OPERATION

QUICK START HUB MODE

The QUICK START HUB MODE is used with Precision Hub Plate systems. The Quick
Start procedure provides instructions to compensate for the weight difference of the
Precision Hub Plate System wheel and tire assemblies. Prior to initiating the QUICK
START HUB MODE procedure, refer to the QUICK START NORMAL procedure for
initial screen setup instructions.
The following Compensation Formula is used to calculate the following hub
compensations for each wheel; Tire Weights, Hub Assembly Weights and Cambers.
Displayed Weight For Each Corner = [Uncompensated Weight* + Tire Assy Weight -
Hub Plate Weight]
* If cambers have been entered, the uncompensated weight reflects the camber input.
ATTENTION: When weights are entered for the hub plate and tire assemblies,
pressing the ZERO key will zero the system. However, the difference between
the tire and hub plate weights for each wheel position may result in the indicator
zeroing to a non-zero value.
If using the Precision Hub Plate / Scale System, follow the setup instructions set forth in
the SETUP section of the Precision Hub Plate System User Manual.
ATTENTION: Prior to accessing the HUB Mode, weigh each wheel, tire and Hub
Plate assembly to be replaced. Record the values for future use.
COMPENSATION FORMULA
Page 21
SW500 Wired Scale System
700431 Rev G, December 2021
