Section 7 - Operating Instructions & Functions Test
At the Platform Controls
1. Turn the Key Switch to platform control.
Test Emergency Stop
1. Push in the platform red Emergency Stop button to the off position.
Result: No functions should operate.
2. Turn the red Emergency Stop button clockwise to the on position.
Result: The LED indicator light should come on.
Test the Horn
1. Push the horn button.
Result: The horn should sound.
Test Function Enable and Up/Down Functions
1. Do not hold the function enable switch on the control handle.
2. Slowly move the control handle in the direction indicated by the blue arrow, then in the direction
indicated by the yellow arrow.
Result: No functions should operate.
3. Press the lift function select button.
4. Press and hold the function enable switch on the control handle.
5. Slowly move the control handle in the direction indicated by the yellow arrow.
Result: The platform should raise.
6. Release the control handle.
Result: The platform should stop raising.
7. Press and hold the function enable switch. Slowly move the control handle in the direction
indicated by the blue arrow.
Result: The platform should lower. The descent alarm should sound while the platform is
lowering.
Test the Steering
Note: When performing the steer and drive function tests, stand in the platform facing the steer end
of the machine.
1. Press the drive function select switch.
2. Press and hold the Function Enable Switch on the control handle.
3. Depress the thumb rocker switch on top of the control handle in the direction identified by the
blue left arrow on the control panel.
Result: The steer wheels should turn in the direction that the blue left arrow points on the
control panel.
4. Depress the thumb rocker switch in the direction identified by the white right arrow on the control
panel.
Result: The steer wheels should turn in the direction that the white right arrow points on the
control panel.
Page 17
Check the area above and around the machine for obstructions and
electrical power lines before operating the machine.
1330SE - Operator's Manual
June 2023
