APPENDIX
SHUTDOWN APPENDIX
Menu item Sub item / Parameter
(80) Max Setp Offset Up
(81) Start Mod Delay Fact
(82) Next Module Start Rate
(83) Next Module Stop Rate
(84) Module Rotation Interval
(149) First Module to Start
(86) MC PID P
(87) MC PID I
(150) MC PID Slew Rate Up
(151) MC PID Slew Rate Dn
(152) PwrMode2 Min Power
(153) PwrMode2 Hysteresis
(154) Post-Pump period
(184) N. active burner for DHW
Boiler Cascade Settings
(73) Boiler Address
(156) Permit Emergency Mode
(157) Emergency Setpoint
(158) Delay Per Start Next Blr.
(159) Delay Per Stop Next Blr.
(160) Delay Quick Start Next
(161) Delay Quick Stop Next
(162) Hyst Down Start Boiler
(163) Hyst Up Stop Boiler
(164) Hyst Down Quick Start
(165) Hyst Up Quick Stop
(166) Hyst Up Stop All
(167) Number of boilers
(168) Power Mode
(169) Max. Setp. Offset Down
(170) Max Setp Offset Up
(171) Start Mod Delay Fact
(172) Next Boiler Start Rate
(173) Next Boiler Stop Rate
(174) Boiler Rotation Interval
(175) First Boiler to Start
(176) BC PID P
(177) BC PID I
(178) BC PID Slew Rate Up
(179) BC PID Slew Rate Dn
(180) PwrMode2 Min Power
(181) PwrMode2 Hysteresis
(182) Post-Pump period
Range
0...40 (0...72)
0...60
10...100
10...100
0...30
1...16
0...1275
0...1275
0...25.5
0...25.5
0...100
0...100
0...255
0...16
Stand-alone (0)
Managing (1)
Dependent (2...8)
Yes/No
20...90 (68...194)
0...1275
0...1275
0...1275
0...1275
0...40 (0...72)
0...40 (0...72)
0...40 (0...72)
0...40 (0...72)
0...60 (0...108)
1...16 (basic cascade) 1...8
(full cascade)
0) Disabled
2) Max burners
3) Balanced burners
0...40 (0...72)
0...40 (0...72)
0...60
10...100
10...100
0...30
1...8
0...1275
0...1275
0...25.5
0...25.5
0...100
0...100
0...255
70 70
Default Value Units
20 (36) °C (°F)
60 Min.
80 %
25 %
5 Days
1
50
500
1.0
1.0
20 %
40 %
60 Sec.
16
Managing
Yes
70 (158) °C (°F)
1275 Sec.
1275 Sec.
400 Sec.
240 Sec.
5 (9) °C (°F)
2 (4) °C (°F)
10 (18) °C (°F)
4 (7) °C (°F)
8 (14) °C (°F)
1
2
0 (0) °C (°F)
20 (36) °C (°F)
40 Min.
80 %
25 %
5 Days
-
25
1000
1.0
1.0
20 %
40 %
30 sec
User level
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
3: Factory
3: Factory
3: Factory
3: Factory
2: Installer
2: Installer
2: Installer
2:Installer
2: Installer
1: User
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
2: Installer
3: Factory
3: Factory
3: Factory
3: Factory
2: Installer
2: Installer
2: Installer
