration. System Agent (SA) Configuration Item Options Description Refer to Graphics Configuration Graphics Configuration Do not change this setting.
Page 69
— — BIOS Setup BX-M2510 Series Reference Manual Item Options Description 32M/F7 256MB DVMT Total Gfx Mem Do not change this setting. 128MB PAVP Enable Enabled / Disabled Do not change this setting. - 69 -...
Page 70
— — BIOS Setup BX-M2510 Series Reference Manual PCH-IO Configuration Use this menu to configure the operation settings for PCH-IO. PCH-IO Configuration Item Options Description Refer to HD Audio HD Audio Configuration Configuration. Onboard LAN A Controller Enabled / Disabled Configure the controller settings for LAN A.
Page 71
— — BIOS Setup BX-M2510 Series Reference Manual Item Options Description the power is supplied. BIOS Lock Enabled / Disabled You can prohibit rewriting of the BIOS. HD Audio Configuration Item Options Description HD Audio Configure the HD Audio settings.
— — BIOS Setup BX-M2510 Series Reference Manual 5. Security Menu Configure the security of the system settings. The following items are available. Administrator Password Set the Administrator Password. Press Enter to display the following screen for entering the password.
Page 73
— — BIOS Setup BX-M2510 Series Reference Manual CAUTION Be careful to not forget the password. If you forget the password, the product will have to be repaired at an extra cost. - 73 -...
Page 74
— — BIOS Setup BX-M2510 Series Reference Manual Secure Boot menu Configure the Secure Boot settings. Leave these settings as configured before shipment. Secure Boot menu Item Options Description Secure Boot Do not change this setting. Disabled / Enabled...
— — BIOS Setup BX-M2510 Series Reference Manual 6. Boot Menu Configure the settings boot devices and other devices. Boot Configuration Item Options Description Set the standby time for BIOS Setup <Del> Setup Prompt Timeout or <F2> input. Unit : [second]...
— — BIOS Setup BX-M2510 Series Reference Manual 7. Save & Exit Menu Use this menu to save/restore BIOS settings and exit the setup utility. The following items are available. Save Changes and Exit Save the changed settings and exit.
Page 77
— — BIOS Setup BX-M2510 Series Reference Manual Save as User Defaults Save the settings as the user default values. Restore User Defaults Return the settings to the user default values. Boot Override Specify this setting when you want to temporarily start the system from a connected device other than those that have been set with the Boot Configuration menu.
— — BIOS Setup BX-M2510 Series Reference Manual 8. CONTEC Utility Menu Utility that runs on the UEFI environment can be used. The following items are available. Disk Copy Copy the disk and perform such functions as backup and restore.
Page 79
— — BIOS Setup BX-M2510 Series Reference Manual Disk Copy Copy the disk and perform such functions as backup and restore. Available only when two or more storage devices are connected. (Actual display may differ) Disk Copy Item Options...
Page 80
— — BIOS Setup BX-M2510 Series Reference Manual Item Options Description The copy source disk file data is copied to the copy destination disk. The file must be saved with the name “conback_x” (where “x” is a sequential number). The copy source disk must be in FAT32 format.
Page 81
— — BIOS Setup BX-M2510 Series Reference Manual Self Inspection Use this menu item to perform self-inspection. (Actual display may differ) Self Inspection Item Option Description Checks whether the expected PCI devices PASS are present. [PASS] is displayed if all devices...
Page 82
LAN EEPROM Check FAIL Checking will not be possible if no LAN device is found. PASS Check whether the MAC data from CONTEC CONTEC MAC FAIL has been written. PASS Check whether the MAC data is unique in Unique MAC FAIL the actual device.
1. Outline This section describes software mirroring (RAID1) setup. The CONTEC only supports mirroring. We do not support operation for other RAIDs. Be aware that functions not supported are outside the scope of the warranty. Software RAIDs are not hot-swappable.
Make sure to create RAID volume first, then install operating system. If you create a RAID volume after installing OS, data will be erased and it cannot start OS. The CONTEC only supports mirroring. If you intend to create RAID volume other than mirroring, we leave it as user’s option.
Page 86
— — Software RAID Setup BX-M2510 Series Reference Manual Create RAID volume Go to Advanced> Intel(R) Rapid Storage Technology> Create RAID Volume. Set RAID Level for <RAID1 (Mirror)>. In Select Disks, set <x> in [ ] for two of SATA disks that configure RAID.
Page 87
— — Software RAID Setup BX-M2510 Series Reference Manual Press [F4] key, select [Save & Exit Setup]. Please select [Yes] and press [ENTER] key. You have now finished creating RAID volume. After RAID volume has been created, the volume will be displayed in Advanced> Intel(R) Rapid Storage Technology>...
Page 88
— — Software RAID Setup BX-M2510 Series Reference Manual RAID Volume The state of RAID volume can be checked and deleted. Also, the state of SATA disk that configures RAID volume can be checked. RAID VOLUME INFO Item Options Description ▶...
— — Software RAID Setup BX-M2510 Series Reference Manual 3. Delete RAID Volume (RAID1(Mirror)) Describe the procedure for deleting RAID volume. Follow the steps below on the BIOS setup screen. CAUTION Data may be lost if an existing RAID volume is deleted. Back up the data on a RAID volume before deleting it if the data is important.
