Contec BX-R100 Series Manual

Pre-installed model os
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Pre-installed Model
OS Manual
(Windows 10 IoT Enterprise LTSB 2016)
Industrial computer
BX-R100 Series
CONTENTS
Introduction .................................................................. 4
Notes Regarding Use .............................................. 10
Setup procedures ..................................................... 17
System Information.................................................. 21
Recovery Method ..................................................... 43
Customer Support and Inquiry ............................ 49

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BX-R100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Contec BX-R100 Series

Summary of Contents for Contec BX-R100 Series

  • Page 1 Pre-installed Model OS Manual (Windows 10 IoT Enterprise LTSB 2016) Industrial computer BX-R100 Series CONTENTS Introduction ..............4 Notes Regarding Use ..........10 Setup procedures ............. 17 System Information..........21 Recovery Method ............. 43 Customer Support and Inquiry ......49...

  • Page 2: Table Of Contents

    Must Read the Followings............................6  Download Manuals ..............................6  3. Manual composition..............................7 4. CONTEC Software License ...........................8 Notes Regarding Use ............10 1. Safety Information ............................... 11 2. Handling Precautions ............................12 3. About Adobe Flash Player ..........................13 4.
  • Page 3 Table of Contents Recovery Method ............43 1. Preparations ................................44 2. Procedure ................................45 1. BIOS settings ..............................45 2. OS installation ..............................46 3. BIOS settings ..............................47 4. Start OS ................................48 Customer Support and Inquiry ........49 1.

  • Page 4: Introduction

    Introduction This will inform you of the information you need to know before using this product, such as an overview of the OS equipped with the preinstalled model, the overall configuration of this manual, the various manuals associated with this product, and so on. —...

  • Page 5: About The Product

    1. About the Product Windows 10 IoT Enterprise LTSB 2016, equipped with the preinstalled model, is the OS for embedded applications. CONTEC’s preinstalled models perform customization to build the OS based on a configuration determined in advance. In this manual you will find basic information on the installed OS, as well as explanations of setup procedures and recovery procedures.

  • Page 6: Related Manuals

    Reference Manual Read this when This describes the hardware Download from operating the product. aspects such as functions the Contec and settings. website (PDF) Pre-installed Model Must read this after This explains basic OS Download from OS Manual (This manual) opening the package.

  • Page 7: Manual Composition

    — — Introduction BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 3. Manual composition This manual is composed as follows: — 7 —...

  • Page 8: Contec Software License

    The copyright, patent right or any other intellectual property right pertaining to the Software or any documentary attachments, such as manuals, as well as any copies thereof (the “Software and the Like”) shall belong to CONTEC, and customers shall have no rights therefor other than those expressly authorized herein.
  • Page 9 BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) Article 6. Termination 1.CONTEC may terminate the Agreement with immediate effect without any notice or demand to the customer if the customer fails to comply with any of the provisions herein.

  • Page 10: Notes Regarding Use

    Notes Regarding Use This manual explains the precautions for using the product safely. Please make sure to read this before using this product. — 10 —...

  • Page 11: Safety Information

    — — Notes Regarding Use BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely.

  • Page 12: Handling Precautions

    Even when using the product continuously, be sure to read the manual in the CONTEC’s website and understand the contents. Do not modify the software. CONTEC will bear no responsibility for any problems, etc.,  resulting from modifying the software.

  • Page 13: About Adobe Flash Player

    — — Notes Regarding Use BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 3. About Adobe Flash Player Adobe Flash Player is disabled by default. You may require a license from Adobe Systems Incorporated or the partner of Adobe.to use the service.

  • Page 14: About Unified Write Filter

    — — Notes Regarding Use BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 4. About Unified Write Filter Unified Write Filter function (referred to as “UWF” in this document) is the new filtering which combined EWF, FBWF, and Registry filter. UWF has deterred the write to DISK by redirecting the write to DISK from operating system or application to overlay.
  • Page 15 — — Notes Regarding Use BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) In early stages, a UWF overlay region serves as maximum size of 1024 MB.  The present operating condition of a UWF overlay region can be checked by the following command.

