SW500 Wired Scale System
700431 Rev G, December 2021
INDICATOR OVERVIEW
Indicator Controls (continued)
The Baud Rate of the SW scale must match the Baud Rate setting of the indicator to
enable wireless communication. To change the Baud Rate press the 2 key. The active
Baud Rate will have an asterisk to the right the of the number displayed. Press the
corresponding key to change the Baud Rate. Refer to the Serial Output section for
additional information.

CLEAR

When in Normal weighing mode, press the CLEAR key to erase a memory location.
Press the CLEAR key to reset the number to 00 when accessing a numeric entry
screen. Refer to the Clear Baseline Setup section for additional information.

STORE/ENTER

The STORE/ENTER key is used to store a setup as a target setup. Refer to the Store
Baseline Setup section for additional information. The STORE/ENTER key is also used
to save a numeric entry.

COMPARE

Press the COMPARE key to compare the actual weight to the target weight. The value
is positive when the actual weight is less than target weight. The value is negative when
the actual weight is greater than the target weight.

TARGET

The ideal weight setup for the car is described as the Target weight. Press the TARGET
key to view the target weight. Refer to the Store Baseline Setup and Recall Baseline
Setup sections for additional information.

ACTUAL

Press the ACTUAL key to view the actual weight.
Page 11