Page 90
— — Software RAID Setup BX-M2510 Series Reference Manual When the following message appears, select <Yes>. Press [F4] key, select [Save & Exit Setup]. Please select [Yes] and press [ENTER] key to save the setting. You have now finished deleting RAID volume.
— — Software RAID Setup BX-M2510 Series Reference Manual 4. RAID setup when replacing SATA disk If you replace SATA disk while setting the software mirroring (RAID1), you need to rebuild the mirroring RAID drive. After replacing SATA disk, follow the steps below on the BIOS setup screen.
Page 92
— — Software RAID Setup BX-M2510 Series Reference Manual Select <Rebuild> from Volume Actions. Select the SATA disk to be Rebuild. Press [F4] key, select [Save & Exit Setup]. Please select [Yes] and press [ENTER] key to save the setting.
Page 95
— — Appendix BX-M2510 Series Reference Manual Item Description RJ-45 connector x 2 (supports Wake On LAN) USB 3.2 Gen2 compliant x 4 ports USB 2.0 compliant x 2 ports Serial RS-232C 3ports, RS-232C/422/485 1port, Baud rate: 50 - 115,200bps...
— — Appendix BX-M2510 Series Reference Manual 3. POST Codes POST (hex) Description < Security (SEC) phase > Power on. Reset type detection (software / hardware) AP initialization before microcode loading North Bridge initialization before microcode loading South Bridge initialization before microcode loading...
Page 99
— — Appendix BX-M2510 Series Reference Manual POST (hex) Description 3Ch - 3Eh Post-memory, South Bridge initialization (South Bridge module specific) 3Fh - 4Eh OEM post memory initialization codes DXE IPL is started < Driver Execution Environment (DXE) phase >...
Page 100
— — Appendix BX-M2510 Series Reference Manual POST (hex) Description SCSI initialization is started SCSI Reset SCSI Detect SCSI Enable Setup Verifying Password Start of Setup Reserved for ASL (see ASL Status Codes section below) Setup Input Wait Reserved for ASL (see ASL Status Codes section below)
— — Appendix BX-M2510 Series Reference Manual 4. SERIAL I/O Address and Register Function I/O Port Addresses The following table lists the I/O addresses in case of SERIAL A. I/O address DLAB Read/Write Register Transmitter holding register 03F8H Receive buffer register...
Page 104
— — Appendix BX-M2510 Series Reference Manual I/O address Description 03FDH 03FEH 03FFH SCR: Scratchpad Register This is an 8-bit, readable/writable register which is available to the user to allow data to be saved temporarily. - 104 -...
Page 105
— — Appendix BX-M2510 Series Reference Manual Baud Rate Settings A baud rate is set by software by dividing the clock input (1.8432MHz). The baud rate in terms of hardware can be set to a maximum of 115,200 bps for SERIALA, B, C and D. The baud rates available in practice depend on the operating environment (cable, software, etc.).
* It is also possible not to perform [WDT Stop] instead of performing [WDT Stop] to [WDT Start], but to perform [WDT Start] continuously at the time of a re-start. CONTEC Manager is necessary to use the watch-dog-timer. (It is already installed for the product OS pre-installed type when shipped from the factory.)
Page 107
— — Appendix BX-M2510 Series Reference Manual CONTEC Manager can be downloaded through the CONTEC's Web site. For more detailed information, contact your retailer. CAUTION The timer’s intervals have a tolerance of ±2 seconds. - 107 -...
— — Appendix BX-M2510 Series Reference Manual 6. Battery Disposal 1. Battery Specification The product contains one battery, and the details are as follows: Item Description Type Lithium primary battery Model BR-2032/BN Maker Panasonic Nominal Voltage Nominal capacity 200mAh Lithium content...
— — Appendix BX-M2510 Series Reference Manual 2. Dispose of the Battery WARNING For battery replacement, contact your retailer as it must be performed as a process of repair. Do not attempt to replace the battery as inappropriate battery replacement poses a risk of ...
— — Appendix BX-M2510 Series Reference Manual 7. Life of SSD 1. About write endurance SSD contained in product has a write endurance which limits the number of times each memory may be written, due to the characteristic of the memory that is used. Write endurance can be calculated...
— — Appendix BX-M2510 Series Reference Manual 2. About S.M.A.R.T. Life endurance can be estimated by installing the self-diagnosis program that can obtain the S.M.A.R.T. information of SSD. * Ask your retailer for details. - 111 -...
DC FAN UNIT for box computer CAUTION If a product other than our optional one is used, the normal operation may be impaired or the functions may be limited. Visit the CONTEC website for the latest optional products. https://www.contec.com/ Website - 113 -...
Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. - 114 -...
— — Customer Support and Inquiry BX-M2510 Series Reference Manual 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the CONTEC website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages. Membership registration (myCONTEC) is required to use the services.
Page 116
October 2022 The First Edition Copyright Copyright 2022 CONTEC CO., LTD. ALL RIGHTS RESERVED. The information contained in this document is subject to change without prior notice. Should you notice an omission or any questionable item in this document, please feel free to ...
Page 117
3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. BX-M2510 Series Reference Manual NA09189 (LXBV182) 01252023_rev2 [10142022] January 2023 Edition...