  • Page 16: Security Warning

    — — Notes Regarding Use BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 5. Security Warning When connecting to the network, be aware of security-related problems. See the examples of Security measures below and set up the product properly along with the network devices. 1.

  • Page 17: Setup Procedures

    Setup procedures This manual describes the setup procedure that a user needs to perform after unpacking the product with a pre-installed operation system. The setup of Windows is performed interactively. — 17 —...

  • Page 18: Windows Setup

    — — Setup procedures BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 1. Windows setup Check that the monitor, the keyboard and the mouse are connected with the PC. Do not connect other devices until a Windows setup is completed. After confirming the connections, turn on the PC power.
  • Page 19 — — Setup procedures BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) Please select the zone, a language, etc. to be used. And, Click Next It is a document regarding License. Click the Accept It is a setup about operation of OS. Click Use Express settings "Restarting in a moment"...
  • Page 20 — — Setup procedures BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) "Just a moment" displays, and some reboots are done. When a password setting is skipped, an automatic logon can be made by the created account (user name). —...

  • Page 21: System Information

    System Information Explains the preinstalled model’s basic system information and main device driver versions, etc. — 21 —...

  • Page 22: Basic Information

    Update Version:11.0.126(KB4505050) versions Windows Media Player 12.0.14393.2999 Microsoft .NET Framework 4.6.2 Remote Desktop Connection 10.0.14393 Remote Desktop Protocol 10.2 CONTEC utilities CONTEC Manager 4.0.2 TPBK(S) Supply schedule Mainstream support end date 2021/10/12 Extended support end date 2026/10/13 End of Life 2026/07/31 —...

  • Page 23: Storage And Partition Configuration

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 2. Storage and Partition Configuration The following is for a mSATA with 32GB. * The disk usage indicated is a reference value. — 23 —...

  • Page 24: Programs And Features

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 3. Programs and Features 1. Installed software View a list of installed software 2. Installed updates View a list of installed updates. — 24 —...

  • Page 25: Enable Or Disable Windows Functions

    Internet to perform setup, or recover the preinstalled model. Under CONTEC preinstalled model factory default settings, Device Lockdown is enabled. Using the lockdown function, you can restrict unintentional user operations or control information displayed on the screen.

  • Page 26: Uwf Settings

    4. UWF settings For UWF settings, use either the Microsoft console application UWF manager (uwfmgr.exe) or CONTEC Manager, the GUI application installed in the preinstalled model. The UWF function’s filter is disabled by default. The following explains the procedure for checking the UWF settings using UWF manager (uwfmgr.exe).
  • Page 27 — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) When UWF is enabled, writing to the disk will be restricted, allowing for the lifetime of disks with writing restrictions to be lengthened. It also allows you to prevent unintentional system alterations. Below is a configuration graph of the UWF functions.
  • Page 28 — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) Input “uwfmgrget-config” and press the [Enter] key. View current setting status. Enter the Item Display Meaning command Filter state Disabling the Enabling the Check the state Volume state Un-protected Invalid Volume...

  • Page 29: Main Device Drivers

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 4. Main device drivers Category Data IDE ATA/ATAPI Controller SD host adapters Display Adapter — 29 —...
  • Page 30 — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) Network Adapters Sound video and game controller System devices — 30 —...
  • Page 31 — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) Universal Serial Bus Controller — 31 —...

  • Page 32: Set To Factory Default Values

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 5. Set to factory default values This section explains the preinstalled model’s various factory default settings. You can reset these settings unless their values are specially designated. 1.

  • Page 33: Ethernet Settings

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 2. Ethernet settings The preinstalled model’s product Ethernet display and the OS Ethernet recognition status are shown below. Product Ethernet display OS Ethernet recognition LAN A Ethernet LAN B Ethernet 2...

  • Page 34: Serial Port Settings

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) [Internet Protocol Version 6] IP address : automatically DNS : automatically 3. Serial Port Settings The preinstalled model’s product SERIAL display and OS SERIAL recognition status are shown below. Product SERIAL display OS SERIAL recognition SERIAL...

  • Page 35: Optional Power Settings

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 4. Optional power settings This section explains the factory settings for power options. Power and sleep button settings When I press the power button : Shut down Shutdown settings Turn on fast startup(recommended) : Off Advanced settings...

  • Page 36: Changing The Language

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 6. Changing the language The preinstalled model supports English, Japanese, Korean and Simplified Chinese. The following explains how to manually change the language settings. As an example we will explain the procedure for switching from English to Japanese.
  • Page 37 — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) Input “JAPAN” in the textbox, and a list will appear below. Select [ 日本語 (Japanese) and then click [ Next Japanese is added, so select that item. In order to change the current language from English (United States) to Japanese, click [ Set as...
  • Page 38 — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) In Control Panel, click [ 時計、言語、および地域 ], then click [ (Clock and Region) 地域 ]. The [ ] properties (Region) 地域 (Region) screen appears. Select the [ 管理...

  • Page 39: Windows Update

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 7. Windows Update You can install the correction program (QFE) in [Update & Security]. On the [ ] menu, click [ Start Settings Click [ Update & Security —...

  • Page 40: Contec Manager

    8. CONTEC Manager 1. Overview CONTEC provides not only functions installed with this product such as the RAS function to secure reliability and the UWF function providing the OS, but also setting tools that allow you to use CONTEC products more smoothly and a library to control the functions listed below.

  • Page 41: Properties Screen

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 3. Properties screen *The following images may differ from the actual product. Monitor hardware status such as the CPU temperature, the M/B temperature and so on. If it exceeds the set threshold, the set alarm action will be activated.

  • Page 42: Uwf Settings

    — — System Information BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 4. UWF settings The following explains the method for setting write protection for the C drive. ① Click [ ] and set to [ ② Tick the volume [ ] targeted for protection.

  • Page 43: Recovery Method

    Recovery Method This chapter explains how to recover the OS in the event that it is unable to start in the preinstalled model. — 43 —...

  • Page 44: Preparations

    — — Recovery Method BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 1. Preparations This document describes the recovery procedures in a case where OS becomes unable to start up on a preinstalled-OS system. The Recovery uses USB connection’s DVD-ROM Drive. Please prepare a necessary equipment according to DVD-ROM used.

  • Page 45: Procedure

    — — Recovery Method BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 2. Procedure Before performing the operation, connect the monitor, USB-HUB, USB keyboard, USB mouse and USB DVD-ROM drive to the product. 1. BIOS settings Please set recovery media (Disc 1 of 2) to a USB DVD-ROM drive, and connect with PC. Turn on the power supply of PC and Press [DEL] key or [ESC] key immediately after turning on the power, activating Aptio Setup Utility.

  • Page 46: Os Installation

    (If you do not continue the recovery, press N key.) HDD/SSD initialization and recovery CImage Tool for Windows processing will be performed automatically. Copyright<C> 2017 CONTEC CO., LTD. Version X.X.X.X Copy swm file: xxxxx.swm [xx%] copied The screen on the left will appear. Take out the...

  • Page 47: Bios Settings

    — — Recovery Method BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 3. BIOS settings After restarting the system by the method outlined above, immediately press [DEL] or [ESC] to start the BIOS settings screen (Aptio Setup Utility). Aptio Setup Utility - Copyright ©...

  • Page 48: Start Os

    — — Recovery Method BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 4. Start OS The screen of the left figure is displayed after several times reboot. Perform Windows setup following the setup procedure in this manual. — 48 —...

  • Page 49: Customer Support And Inquiry

    Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. — 49 —...

  • Page 50: Services

    — Customer Support and Inquiry BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the Contec website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages.
  • Page 51 No part of this document may be copied or reproduced in any form by any means without  prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained  in this document.
  • Page 52 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. BX-R100 Pre-installed Model OS Manual(Windows 10 IoT Enterprise LTSB 2016) NA06819 (LYXD942)
